May Wes QD2 Assembly Instructions

2.7
2.1
2.8
2.9
2.12
2.5
Notes:
43016 - 14" Stalk Stomper Shoe Assy
1
41748 - 14" Stalk Stomper Shoe W/Poly
2
3 Install Self-Tapping Grease Fitting into end of Pivot Bolt
Torque grease fitting to 65-70 inch pounds. DO NOT OVERTIGHTEN!
PAGE 1 OF 5
1.1
2.6
2.3
2.4
2.10
2.2
120 Eastgate Drive SE
PO Box 7
Hutchinson, MN 55350
QD2 TOOLBAR MOUNT STALK STOMPER
ASSEMBLY INSTRUCTIONS / PARTS LISTING
1.2
1.3
ITEM # PART #
1.4
1 43001
2.11
1.1 43002
3
1.1.3 24022
1.2 00986
1.3 00255
1.4 00214
1
2 43003
2.1 43004
2
2.2 41825
2.3 01040
2.4 00691
2.5 00931
2.6 01001
2.7 00213
2.8 00249
2.9 00104
2.10 00209
2.11 01009
2.12 01046
1-800-788-6483
1-320-587-2322
1-320-587-6112 (Fax)
43000
QD2 TOOLBAR MOUNT
STALK STOMPER ASSEMBLY
DESCRIPTION
TOOLBAR MOUNT BRACKET ASSY
TOOLBAR MOUNT BRACKET
LOCK PLATE
U-BOLT 1/2"-13
WASHER, 1/2" SPRING LOCK
NUT, 1/2"-13 HEX
STALK STOMPER ASSY 9"
SHOE BRACKET ASSY
STALK STOMPER SHOE W/POLY 9"
SPRING
PIN, 1/4" X 3" COTTER
CHAIN
BOLT, CUSTOM (GREASEABLE)
NUT, 7/16"-14 HEX TOP LOCK
WASHER, 3/8" FLAT
BOLT, 3/8"-16 X 1" HEX
NUT, 3/8"-16 HEX
GREASE FITTING, 1/4"-28 STRAIGHT
CHAIN SLEEVE
WWW.MAYWES.COM
QTY
1
1
1
2
4
4
1
1
1
1
1
1
1
1
2
2
2
1
1
Doc #: 10213_B
