Instructions Update/Addendum
I
Note: PM2 mounts hole pattern.
Note:
If your cart or credenza has precut holes to support
this PM2-mount:
You may have both old and new hole patterns precut
into your furniture as we transition from first to
second generation.
These are designed to work with either generation
mounts and will not affect the strength or appearance
of the mount or furniture.
1
www.video-furn.com
288 Don Hillock Drive |Aurora |Ontario|L4G 0G9 | 1.877.834.3876
Advertisement
Related Manuals for Audio Visual Furniture PM2-S
Summary of Contents for Audio Visual Furniture PM2-S
- Page 1 Instructions Update/Addendum Note: PM2 mounts hole pattern. Note: If your cart or credenza has precut holes to support this PM2-mount: You may have both old and new hole patterns precut into your furniture as we transition from first to second generation. These are designed to work with either generation mounts and will not affect the strength or appearance of the mount or furniture.
- Page 2 Assembly Instructions PM2-S/D/XL/CS Mounts Thank you for purchasing AVFI’s PM2-series mount. This product is designed for mounting to a table, cart or credenza at approx. 30” height. Read these instructions start to finish before beginning installation. Note: If you cannot understand these instructions or are concerned about safety of the installation contact a qualified...
- Page 3 Assembly Instructions PM2-S/D/XL/CS Mounts Check furniture from underside to see if partial cuts are there. (Partial cut is routing 3/4 way thru bottom side) If so. Use existing cuts as guide , finish cuts all the way through to top.
- Page 4 Assembly Instructions PM2-S/D/XL/CS Mounts TV 52-70 6.Attach TV brackets to TV HW Bag using provided hardware. Do not overtighten. Max TV Weight 200 lbs. (100 lbs each on Dual) Phillips Screwdriver M8 X 20 Single Setup 10-32 Camera M8 Hex key bag (1) 7.With assistance,...
- Page 5 Assembly Instructions PM2-S/D/XL/CS Mounts 9. Adjust Camera neck to rest on top of TV bezel and attach using M6 bolts M6 Hex key and Hex key. For Camera below TV The main spine section Needs to be turned around in step 2.
