IMPORTANT:
Always leave the thumb latch in the open position when storing unit.
6.3 INFLATING OTHER ARTICLES (WITHOUT VALVE STEM)
Inflation of other items requires use of one of the adapters (nozzles).
1. Open the hatch and remove the nozzles noting their storage positions.
2. Insert appropriate adapter (e.g. needle) into connector (chuck) and close
thumb latch.
3. Refer to Table III, Typical Inflation Times, for approximate filling pressure and
time. Small items such as volleyballs, footballs, etc. inflate very rapidly.
4. Insert adapter (e.g. needle) into item to inflate to appropriate pressure.
5. Turn ON compressor switch - inflate to desired pressure or fullness
6. Turn off compressor switch.
7. Remove adapter from the inflatiable item.
6.4

TYPICAL INFLATION TIMES

The following are approximate pressure and inflation times for various items.
WARNING:
Always follow tire manufacturers recommendations for pressure on item to
be inflated.
Table III
V
EHICLE AND TRAILER TIRES
155/80R 13"
185/70R 14"
235/75R 15"
235/85R 16"
B
ICYCLE TIRES
27" X 1" (racing)
Football
Basketball
Volleyball
7.

REPLACEMENT PARTS

For replacement parts (bulbs, batteries, fuses, etc.), contact Vector Customer Service:
(954) 584-4446 or toll-free (866) 584-5504.
Vec021APC manual 10/02
I (
NFLATION PRESSURE PSI
26
30
30
50
10
13
9
5
12
) F
ILLING TIME
2.5 min
4.5 min
6.5 min
16 min
40 sec.
24 sec.
20 sec.
6 sec
