VEC021/021AC
INDUSTRIAL SERIES
900
™
JUMPSTART SYSTEM & POWER SUPPLY
PORTABLE, CORDLESS, RECHARGEABLE 12-VOLT DC* POWER SUPPLY
COMPLETELY PORTABLE, SAFE & CONVENIENT
*INCLUDES INSTRUCTIONS FOR 110-VOLT AC POWER OPTION
(MODEL VEC023 INVERTER: INCLUDED WITH MODEL VEC021AC; NOT INCLUDED WITH MODEL VEC021)
THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY, OPERATION, MAINTENANCE AND STORAGE OF THIS
PRODUCT. BEFORE USE, READ AND UNDERSTAND ALL CAUTIONS, WARNINGS, INSTRUCTIONS AND PRODUCT LABELS, PLUS YOUR VEHICLE'S
BATTERY MANUFACTURER GUIDELINES. FAILURE TO DO SO COULD RESULT IN POSSIBLE INJURY OR PROPERTY DAMAGE.
OWNER'S MANUAL
4140 S.W. 28th WAY
FT. LAUDERDALE, FL 33312
Advertisement
Table of Contents
Related Manuals for Vector Industrial Series VEC021
Summary of Contents for Vector Industrial Series VEC021
- Page 1 VEC021/021AC INDUSTRIAL SERIES ™ JUMPSTART SYSTEM & POWER SUPPLY PORTABLE, CORDLESS, RECHARGEABLE 12-VOLT DC* POWER SUPPLY COMPLETELY PORTABLE, SAFE & CONVENIENT *INCLUDES INSTRUCTIONS FOR 110-VOLT AC POWER OPTION (MODEL VEC023 INVERTER: INCLUDED WITH MODEL VEC021AC; NOT INCLUDED WITH MODEL VEC021) THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY, OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT.
-
Page 2: Table Of Contents
Introduction ..............11 How the Vector™Power Force 150™ Inverter Works ....... 11 8.2.1 Principle of Operation . -
Page 3: First Aid
• THIS UNIT WILL NOT OPERATE APPLIANCES AND EQUIPMENT THAT PRODUCE HEAT, SUCH AS HAIR DRYERS, MICROWAVE OVENS, AND TOASTERS. BATTERY REPLACEMENT: IT IS RECOMMENDED TO RETURN UNIT TO VECTOR™ CUSTOMER SERVICE FOR BATTERY REPLACEMENT: CONTACT (954) 923-1155 BATTERY DISPOSAL: THIS UNIT CONTAINS A MAINTENANCE-FREE, SEALED, NON-SPILLABLE, LEAD ACID BATTERY WHICH MUST BE DISPOSED OF PROPERLY. - Page 4 - when jumpstarting assistance or permanent utility power sources are not available. It is also ideal for use with Vector™ 12-volt DC cordless, portable, rechargeable products. For easy reference, this manual includes all information and specifications pertaining to the following Vector™...
-
Page 5: Features
Figure 4. Figure 3. 1. INVERTER POWER INDICATOR 1. FIXED CLAMP COVER 2. INVERTER ON/OFF SWITCH 2. CLAMP HOLSTER SHOULDER 3. INVERTER OVERLOAD/LOW BATTERY INDICATOR SLIDE DOWN & ROTATE 4. STANDARD HOUSEHOLD-TYPE 110-VOLT AC CLAMP OUTWARD FROM POWER SOCKET BACK OF UNIT TO REMOVE 5. -
Page 6: Introduction
• When using this vehicle in proximity to the vehicle ‘s battery and engine, stand the unit on a flat, stable surface, and be sure to keep all cords and cables well away from any moving parts. • Check unit periodically for wear and tear. Replace worn or defective parts immediately - contact Vector™ Customer Service Department at (954) 923-1155. -
Page 7: Battery Replacement
• Eyes: If battery acid comes in contact with eyes, flush eyes immediately—for minimum of 15 minutes—SEEK IMMEDIATE MEDICAL ATTENTION. 2.2 BATTERY REPLACEMENT IT IS RECOMMENDED TO RETURN UNIT TO VECTOR™ CUSTOMER SERVICE FOR BATTERY REPLACEMENT: CONTACT (954) 923-1155 2.3 BATTERY DISPOSAL Contains a maintenance-free, sealed, non-spillable, lead acid battery which must be disposed of properly. -
Page 8: To Use The Industrial 900™ System
2. Make sure that the inverter ‘s power switch is in the OFF position before recharging or making any connection RECHARGING to power source or load. 3. Line up the body housing on the Vector™ 4...32 included with Model VEC021AC) with the mounting walls on the back of the INDUSTRIAL 900™. Slide the 5 ...40... -
Page 9: Specifications
900 Amps The Vector Power Force 150™ inverter is one in a series of the most advanced DC to AC inverters available today. 12-volt DC,17.5-Ampere-hours With proper care and appropriate usage, it will provide years of dependable service in your car, truck, RV, boat or even airplane. -
Page 10: How The Vector™Power Force 150™ Inverter Works
If the inverter is connected to the incorrect polarity, the fuse will be blown. If the unit does not function after replacement of the fuse, the unit must be returned to Vector for repair. Repair expenses for this type of damage are not covered by your warranty. -
Page 11: Placement Of The Power Force 150
8.3.5 Placement Of The Power Force 150™ For best operating results, the inverter should be properly installed (as directed in this manual) in the INDUSTRIAL 900™. The combined unit should only be used in locations that meet the following criteria: DRY—Do not allow water or other liquids to come into contact with unit. -
Page 12: Troubleshooting Guide
2. Do not use inverter with inexpensive audio systems. ™ VECTOR Power Force 150 POWER INVERTER PRODUCT SPECIFICATIONS MAXIMUM CONTINUOUS POWER ..... 150 WATTS SURGE CAPACITY (PEAK POWER) . - Page 13 1 YEAR LIMITED WARRANTY REGISTRATION FORM This Vector Manufacturing, Ltd. product is warranted to the original purchaser only, for one year from the date of purchase, to be free of defects in materials and workmanship. In no event will Vector Manufacturing, Ltd.
