Summary of Contents for Mettler Electronics Auto Therm 395
- Page 1 Auto Therm ® Instruction Manual...
- Page 2 Mettler Electronics Corp. FCC Frequency Interference Statement Warning: This equipment generates and uses radio frequency energy, and if not installed and operated in strict accordance with the manufacturer’s instructions, may cause radio frequency interference. Notice 1: This equipment has been verified to comply with the specifications in Part 18 of FCC Rules, which are designed to provide reasonable protection against radio frequency interference.
-
Page 3: Table Of Contents
Auto * Therm 395, Shortwave Diathermy TABLE OF CONTENTS Introduction ® Introduction to the Auto * Therm Introduction to this manual Safety precautions Caution Shipping damage Package contents Limited Warranty Symbol Glossary and List of Abbreviations Operational controls, displays, receptacles and symbols General information Shortwave diathermy applications Unit description... - Page 4 Capacitive method of application Inductive method of application Applicator loading What to do when problems occur Summary of operations Specifications Accessories...
-
Page 5: Introduction
In addition, the Auto * Therm 395 meets the following standards for radio frequency emissions: • FCC Part 15–B • EN60601-1-2:1993 • EN–55011 (CISPR–11) Mettler Electronics Corp. has been certified by TÜV Rheinland of North America to be compliant with EN ISO 13485:2003 and ISO 13485:2003. -
Page 6: Introduction To This Manual
(714) 533–2221) NOTE: All warranty repairs must be performed by Mettler Electronics Corp. or by a service facility authorized by Mettler Electronics to perform warranty repair work. A service manual for the Auto * Therm 395 is available from Mettler Electronics Corp. for a nominal charge. Caution Federal law restricts the sale of this device to, or on the order of a physician, dentist, veterinarian or any other practitioner licensed by law of the state in which he practices. -
Page 7: Limited Warranty
The Auto * Therm 395 shortwave diathermy unit and its accessories are warranted against defects in materials and workmanship for a period of one year from date of purchase. During the applicable warranty period Mettler Electronics Corp. will, at its discretion, either repair or replace the Product without charge for these types of defects. -
Page 9: Symbol Glossary And List Of Abbreviations
Auto * Therm 395, Shortwave Diathermy Symbol Glossary and List of Abbreviations Operational controls, displays, receptacles and symbols 1 4 1 6 MINUTES WATTS Auto T herm 39 5 ® RESET MODE APPLICATOR TIME TUNING / INTENSITY 11 10 9 Auto * Therm 395 membrane panel controls Auto * Therm 395 applicator arm assembly... - Page 10 Auto * Therm 395—controls and receptacles located on the back of the unit Power switch with indicator light RESET Selector Continuous mode selector Pulsed mode, 70 Hz / 2 ms selector Pulsed mode, 350 Hz / 0.4 ms selector 8 cm diameter inductive coil applicator selector 14 cm diameter inductive coil applicator selector 15 cm x 35 cm (Triplode) inductive coil applicator selector 4.2 cm diameter condenser applicator and 8 x 14 cm flexible condenser...
- Page 11 Auto * Therm 395, Shortwave Diathermy (14) Treatment time display in minutes (15) Intensity display (16) Patient coupling display bar graph (17) Intensity control knob (18) Slide for attaching the applicators (19) Applicator holder (20) Hinge (21; 23) Lock knobs for arm hinges (24) Lower part of arm (25)
-
Page 13: General Information
Auto * Therm 395, Shortwave Diathermy General information Shortwave diathermy applications ® The Auto * Therm 395 is a shortwave diathermy device that operates at 27.12 MHz. It provides traditional shortwave diathermy therapy using condenser and electromagnetic inductive coil fields in both continuous and pulsed modes of operation. -
Page 14: Applicators And Applicator Cables
When using an inductive coil applicator with a fixed connection cable, feed the cable through the aperture first before attaching the applicator. Remove the applicator by pushing back the slide (18) and pulling the applicator out of the hoIder. The central joint of the arm (23) is factory-adjusted to a basic braking force. -
Page 15: Cleaning And Disinfecting
Auto * Therm 395, Shortwave Diathermy Cleaning and disinfecting Turn off the unit and unplug it from the mains power supply before cleaning or disinfecting it. Clean and disinfect the unit and its accessories (except for the felt spacers) with commerciaIly available surface disinfectants. -
Page 17: Indications, Contraindications And Precautions For Shortwave Diathermy
Auto * Therm 395, Shortwave Diathermy Indications, Contraindications and Precautions for Shortwave Diathermy Indications Shortwave diathermy delivers energy in the radio band of 27.12 MHz to provide deep heating therapeutic effects to body tissues. When shortwave diathermy is delivered to the body at intensities capable of generating a deep tissue temperature increase, it can be used to treat selected medical conditions such as: 1. - Page 18 2. Any bleeding tendency is increased by heating because of the increase in blood flow and vascularity of the heated tissues. Care, therefore, should be used in treating patients with therapeutic shortwave diathermy who have bleeding disorders. 3. Heating of the joint capsule in acute or subacute arthritis should be avoided. 4.
-
Page 19: Installation & Operation
Auto * Therm 395, Shortwave Diathermy Installation & Operation ATTENTION: The Auto * Therm 395 is not designed to be operated in environments where there is a danger of explosion. Do not use in surgical rooms, where inflammable anesthesia may be used. Mains connection The standard Auto * Therm 395 must be connected to a mains power of 115 V ±... -
Page 20: Connecting Applicators
3959 4.2 cm diameter condenser applicators or flexible 8 x14 cm condenser applicators 3962 3960 8.5 cm diameter condenser applicators or flexible 12 x 18 cm condenser applicators 3963 3961 13 cm diameter condenser applicators As mentioned above, any programming is possible only when the intensity display (15) shows “000”. Connecting the applicators The applicators are electrically connected to receptacles (30) or (31). -
Page 21: Emergency Shut Off
Auto * Therm 395, Shortwave Diathermy the device prior to attempting to adjust the treatment intensity so that the Auto * Therm can properly tune to the patient’s body. The intensity control knob (17) can be turned continuously. It has no stops to prevent clockwise or counterclockwise rotation. -
Page 22: Safety Circuit Shut Off
Safety circuit shut off The micorprocessor automatically monitors the circuitry to help ensure the safety of the patient and the Auto * Therm 395. When errors are detected, the output is shut off and an error code is displayed in the intensity display (15). -
Page 23: Treatment
Auto * Therm 395, Shortwave Diathermy Treatment Preparing the patient For optimum therapy, ensure that the patient is in a comfortable and relaxed position. To accomplish this either have the patient in a seated or supine position. Patients shall never be treated on metal chairs, tables or beds. For safety reasons, remove all hearing aids, watches, rings, chains, bracelets and other metal objects before starting the treatment. -
Page 24: Applicator Loading
the treated area. The intensity and treatment time values given in the application table should be observed. For maximum deep effects apply the inductive coil applicator directly to the body through a single layer of towelling. Watch the patient-coupling indicator (16), to ensure maximum patient coupling. Pay particular attention when applying the Triplode. - Page 25 Auto * Therm 395, Shortwave Diathermy 13 cm diameter condenser applicator 11— When different condenser applicators are combined, the smallest type of applicator determines the maximum intensity. Deviations are possible depending on the heating felt by the patient.
-
Page 26: What To Do When Problems Occur
What to do when problems occur We have found that most problems occur because of inadvertent operating errors. Therefore, when the Auto * Therm 395 displays an error code, please check whether the operating instructions have been correctly followed (sections 5 and 6). If displays (14) and (15) and the light in the power switch (1) do not light when the unit is turned on, check whether the unit is correctly connected to an active wall outlet and the power cord is connected to the unit. -
Page 27: Summary Of Operations
Auto * Therm 395, Shortwave Diathermy Summary of operations See section • Connect the appliance to the power outlet. • Connect the applicator(s) to the device. • Attach the applicator(s) to the patient. • Turn on the unit using the power switch (1). •... -
Page 28: Specifications
Specifications Mains voltage, standard 115 VAC ± 10 %; 50/60 Hz Optional 230 VAC ± 10 %; 50/60 Hz Electric fuses (external) 16 A, slow acting for 115 VAC 10 A, slow acting for 230 VAC Mains fuses for the appliance circuit, 2 x FST 7 AS for 115 VAC (6.3 x 32) externally accessible 2 x FST 6.3 AF for 230 VAC (5 x 20) -
Page 29: Accessories
Auto * Therm 395, Shortwave Diathermy Accessories Part # Description 3951 Inductive coil set * 1 four-joint arm 1 — 14 cm diameter inductive coil applicator 1 special field inductive coil cable 3952 Condenser field set * 2 four-joint arms 2 —...
