Version
Calibration
● Battery calibration ​ - Use a multimeter to
measure and input the voltage
● RTC battery​ - shows the actual RTC battery
voltage
● Serial port​ - not yet supported
Max. bauds​ - Specify communication baud
●
rate between the T2 and the build-in Crossfire
modul, ​ m ust be set to 400000
● RAS ​ - not used by the Tango 2
● Debug​ - shows the raw values of the switches
and keys
Current build and version of the OpenTX firmware
● As the TANGO II is branch of the OpenTX
codebase it needs it specific build
● Firmware Options​ - shows the included
software modules
Re-perform the gimbal stick calibration
The calibration can be entered on ​ p age 6
●
[CALIBRATION]
● If the initial calibration was incorrect, re-do it
by pressing the Enter-button and follow the
instructions
IMPORTANT​ : on the final step, do NOT move
●
the sticks to their combined extremes (e.g.
top-left, top-right, bottom-left, bottom-right).
Move the sticks in a "+" pattern
16
