May Wes QD2 Assembly And Installation

NOTES:
43016 - 14" Stalk Stomper Shoe Assy
1
41748 - 14" Stalk Stomper Shoe W/Poly
2
Install Self-Tapping Grease Fitting into end of Pivot Bolt
3
Torque grease fitting to 65-70 inch pounds. DO NOT OVERTIGHTEN!
ITEM # PART #
1 43010
2 43003
1
2.1 43004
2.2 41825 STALK STOMPER SHOE W/POLY 9"
2
2.3 01040
2.4 00691
2.5 00931
PAGE 1 OF 2
JOHN DEERE 90/40 SERIES
ALL ROWS EXCEPT ROW 6 ON 8 ROW HEAD
QD2 STALK STOMPER PARTS LISTING/ASSEMBLY INSTRUCTIONS
2.1
2.5
2.12
2.9
2.8
DESCRIPTION
QD2 HEADER BRACKET
STALK STOMPER ASSY 9"
SHOE BRACKET ASSY
SPRING
PIN, 1/4" X 3" COTTER
CHAIN
1
2.7
QTY ITEM # PART #
1 2.6 01001
1 2.7 00213
1 2.8 00249
1 2.9 00104
1 2.10 00209
1 2.11 01009
1 2.12 01046
120 Eastgate Drive SE
PO Box 7
Hutchinson, MN 55350
WWW.MAYWES.COM
2.11
2.3
2.2
2.4
2.10
DESCRIPTION
BOLT, CUSTOM (GREASEABLE)
NUT, 7/16"-14 HEX TOP LOCK
WASHER, 3/8" FLAT
BOLT, 3/8"-16 X 1" HEX
NUT, 3/8"-16 HEX
GREASE FITTING, 1/4"-28 STRAIGHT
CHAIN SLEEVE
1-800-788-6483
1-320-587-2322
1-320-587-6112 (Fax)
2.6
3
QTY
1
1
2
2
2
1
1
Doc #: 10197_A
