- Page 1 MD150 MD150 INSTALLER AND USER’S MANUAL M O D R E S E v1.0 REV. 04/2023...
-
Page 2: Table Of Contents
00. CONTENT 01. SAFETY INSTRUCTIONS INDEX ATTENTION: 01. SAFETY INSTRUCTIONS This product is certified in accordance with European Community (EC) safety standards. 02. MAGNETIC DETECTOR TECHNICAL CHARACTERISTICS This product complies with Directive 2011/65/EU of the 03. PRE INSTALLATION European Parliament and of the Council, of 8 June 2011, on PRECAUTIONS TO HAVE the restriction of the use of certain hazardous substances in electrical and electronic equipment. -
Page 3: Safety Instructions
01. SAFETY INSTRUCTIONS GENERAL WARNINGS • Children shouldn’t play with the product or opening devices to avoid the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. very important. Read all instructions carefully before beginning the WARNINGS FOR TECHNICIANS installation/usage procedures and keep this manual in a safe place that it can be consulted whenever necessary. - Page 4 01. SAFETY INSTRUCTIONS RESPONSABILITY September 2009. • Attach the permanent label for the manual release as close as possible • Supplier disclaims any liability if: to the release mechanism. • Product failure or deformation result from improper installation • Disconnect means, such as a switch or circuit breaker on the electrical use or maintenance! panel, must be provided on the product’s fixed power supply leads in •...
-
Page 5: Magnetic Detector
03. PRE INSTALLATION PRECAUTIONS TO HAVE TECHNICAL CHARACTERISTICS MD150 is a vehicle magnetic detector that detects the presence of large metal objects (cars, trucks, wagons) even when the vehicle is not moving. Please pay attention to the supply voltage of the equipment. -
Page 6: Installation
Wire DETAIL A DETAIL B INSTALL MD150 Detach the connector base from the MD150 and install on the desired surface. Make the connections according to the diagram on the next page. Put the MD150 back on the connector base. 2000-3000... -
Page 7: Connection Scheme
05. CONNECTION SCHEME 06. PROGRAMMING COMPONENT CONNECTIONS OPERATION AND INDICATION OF STATUS DEVICE CALIBRATION Loop 1 When connecting the device to power, the calibration will be done automatically. The calibration process takes about 3 seconds. During the calibration process, the two green LEDs on the panel remain ON. No vehicle should pass through the loop zone during the calibration process. - Page 8 06. PROGRAMMING 06. PROGRAMMING FREQUENCY ADJUSTMENT AUTOMATIC INCREASE IN SENSITIVITY The adjustment of the frequency of channels 1 and 2 is done on Dip switch #1 and Dip switch #2 The automatic increase in sensitivity increases the sensitivity level to the maximum value. respectively which are located on the front panel of Dippers.
- Page 9 06. PROGRAMMING DIRECTION OF THE CHANNELS You can define whether the two channels work individually (Single) for each direction or whether they work simultaneously (Double) in the same direction. Direction of the channels Dip switch #10 Individual Double DEVICE RESET By pressing the reset button, the device will automatically switch to a vehicle-free mode.
