1.

Introduction

DEAR CUSTOMER,
we hope your new tool brings you much enjoyment and suc- cess.
NOTE:
According to the applicable product liability laws, the manu- facturer of the device does not assume
liability for damages to the product or damages caused by the product that occurs due to:
● Improper handling,
● Non-compliance of the operating instructions,
● Repairs by third parties, not by authorized service techni- cians,
● Installation and replacement of non-original spare parts,
● Application other than specified,
● A breakdown of the electrical system that occurs due to the non-compliance of the electric regula-
tions and VDE regula- tions 0100, DIN 57113 / VDE0113.
We recommend:
Read through the complete text in the operating instructions before installing and commissioning the
device.
The operating instructions are intended to help the user to become familiar with the machine and take
advantage of its application possibilities in accordance with the recommenda- tions.
The operating instructions contain important information on how to operate the machine safely, profes-
sionally and economically, how to avoid danger, costly repairs, reduce
downtimes and how to increase reliability and service life of the machine.
In addition to the safety regulations in the operating instruc- tions, you have to meet the applicable
regulations that apply for the operation of the machine in your country.
Keep the operating instructions package with the machine at all times and store it in a plastic cover to
protect it from dirt and moisture. Read the instruction manual each time before operating the machine
and carefully follow its information. The machine can only be operated by persons who were instructed
concerning the operation of the machine and who are informed about the associated dangers. The
minimum age requirement must be complied with.
In addition to the safety instructions contained in this operat- ing manual and the specific regulations of
your country,
the technical rules generally accepted for the operation of machines of the same type must be observed.
We accept no liability for damage or accidents which arise due to non-observance of these instructions
and the safety information.
2.

Device description (fig. 1-21)

1. Handle
2. ON/OFF switch
3. Lock switch
4. Machine head
5. Moving saw blade guard
6. Saw blade
7. Clamping device
8. Workpiece support
9. Set screw for workpiece support
10. Table insert
11. Locking handle
12. Pointer
13. Scale
14. Rotary table
15. Fixed saw table
16. Stop rail
16a. Movable stop rail 16b. Set screw
17. Chip collection bag
18. Scale
19. Pointer
20. Set screw for drag guide
21. Drag guide
22. Set screw
23. Locking bolt
24. Screw for cutting depth limiting
25. Stop for cutting depth limiting
26. Adjusting screw (90°)
27. Adjusting screw (45°)
28. Flange screw
