- Page 1 703749 SOFA TABLE ASSEMBLY INSTRUCTION COASTER FINE FURNITURE 703747 703749 703748 coastercompany.com WWW. Page 1 OF 4 2014-07-11...
- Page 2 ITEM: 703749 ASSEMBLY INSTRUCTION Assembly lnstruction ASSEMBLY TIPS: 1.Remove hardware from box and sort by size. 2.please check to see that all hardware and parts are present prior to start of assembly. 3.please follow attached instructions in the same sequence as numbered to assure fast &...
- Page 3 ITEM: 703749 ASSEMBLY INSTRUCTION Assembly lnstruction It needs two persons and takes about thirty minutes to assemble the item. STEP 1 Insert the WOODEN DOWEL and BOLT on the STRETCHER on then insert the HALF ROUND NUT and HEXAGON NUT in CROSS BAR. Use SPANNER to fit tight.
- Page 4 ITEM: 703749 ASSEMBLY INSTRUCTION Assembly lnstruction STEP 3 Attach the side stretchers and stretcher bar to the assembled piece from step 2, using flat washer, lock washer and bolt with allen wrench. Place the top panel upside down on a soft surface, then attach the assembled base using flat washer, lock washer and bolt with allen wrench.
