Instruction Manual
Customer Service
US: 1-800-645-2986
Outdoor Wall Mounted Drinking Fountain
Models 761224, 761224BK,
761224BL & 761224GN
• DO NOT attempt to repair or replace any part of this fountain unless it is specifically
recommended in this manual. All other services should be referred to a qualified technician.
• For use with clean, clear potable drinking water only.
• Shut-off water supply during installation to reduce the risk of water damage.
• Freezing Caution: Before freezing temperatures occur, refer to the Draining and
Winterization section of this manual (page 11) for proper preparation.
• Installation of a trap on the water drain line may be necessary; remove trap before
winterization draining.
• Failure to follow safety warnings and/or installation instructions will void warranty.
NOTE: Included are the necessary vandal-resistant stainless steel bolts and washers needed
to anchor this unit to the wall. Installer must provide a 1-1/2" PVC drain line (if applicable) and
water supply line. All connections are made inside the item through the access door, as shown
in the drawings. It is recommended to install a shut-off valve (not included) on the water supply.
Manual de Instrucciones
Servicio de atención al Cliente
México: 01.800.681.6940
WARNING
• All installation work must be performed
by authorized service personnel.
• Two or more people are recommended
to lift and install the unit.
• To avoid the risk of property damage
and/or personal injury, mount this fountain
to a flat finished wall surface adequate to
support up to 300 lbs.
• Check local codes for plumbing
requirements prior to installation.
• Refer to Rough-In Guide (page 4)
prior to installation.
• Thoroughly flush all water supply lines of all
foreign matter before connecting to the fixture.
• Check for any leaks before use.
1
Distribucion Industrial Globales S DE RL DE CF
Manuel d'instruction
Service à la clientèle
Canada: 888-645-2986
