Atherton ADE-110W1 User Manual

Cctv led monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

USER'S
MANUAL
CCTV LED MONITOR
MODEL: ADE-110W1
© 2016 Atherton Electronics Corp. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADE-110W1 and is the answer not in the manual?

Questions and answers

Related Manuals for Atherton ADE-110W1

Summary of Contents for Atherton ADE-110W1

  • Page 1 USER’S MANUAL CCTV LED MONITOR MODEL: ADE-110W1 © 2016 Atherton Electronics Corp. All rights reserved.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS  FCC information ------------------------------------------------------------------- 3  CE information --------------------------------------------------------------------- 3  Safety Precautions ---------------------------------------------------------------- 3 Scope ----------------------------------------------------------------------------------- 5 Functional specification ---------------------------------------------------------- 5 Controls and indicators ----------------------------------------------------------- 7 OSD Menu ------------------------------------------------------------------------------ 8 Regulatory Agency ----------------------------------------------------------------- 19 Mechanical ---------------------------------------------------------------------------- 19...

  • Page 3: Fcc Information

    FCC INFORMATION This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 4 8. Route power cords so that they cannot be walked upon or tripped over. Do not allow anything to rest on the power cord. 9. Do not install monitor in wet areas, or where it may be exposed to rain or water. Do not spill liquid of any kind on the unit.

  • Page 5: Scope

    1. Scope This specification is used to define the performance of ADE-110W1 series color LED monitor. This system also supports both video input and PC input. In video input mode, the system can automatically detect the NTSC signal and PAL signal. In PC mode, this system can support up to1280 x 800 VESA standard.
  • Page 6  Humidity Operating: 10% to 85% (non-condensing) Storage: 10% to 95% (non-condensing) 2.6 EDID This series of displays support EDID, but does not support DDC2B. 2.7 Connectors A. DC INPUT: DC JACK: DC12V IN, 5.5Ø / 2.5Ø B. CVBS OUTPUT: BNC Connector C.

  • Page 7: Controls And Indicators

    3. Controls and indicators A. “ ”Source button  Press the button to show source menu. Select CVBS, VGA or HDMI input channel B. “ ”Down button  Press the button to scrolling the cursor to desired function.  Press the button to decrease the value of selected function in sub OSD menu. C.

  • Page 8: Osd Menu

    4. OSD Menu Hot key ： Quick adjust keys from front panel hot keys： VOLUME： Press button to select the function and press buttons to adjust volume, then press MENU button to exit OSD menu KEY LOCK：Press and hold MENU key for 6 seconds to enable this function KEY UN-LOCK：Press and hold MENU key for 6 seconds to disable this function RUNNING HOURS：...

  • Page 9: Video Mode

    Video mode ： Press MENU button to bring up the MAIN MENU Page. The following page will appear. Press Down / Up buttons to select an icon, then Press MENU button to enter the sub menu. MAIN ADJUST： 1. Press Down / Up buttons to select an icon 2.
  • Page 10 CONTRAST：Adjust the contrast value SHARPNESS：Adjust Image sharpness SATURATION：Adjust Image saturation TINT：adjust Image tint (NTSC only) BACKLIGHT：Adjust the backlight value VOLUME：Adjust the volume EXIT：Press MENU button to return to the MAIN MENU COLOR ADJUST： Set the color temperature of monitor for the CIE coordinate 9300˚k or 6500˚k or USER MODE.
  • Page 11 SCAN SETTING： 1. Press Down / Up buttons to scroll the curser to SCAN SETTING 2. Press MENU button to enable setting 3. Press Down / Up buttons to set Scan Setting state INFORMATION： Press MENU button to get the input timing information LANGUAGE：Press MENU button to enter the sub menu 1.
  • Page 12 SETUP MENU： 1. Press Down / Up buttons to select an icon 2. Press MENU button to confirm 3. Press Down / Up buttons to adjust value or change status OSD TIMEOUT：Adjust the OSD Show time (5 ~120 sec) GREEN MODE：Off or On (5 min~10 min) OFF –...
  • Page 13 VGA & HDMI mode ： Press MENU button to bring up the MAIN MENU Page. The following page will appear. Press Down / Up buttons to select an icon, then press MENU button to enter the sub menu. VGA MAIN MENU HDMI MAIN MENU...
  • Page 14 MAIN ADJUST： 1. Press Down / Up buttons to select an icon 2. Press MENU button to select item 3. Press Down / Up buttons to adjust value VIVID MODE：Select the VIVID MODE (0~3 and USER) USER, 0: TEXT, 1: PHOTO, 2: MOVIE, 3: GAME BRIGHTNESS：Adjust the brightness value CONTRAST：Adjust the contrast value BACKLIGHT：Adjust the backlight value...
  • Page 15 COLOR ADJUST： Set the color temperature of monitor for the CIE coordinate 9300˚k or 6500˚k or USER MODE 1. Press Down / Up buttons to select an icon 2. Press MENU button to confirm 3. Press Down / Up buttons to adjust value USER COLOR：Adjust the color temperature RED：Adjust the RED value for user mode GREEN：Adjust the GREEN value for user mode...
  • Page 16 IMAGE ADJUST (VGA ONLY)： 1. Press Down / Up buttons to select an icon 2. Press MENU button to confirm 3. Press Down / Up buttons to adjust value AUTO ADJUST：Press MENU buttons to auto adjust the H. Position, V. Position, Phase, Clock H.
  • Page 17 LANGUAGE：Press MENU button to enter the sub-menu 1. Press Down / Up buttons to select language 2. Press MENU button to confirm SETUP MENU： 1. Press Down / Up buttons to select an icon 2. Press MENU button to confirm 3.
  • Page 18 AUTO SHIFT：Adjust AUTO SHIFT ON/OFF OFF – No Function ON – Every one hour there will one scan line from top to bottom ( Every 1 second down one scan line) to prevent panel image sticking AUTO SHIFT scan line EXIT：Press MENU button to return to the MAIN MENU RECALL：Brightness, Contrast, Volume, Vivid Mode, OSD Timeout, Green Mode, Auto Shift return to default Value...

  • Page 19: Regulatory Agency

    5. Regulatory Agency 5.1 Safety Approvals This series design shall meet the standards of the following domestic and foreign agencies: CE LVD : EN60950 5.2 EMI/EMS Emission Approvals. This series design shall meet following EMI/EMS specifications: FCC Compliance: FCC Rules and Regulations, Part 15, subpart B, Class B. CE COMPLIANCE: EN55022 class B, EN55024, EN50130-4.
  • Page 20 Atherton Electronics Corp. www.athertonelectronics.com © 2016 Atherton Electronics Corp. All rights reserved.
