May Wes QD Assembly And Installation

NOTES:
Install Self-Tapping Grease Fitting into end of Pivot Bolt
1
Torque grease fitting to 65-70 inch pounds. DO NOT OVERTIGHTEN!
ITEM# PART#
1 41942 QD HEADER BRACKET - OFFSET RIGHT
2 41944 OFFSET RIGHT STALK STOMPER ASSY
2.1 41824
2.2 41858 OFFSET RIGHT STALK STOMPER
2.3 41746 PIN ASSY (WITH LYNCH PIN)
2.4 40649
2.5 00691
2.6 00931
2.7 00216
PAGE 1 OF 3
JOHN DEERE 90/40 SERIES
ROW 6 ON 8 ROW HEAD

STALK STOMPER PARTS LISTING/ASSEMBLY INSTRUCTIONS

1
2.7
2.1
2.10
2.6
2.8
2.2
DESCRIPTION
SHOE BRACKET
SPRING
PIN, 1/4" X 3" COTTER
CHAIN
NUT, 1/2"-13 TOP LOCK
4
5
2.9
QTY ITEM# PART#
1
2.8 00104
1
2.9 00208
1
2.10 00249
1
2.11 01001
1
2.12 01009
1
3 01003
1
4 00235
1
5 00195
1
6 22376
120 Eastgate Drive SE
PO Box 7
Hutchinson, MN 55350
WWW.MAYWES.COM
3
6
2.3
2.12
1
2.11
2.4
2.5
DESCRIPTION
BOLT, 3/8"-16 X 1" HEX
NUT, 5/16"-18 TOP LOCK
WASHER, 3/8" FLAT SAE
BOLT, CUSTOM (GREASEABLE)
GREASE FITTING, 1/4"-28 STRAIGHT
BOLT, 5/8"-11 X 6-1/2" HEX
WASHER, 5/8" SPRING LOCK
NUT, 5/8"-11 REGULAR
SHIELD PLATE
1-800-788-6483
1-320-587-2322
1-320-587-6112 (Fax)
QTY
2
2
2
1
1
1
3
3
1
Doc #: 10010_C
