Assembly Instructions
LFT7000
wheeled stand
Thank you for purchasing AVFI's LFT7000 mobile Stand.
This stand is designed for TV setups totaling up to 280lbs.
Confirm all hardware is included before you begin assembly.
Read these instructions start to finish before beginning installation.
Note: If you cannot understand these instructions or are concerned about safety
of the installation contact a qualified contractor or contact AVFI at 1-877-834-3876.
Supplied Parts
Tower
Left and Right Bases
Box 1
Box 2
TV Brackets
TV Hardware bag
x2 if dual mount
S (shown)/XL/D
Box 3+ Tube
Not all hardware supplied will be used.
Supplied Hardware (additional to hardware bags)
Tools required
M8 X 40
M8 Nut
Allen Keys found
Keys
1/2 X 1
Wrench or Socket set
(6)
In hardware bag
(4)
(6)
(2)
1
www.video-furn.com
190 Don Hillock Drive |Aurora |Ontario|L4G 0G9 | 1.877.834.3876
