CASE IH 2200/2400/3200/3400 - NEW HOLLAND 96C/96D/98C/98D/996
G4 STALK STOMPER PARTS LISTING/ASSEMBLY INSTRUCTIONS
2.3
4
NOTES:
Item 4 is optional and not included in the kit, please order separately
1
ITEM #
2.1
2.2
2.3
2.4
PAGE 1 OF 2
2.1
PART #
1
01130
42295
22726
00729
BOLT, 1/2"-13 X 1-1/2" HEX FLANGE
00730
3
42353
4
22043
3
2.2
DESCRIPTION
PIN, 1/2" X 4" BENT HITCH
STALK STOMPER TORSION ASSY
SHOE, STALK STOMPER
NUT, 1/2"-13 HEX FLANGE
HEADER BRACKET
MOUNT BRACKET (OPTIONAL)
120 Eastgate Drive SE
Hutchinson, MN 55350
WWW.MAYWES.COM
2.4
QTY
1
1
1
4
4
1
1-800-788-6483
1-320-587-2322
1-320-587-6112 (Fax)
Doc #: 10286_A
1
Advertisement
Related Manuals for May Wes G4
Summary of Contents for May Wes G4
- Page 1 CASE IH 2200/2400/3200/3400 - NEW HOLLAND 96C/96D/98C/98D/996 G4 STALK STOMPER PARTS LISTING/ASSEMBLY INSTRUCTIONS NOTES: Item 4 is optional and not included in the kit, please order separately ITEM # PART # DESCRIPTION 01130 PIN, 1/2" X 4" BENT HITCH 42295...
- Page 2 CASE IH 2200/2400/3200/3400 - NEW HOLLAND 96C/96D/98C/98D/996 STALK STOMPER INSTALLATION Safety Procedure: - Park combine on level ground and engage the parking brake. - Raise the head and lock in the upright position. - Support all row units that stalk stompers will be installed on to ensure row units remain stationary during installation.
