MANUAL RGB STICKS
LED-Sticks #57006
ENGLISH

Advertisement

loading
Need help?

Need help?

Do you have a question about the 57006 and is the answer not in the manual?

Questions and answers

Summary of Contents for Muller licht 57006

  • Page 1 MANUAL RGB STICKS LED-Sticks #57006 ENGLISH...
  • Page 2: Installation

    MANUAL RGB STICKS Implied warranty Our product is manufactured under strict quality inspections. We deliver our products with implied warranty of two years. If you should have any cause for complains, please contact your local dealer from which you bought the product. He will handle the replacement, where applicable. The implied warranty will be affected by improper or incorrect usage of our product. Installation For technical support you can contact us directly: MÜLLER-LICHT International GmbH Goebelstr. 61/63 D-28865 Lilienthal Tel. +49 (0) 4298-93700 service@mueller-licht.de english...
  • Page 3 MANUAL RGB STICKS Security advice Please read this manual completely and store it safely. By passing the product to another person, please add this manual. Usage • Not suitable for household room illumination. Only for decorative usage. • The LED-sticks are intended to use in homes • The LED-sticks are intended for mounting on wall and roof • The LED-sticks are intended for use only on normal flammable environment • The LED-sticks are protected against penetration of solid matter, IP20 Security • The LED-sticks are only allowed to be powered by driver of the original accessory. • Do not use the LED-sticks or cables, if damaged • Please protect the cable in use against damage, if placed on the floor • Please connect the line adapter only to approved power sockets (220-240 V · 50/60 Hz) • Please disconnect the line adapter from the power socket before cleaning or mounting of the LED-sticks english...
  • Page 4 MANUAL RGB STICKS Security advice Application • Do not look from close distance into the operating LED • Do not look into the operating LED by a magnifier • Do not use the LED-sticks inside the color box • Do not use the LED-sticks covered • Do not connect the LED-sticks to other sticks or electric devices Battery • Do never charge the battery! Risk of explosion! • Protect children from the battery • Do not throw the battery into fire or dismantle it • Please remove an empty battery from the compartment • Do not expose the battery to extreme conditions (e.g. heater, fire) • Avoid contact to skin, eyes or mucosa with battery acid • In case of contact to battery acid, please clean the affected areas with pure water and contact immediately a doctor • Please replace the battery only with same or equivalent type • Please contact immediately a doctor in case of a swallowed battery • In longer times of non-use please remove the battery from the compartment english...
  • Page 5 MANUAL RGB STICKS Scope of delivery 4x connectors 10 cm 8x connector bridges 4x end cap Mounting material Line adapter with cable 4x LED-stick Remote control with battery (1x CR2025 · 3 V) Repeater with IR-receiver english...
  • Page 6 MANUAL RGB STICKS Mounting 1. Estimate the position of holding clips or glue ares Assembly the sticks with the connectors and check the position of the holding clips or place the glue pads on the sticks 3. Push the sticks into the holding clips or glue the sticks on the desired place 5. Put the end cap on the last stick 6. Connect the first stick with the line adapter 7. Connect the line adapter to the power socket 8. Remove the contact protection in the battery compartment 9. Start the LED strip by using the remote control Advice : Receiver for the infrared-signals of the remote is the repeater. The remote control need a direct and barrier-free connection to the repeater. Max. distance 5-7 m. Battery replacement P lease open the battery compartment on the side of the remote c ontrol by pushing the clamping pin by simultaneously e xtracting the compartment.
  • Page 7: Technical Details

    MANUAL RGB STICKS Technical details Model 57006 15 W · 12 V DC · 1 A · RGB Protection class II · IP20 Line adapter: XY-1201000-E 100-240 V · 1,5 A · 50/60 Hz Out: 12 V · 1 A Power: 15 W...
  • Page 8 MANUAL RGB STICKS 16 Level Brightness Power (ON/OFF) Adjusting* White 15 Kinds Of Existing Colors 7 color FLASH jumpy change All fade out STROBE & fade in 7 color FADE fade change 3 base SMOOTH color jumpy * When switching to dynamic mode the Brightness-button means the speed of light changes in 32 steps Recycle LED-devices are not allowed to be placed in household garbage. Please recycle it. Please contact your local recycling agency for details.
  • Page 9 MANUAL RGB STICKS MÜLLER-LICHT International GmbH Goebelstr. 61/63 D-28865 Lilienthal Tel. +49 (0) 4298-93700 service@mueller-licht.de Nachdruck, auch auszugsweise, nur mit schriftlicher Genehmigung des Urhebers • Irrtum und Änderung vorbehalten Full or partial reproduction subject to prior written approval • Errors and changes are excepted 57006_LED-Sticks_RGB_MANUAL_002.pdf...
