N02118905 Rev. A
3
Unit overview
3.1
The Box cassette fan coil unit is designed for room air conditioning. The unit is
available in two sizes, Box Mono and Box Double. The unit is also available with
two automation options, Vari and Vari Pro.
Figure 1: Overview of the units
1. Coil and fan (inside unit)
2. Water connections
3. External drain pan
4. Electrical box
5. Grille
6. Attachment brackets
Copyright © 2020. All rights reserved.
BOX Vari & Vari Pro – Installation, Operation, and Maintenance Manual
Introduction of the unit
1
2
4
6
3
4
5
8 (41)
