Summary of Contents for Motorline professional MR30
- Page 1 MR30 USER'S AND INSTALLER'S MANUAL v1.1 REV. 07/2020...
- Page 2 00. CONTENT 01. SAFETY INSTRUCTIONS INDEX STANDARDS TO FOLLOW 01. SAFETY INSTRUCTIONS This product is certified in accordance with European STANDARDS TO FOLLOW Community (EC) safety standards. 02. THE PRODUCT This product complies with Directive 2011/65/EU of the TECHNICAL SPECIFICATIONS European Parliament and of the Council, of 8 June 2011, on 03.
- Page 3 01. SAFETY INSTRUCTIONS GENERAL WARNINGS • Children shouldn’t play with the product or opening devices to avoid the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. very important. Read all instructions carefully before beginning the WARNINGS FOR TECHNICIANS installation/usage procedures and keep this manual in a safe place that it can be consulted whenever necessary.
- Page 4 01. SAFETY INSTRUCTIONS RESPONSABILITY September 2009. • Attach the permanent label for the manual release as close as possible • Supplier disclaims any liability if: to the release mechanism. • Product failure or deformation result from improper installation • Disconnect means, such as a switch or circuit breaker on the electrical use or maintenance! panel, must be provided on the product’s fixed power supply leads in •...
- Page 5 02. THE PRODUCT 03. INSTALLATION TECHNICAL SPECIFICATIONS MOUNTING PRECAUTIONS • Supply Voltage 12-24 Vac/dc 50/60Hz • Detection Method To prevent leakage, malfunction or damage, please follow instructions below. Active Infrared Reflection • Installation Height 3 meters 12Vac: 1.3VA max. 24Vac: 1.5VA max. Mount lower than 3m (9.8ft).
- Page 6 03. INSTALLATION 04. PROGRAMMING MOUNTING AND WIRING DIP SWITCH SETTINGS • Determine the mounting position of the device and attach Mounting Default Setting Template. Drill mounting and wiring holes. Quantity of Self- Monitoring Monitor Mode Presence Timer Frequency Detection Rows •...
- Page 7 04. PROGRAMMING 04. PROGRAMMING APPLYING POWER ADJUSTING DETECTION PATTERN • Width adjustment - You can adjust the detection width by Area mask Before turning on the power, please wire the door controller to the sensor. If there is a moving turning Area Mask with a screwdriver.
- Page 8 05. TROUBLESHOOTING INSTRUCTIONS FOR CONSUMERS AND SPECIALIZED TECHNICIANS PROBLEM POSSIBLE CAUSE SOLUTION Connector not connected correctly. Tighten or reconnect the connector. Door does not operate Incorrect power supply voltage. Apply proper voltage to the sensor. (AC/DC 12-24V). Wipe Detection Window clean and install a weather cover if necessary (Chemicals Dust, frost or water droplet on the sensor lens.
