- Page 1 USER’ S MANUAL 4.3” TVI/AHD TEST MONITOR MODEL: ATT043 © 2016 Atherton Electronics Corp. All rights reserved.
-
Page 2: Table Of Contents
TABLE OF CONTENTS FCC information ---------------------------------------------------------------------- 3 CE information ------------------------------------------------------------------------ 3 Safety and Environmental Precautions--------------------------------------- 3 Scope -------------------------------------------------------------------------------------- 5 Unpacking -------------------------------------------------------------------------------- 5 Getting Started -------------------------------------------------------------------------- 5 Controls and indicators -------------------------------------------------------------- 7 Regulatory Agency ------------------------------------------------------------------- 9 Reliability ------------------------------------------------------------------------------- 9 Mechanical ----------------------------------------------------------------------------- 10... -
Page 3: Fcc Information
FCC INFORMATION This Equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 4 6. Refer all servicing to qualified service personnel. REMOVAL OF BACK COVER BY UNAUTHORIZED PERSONNEL MAY EXPOSE THE USER TO DANGEROUS VOLTAGES OR OTHER HAZARDS. 7. Stop using the unit immediately and notify the service technician. A. If liquid has been spilled into the display or the display has been exposed to rain or water.
-
Page 5: Scope
This specification is used to define the performance of ATT043 TVI/AHD test monitor. ATT043 supports CVBS, AHD and TVI. For CVBS, both NTSC and PAL system can be auto detected. For AHD or TVI, both systems can support up to Full HD mode. - Page 6 Turn ON & OFF the monitor ON - Press the power button can turns monitor ON, the Power LED will indicates green light. If there is no available signal input, the screen will shows “No Signal” & blue background for 6 seconds then vanish and at the meantime Power LED indicates flashing light.
-
Page 7: Controls And Indicators
4. Controls and indicators Level Switch – ‘+’ ‘M’ ‘-‘ Press M to enter to monitor OSD control. Dial + or - to adjust the volume. Power Key and LED identification Press the power button to turn ON or turn OFF the monitor ... - Page 8 OSD Control Input Source Selection: ‘-’ Dial Level Switch button to select the input source of CVBS, AHD, TVI. Press Level Switch ‘M’ button to confirm the selection. OSD Selection: Press ‘M’ key to select BRIGHTNESS OSD and dial ‘-’ or ‘+’ to decrease or increase the value.
-
Page 9: Regulatory Agency
5. Regulatory Agency 5.1 Safety Approvals This series design shall meet the standards of the following domestic and foreign agencies: CE LVD : EN 60950-1 5.2 EMI/EMS Emission Approvals This series design shall meet following EMI/EMS specifications: FCC Compliance: FCC Rules and Regulations, Part 15, subpart B, Class A. CE COMPLIANCE: EN55022 class A, EN55024, EN50130-4 6. -
Page 10: Mechanical
7. Mechanical 7.1 Cabinet Material: Plastic Finish: Black. 7.2 Dimensions: 7.3 Weight Weight 0.33 0.73 N.W. 0.94 2.07 G.W. 7.4 Dimension (Packing ): Unit Inch 8.43 10.47 2.01... - Page 11 Atherton Electronics Corp. www.athertonelectronics.com © 2016 Atherton Electronics Corp. All rights reserved.
