Summary of Contents for Mettler Electronics Sonicator 719
- Page 1 Palm-sized Ultrasound Sonicator® 718 & 719 Instruction Manual To ensure correct use, please read this manual carefully before operating the unit. After reading, store the manual in a safe place for future reference.
-
Page 3: Table Of Contents
Sonicator 718 & 719 Palm-sized Ultrasound Contents Symbols ������������������������ 2 To Ensure Correct and Safe Use �������������� 3 Intended Use ��������������������� 3 Contraindications ������������������� 3 Precautions ���������������������� 3 Precautions on Use ������������������ 4 Storage and Period of service �������������� 6 Precautions on Handling ����������������... -
Page 4: Symbols
Please retain all shipping materials in the event that you will need to return your unit for servicing. NOTE: All warranty repairs are to be performed by Mettler Electronics Corp. or an authorized Mettler Electronics warranty repair center. -
Page 5: To Ensure Correct And Safe Use
Sonicator 718 & 719 Palm-sized Ultrasound To Ensure Correct and Safe Use RX Only—This unit should be used by a licensed medical practitioner. Intended Use Indications for therapeutic ultrasound can be achieved through thermal effects. 1) Relief of pain 2) Reduction of muscle spasms 3) Localized increase in blood flow 4) Decrease of joint contractures Contraindications... -
Page 6: Precautions On Use
Sonicator 718 & 719 Palm-sized Ultrasound To Ensure Correct and Safe Use 5) Over healing fracture Therapeutic ultrasound may delay or prevent callous formation in a healing fracture 6) Spinal cord after laminectomy 7) Superficial peripheral nerves 8) Burns may occur in following application of therapeutic ultrasound ①... - Page 7 ８) Never touch the parts of the device other than the Main Unit, such as the Intermediate box, with wet hands. ９) Avoid operating Sonicator 718 or Sonicator 719 adjacent to and simultaneously with any shortwave or microwave devices. 4. Precautions after use 1) Turn off power, and disconnect the power cable from the outlet according to the steps specified.
-
Page 8: Storage And Period Of Service
Sonicator 718 & 719 Palm-sized Ultrasound To Ensure Correct and Safe Use is off and grasp the adaptor by the plug. Avoid pulling with excessive force when disconnecting cables. 3) Rinse the ultrasound head with lukewarm water lightly and thoroughly wipe dry. Take adequate measures to ensure it remains clean in storage. -
Page 9: Maintenance And Checkup
Sonicator 718 & 719 Palm-sized Ultrasound Maintenance and Checkup 1. Precautions 1) In the event of a malfunction, do not attempt to repair the device yourself. Attach an out-of-order notice to the device and contact the dealer, manufacturer or distributor to obtain repair services. - Page 10 The following accessories for Sonicator 718 and Sonicator 719 are replaceable. Call Mettler Electronics Corp. at 800-854-9305 to place an order. 7181 AC Adaptor (100–240 V)
-
Page 11: Battery
Sonicator 718 & 719 Palm-sized Ultrasound Battery Do not charge the battery in the following locations: 1) Ambient temperature is below 0°C or exceed 40°C. (If ambient temperature is too high or too low, the battery may not charge.) 2) The location is humid, dusty, or subject to vibrations. (The battery may not charge properly.) Be sure to use the specified battery. -
Page 12: Device Configuration
Main Unit and Standard Accessories Main Unit Sonicator 718 Sonicator 719 order # ❶7180 Protective Cap for Sonicator 718 Probe ❹ ❷7190 Protective Cap for Sonicator 719 Probe ❶ ❸1844 Sonigel tube ❹7181 AC Adaptor (100–240 V) 7183 Power Cable for AC Adaptor ❷... -
Page 13: Specifications
Sonicator 718 & 719 Palm-sized Ultrasound Specifications Sonicator 718 Sonicator 719 Power supply AC 100-240 V 50/60 Hz or Rechargeable Battery (optional) Power consumption 50 VA 17 VA Ultrasound frequency 1.0 MHz ± 10% 3.0 MHz ± 10% Intensity (max) 2.00 W/㎠... -
Page 14: Names Of Component Parts
Sonicator 718 & 719 Palm-sized Ultrasound Names of Component Parts ［Front］ ［Side］ ① ⑩ ② ③ ⑤ ⑪ ④ ⑥ ⑨ ⑦ ⑧ * The device in this image is Sonicator 718. ① Output LED ⑦ POWER switch ② Display ⑧... -
Page 15: Preparations Before Use
Sonicator 718 & 719 Palm-sized Ultrasound Preparations before Use 〈Using AC Adaptor〉 Connect the Power Cable for AC Adaptor to the AC Adaptor. Connect the plug for the AC Adaptor to the intermediate box. Connect the plug of the Power Cable for AC Adaptor to the outlet. - Page 16 Sonicator 718 & 719 Palm-sized Ultrasound Preparations before Use 〈Battery-powered〉 * Optional Accessaries Fit the battery into the Battery Charger. Battery Align the parts of the battery and the charger encircled by a dotted line, snap together, and slide the battery in the direction indicated arrow.
- Page 17 Sonicator 718 & 719 Palm-sized Ultrasound The red lamp of the charger will light. This lamp goes out when charging is complete. ［Red lamp ON］ ［Red lamp OFF］ Remove the battery from the charger and fit the battery into the Battery Case. Battery Align parts battery and the Battery Case...
-
Page 18: Operating Procedures
Sonicator 718 & 719 Palm-sized Ultrasound Operating Procedures Press and hold the POWER switch for approximately one second to turn on power for the device. ［Initial check screen］ After the initial check is completed, the therapy screen will appear. Initial Check ver 1.0-1.0 ... - Page 19 Sonicator 718 & 719 Palm-sized Ultrasound To change the settings on the t h e r a p y s c r e e n , p r e s s t h e SELECT switch on the therapy screen while output is off. Program ❶...
- Page 20 The level is set within the ranges above in an increment of 0.05 W/㎠ when the output unit is set to W/㎠. * Note that setting details will differ between Sonicator 718 and Sonicator 719 if the output unit is set to W.
- Page 21 Sonicator 718 & 719 Palm-sized Ultrasound Apply the Ultrasound Gel to the ultrasound head. Press the START/STOP switch to initiate output. While ultrasound is being output, as long as the ultrasound head is in proper contact with the body, an audible therapy signal will be emitted and the output LED will remain on.
- Page 22 Sonicator 718 & 719 Palm-sized Ultrasound Operating Procedures When the timer reaches “0:00,” the buzzer will sound and the display screen and output LED will start blinking to indicate that therapy is complete. Press and hold the POWER switch (approximately one second) to turn off power.
-
Page 23: Storage
［Sonicator 718］ ［Sonicator 719］ * Wipe all Ultrasound Gel from the ultrasound head. * The Sonicator 718 and Sonicator 719 use different caps. 〈Unit Stand〉 *Optional Accessories Place the device on the stand to store in a stable position. -
Page 24: Configuration Setting
Sonicator 718 & 719 Palm-sized Ultrasound Configuration Setting Press and hold the SELECT switch (approximately one second) on the therapy screen while output is off. The Config. screen appears. Config. ❶ Contrast ［Contrast setting screen］ Use the UP and DOWN switches to set the display screen contrast. - Page 25 Sonicator 718 & 719 Palm-sized Ultrasound Press the SELECT switch. Config. ❸ ［Therapy sound setting screen］ Contact Tone Use the UP and DOWN switches to turn the audible therapy signal on or off. ON ◀▶ OFF Press the SELECT switch. Config. ❹...
-
Page 26: Error Screen
Sonicator 718 & 719 Palm-sized Ultrasound Error Screen Error If the screen displays the “Error” message, power for the device will be automatically shut down in approximately 10 seconds. Press and hold the POWER switch (approximately one second) to turn power on once again. -
Page 27: Emc
The Sonicator 718 and Sonicator 719 are intended for use in the electromagnetic environment specified below. The customer or the user of the Sonicator 718 / Sonicator 719 should assure that it is used in such an environment. Emissions test Compliance Electromagnetic environment —... - Page 28 Guidance and manufacturer’s declaration — electromagnetic immunity The Sonicator 718 and Sonicator 719 are intended for use in the electromagnetic environment specified below. The customer or the user of the Sonicator 718 / Sonicator 719 should assure that it is used in such an environment.
- Page 29 If the measured field strength in the location in which the Sonicator 718 / Sonicator 719 should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as reorienting or relocating the Sonicator 718 / Sonicator 719.
- Page 30 Recommended separation distances between portable and mobile RF communications equipment and this unit The Sonicator 718 and Sonicator 719 are intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the Sonicator 718 /...
- Page 32 1333 South Claudina Street Anaheim, CA 92805 U.S.A. Toll Free: 800-854-9305 TEL: 1-714-533-2221 FAX: 1-714-635-7539 URL: http://www.mettlerelectronics.com E-Mail: mail@mettlerelectronics.com IR8-36 Rev.B_06/26/12...
