Outdoor Pedestal Drinking Fountain
WARNING
• All installation work must be performed by authorized
service personnel.
• Two or more people are recommended to lift and
install the unit.
• To avoid the risk of property damage and/or personal
injury, ensure the mounting surface is adequate to
support 400 lbs.
• Check local codes for plumbing requirements prior
to installation.
• Refer to Rough-In Guide (page 4) prior to installation.
• Thoroughly flush all water supply lines of all foreign
matter before connecting to the fixture.
• Check for any leaks before use.
• DO NOT attempt to repair or replace any part of this
fountain unless it is specifically recommended in this
manual. All other services should be referred to a
qualified technician.
• For use with clean, clear potable drinking water only.
• Shut-off water supply during installation to reduce the
risk of water damage.
• Freezing Caution: Before freezing temperatures occur,
refer to the Draining and Winterization section of this
manual (page 11) for proper preparation.
• Installation of a trap on the water drain line may be
Models 761223, 761223BK,
necessary; remove trap before winterization draining.
• Failure to follow safety warnings and/or
761223BL & 761223GN
installation instructions will void warranty.
Note: This unit is designed to be installed on the surface of an existing or new concrete slab.
Included are the necessary vandal-resistant stainless steel bolts and washers needed
to anchor this unit. Installer must provide a 1-1/2" PVC drain line (if applicable) and water supply
line. All connections are made inside the item through the access doors, as shown in the drawings.
It is recommended to install a shut-off valve (not included) on the water supply.
1
Advertisement
Related Manuals for Global 761223
Summary of Contents for Global 761223
- Page 1 Draining and Winterization section of this manual (page 11) for proper preparation. • Installation of a trap on the water drain line may be Models 761223, 761223BK, necessary; remove trap before winterization draining. • Failure to follow safety warnings and/or 761223BL &...
- Page 2 Instruction Manual Outdoor Pedestal Drinking Fountain DRAIN DRAIN PAN BUBBLER PUSH BUT T ON PEDESTAL BASE COLOR OPTIONS: SS316 SS316 GREEN SS316 BLACK SS316 BLUE WWW.GLOBALINDUSTRIAL.COM Package Contents: - Pedestal - Bubbler - Hardware Bag...
-
Page 3: Specifications
Instruction Manual Outdoor Pedestal Drinking Fountain SPECIFICATIONS 316 Stainless, Laminar Flow, Heavy Duty, Vandal Resistant Features: Finish: SS Finish, Black(BK), Blue(BL), Green(GN) Power: No Electrical Required Bubbler Vandal Resistant Activation Type: Push Button Mounting Type: Floor Mount/Free Standing Product Dimensions: 14"L x 14"W x 37-1/2"H Weight: 58.5 lbs. - Page 4 Instruction Manual Outdoor Pedestal Drinking Fountain...
-
Page 5: Installation
Instruction Manual Outdoor Pedestal Drinking Fountain INSTALLATION • It is recommended that 2 or more people install this unit. • This fountain must be mounted on a solid, flat surface with adequate strength (concrete pad recommended) capable of supporting 400 lbs. •... - Page 6 Instruction Manual Outdoor Pedestal Drinking Fountain 2. INSTALL BUBBLER 2a. Unscrew and remove 2b. Locate the hole on the drinking 2c. Bubbler is now nut and washers from fountain pan surface. Align and properly installed. Bubbler (H4). sandwich with the two washers and tighten the nut to secure the bubbler.
- Page 7 Instruction Manual Outdoor Pedestal Drinking Fountain WATER INLET LINE CONNECTION BREAKDOWN: • Install a shut-off valve (not included) on the water supply. • All other internal water lines are preinstalled; see below illustration for reference. • All water connections and drains must comply with local codes. FRONT VIEW SIDE VIEW 1/4"...
- Page 8 Instruction Manual Outdoor Pedestal Drinking Fountain Bubbler Inlet Adapter and Straight Flow Check Valve Push Button Install Shut-off Valve (Not Included) P4: Straight Flow Check Valve: All Water Inlet Connec�ons: OPERATION OF QUICK CONNECT FITTINGS 3/8” O.D. TUBE CONNECT COLD WATER SUPPLY SIMPLY PUSH IN TUBE IS SECURED PUSH IN COLLET...
- Page 9 Instruction Manual Outdoor Pedestal Drinking Fountain WATER DRAIN LINE CONNECTION BREAKDOWN: • Install a shut-off valve (not included) on the water supply. • All other internal drain lines are preinstalled; see below illustration for reference. • All water connections and drains must comply with local codes. •...
- Page 10 Instruction Manual Outdoor Pedestal Drinking Fountain Drinking Fountain Drain Drain Connector 32-3/4” Drain Tube Drain Connector contains quick connections that attaches the Drain Tube to the Drinking Fountain Drain Confirm with local codes for trap and other drainage requirements Note: Turn on water supply and check all connections for leaks and proper operation. Reinstall the (2) access panels using the (10) M6 x 10 flat-head anti-theft screws preciously removed from the fountain.
- Page 11 Instruction Manual Outdoor Pedestal Drinking Fountain START-UP Initial water flow may have sputter due to air in the water lines; this will be eliminated once air is purged from all water lines. Press and hold the push button until a steady water stream is achieved.
