4K Surgical Field Camera System
Important
Please read this "Instructions for Use" carefully to familiarize
yourself with safe and effective usage.
Please retain this manual for future reference.
• For the latest product information including the "Instructions for
Use", refer to our web site :
www.eizo-or.com
Advertisement
Table of Contents
Related Manuals for Eizo CuratOR SC430-PTR
Summary of Contents for Eizo CuratOR SC430-PTR
- Page 1 Please read this “Instructions for Use” carefully to familiarize yourself with safe and effective usage. Please retain this manual for future reference. • For the latest product information including the “Instructions for Use”, refer to our web site : www.eizo-or.com...
- Page 2 EIZO Corporation. EIZO Corporation is under no obligation to keep any submitted material or information con dential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO product speci cations are subject to change without notice.
-
Page 3: Precautions
PRECAUTIONS IMPORTANT • This product has been adjusted speci cally for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as speci ed in the speci cations. •... - Page 4 Use. If the unit is installed incorrectly, it may drop or fall over, resulting in personal injury or equipment damage. If the unit falls, disconnect the power immediately and ask your local EIZO representative for advice. Do not continue using a damaged unit. Using a damaged unit may result in re or electric shock.
- Page 5 WARNING To disconnect the power cord or adapter power cable, grasp the plug rmly and pull. Tugging on the cord or cable may damage it and result in re or electric shock. The equipment must be connected to a grounded main outlet. Failure to do so may result in re or electric shock.
- Page 6 CAUTION Check the operational state before use. Begin use after ensuring that there are no problems with the displayed image. Securely x cables / cords that have a xing feature. If the cables and cords are not secured in place, they may become disconnected, leading to an interruption of the operation.
-
Page 7: About This Product
About This Product Intended Use This product is intended to be used for capturing the operative eld. Attention • This product may not be covered by warranty for uses other than those described in this manual. • The speci cations stipulated in this manual are only applicable when the enclosed power cord is used. •... -
Page 8: Cleaning
Cleaning Periodic cleaning is recommended to keep the product looking new and to prolong its operation lifetime. Gently wipe off any dirt attached to the product with a soft piece of cloth moistened with a small amount of water or one of the chemical agents listed below. Chemicals that may be used for cleaning Material name Product name... -
Page 9: Table Of Contents
CONTENTS 4-5. Video Output ..........33 PRECAUTIONS ............3 4-6. Audio ............33 IMPORTANT .............. 3 4-7. Device Setting ..........34 About This Product ..........7 4-8. Save/Load ............ 36 Intended Use ............. 7 4-9. Information ..........36 Precautions for Use ..........7 4-10. -
Page 10: Chapter 1 Introduction
Chapter 1 Introduction 1-1. Features ● Camera Performance • 4K resolution 60P 4K images can be captured in 60 frames per second • Optical 30x zoom ● Structure (Camera Mount) • Intelligent PTR (PAN/TILT/ROLL) Integrated camera mount allows for simple control Improved movability ●... -
Page 11: Package Contents
1-2. Package Contents Check that all of the following items are included in the package. Note • It is recommended that the box and packing materials be stored so that they can be used to move or transport the product. •... -
Page 12: Ccu
● Front 1. Power switch Turns the power on and off. To turn the power off, press and hold the button for approx. one second. 2. USB terminal Connects a USB memory when updating the software. See “5-3. Software Update” (page 40) for details. 3. - Page 13 Rear 1. Camera connection terminal Connects the camera to the CCU with the provided cable. 2. HDMI output terminal (FHD) Connects a monitor equipped with HDMI input. Full HD images and audio are output. 3. SDI output terminal (FHD) Connects a monitor equipped with SDI input. Full HD images and audio * 3, *4 are output.
-
Page 14: Camera
● Camera Front 1. Lens unit It is a zoom lens. An ND lter (included in the package) can be attached here. 2. IR sensor (light receiving section It is the light receiving section of the remote controller. Do not block of the remote controller) the light receiving section. - Page 15 Rear 0FTD0000 Mfd./ :yyyy-mm-dd S/N / 20000000 ## ## 05B2940 2A1 1. CCU connection terminal Connects the camera to the CCU with the provided cable. 2. MODE switch DIP switches used for switching the settings are located. The power is turned off for all the components in the factory default state. Keep this switch turned OFF.
-
Page 16: Chapter 2 Setup
Chapter 2 Setup 2-1. Before Installing the CCU ● Installation Requirements • The product must be installed at a stable place that is strong enough to withstand the weight. • The product must be installed at an appropriate location. Be sure to turn the power off and observe the safety precautions when installing. -
Page 17: Preparing The Camera
2-2. Preparing the Camera ● Attaching a Filter or a Close-up Lens (Optional) SC430-PTR comes with an ND lter and a close-up lens. Using the ND lter is recommended. • ND lter The lter reduces the light volume to 1/4 (two stages down). It is effective under a surgical light or when your operating environment is too bright. - Page 18 Apply a drop of the provided thread-locking uid at approximately three locations on the lter attaching area. Attention • Use the provided thread-locking uid. • The thread-locking uid is not an adhesive agent. Forcibly rotating the ND lter to left may cause the lter to be detached.
-
Page 19: Attaching The Camera To A Fixture (Arm/Stand)
● Attaching the Camera to a Fixture (Arm/Stand) The camera should be installed using an arm or stand. Attention • When installing, do so by carefully following the information in the User Manual about the arm or stand. • Check that the xture meets the following standards. - Clearance between the screw holes: 100 mm x 100 mm - Max. -
Page 20: Connected
2-3. Connected Attention • Do not move the drive unit of the camera with your hand. Be sure to use the CCU Control Panel or the remote controller. ● Connection Example Camera Monitor, etc. Camera cable HDMI cable, etc. Power cord ●... -
Page 21: Connecting Monitors And Encoders
● Connecting Monitors and Encoders To display or record images captured by the camera, devices such as a monitor and an encoder needs to be connected. Connect input terminals of the devices to the respective output terminals located on the rear side of CCU. Attention •... -
Page 22: Connecting The Power Cord
● Connecting the Power Cord Attention • Turn off this product before connecting it. • When removing the power cord, always remove the power plug from the power outlet rst. • Use the provided power cord. Connect the power cord to the AC IN terminal on the AC adapter. Insert the power cord all the way to the back. - Page 23 Check the rated value on the AC adapter and connect the power plug to the power outlet. Attention • If the AC adapter is installed vertically, make sure the AC inlet is not placed at the top. Correct: Horizontal position Incorrect: Vertical position •...
-
Page 24: Adjustments
2-4. Adjustments Connecting the power cord starts supplying power, and the test pattern appears. Then, the image captured by the camera is displayed on the monitor. Before using this product, it is recommended to con gure some of the settings tailored to your operating environment. -
Page 25: Adjusting The Brightness
Select “Installation Direction” and push the joystick toward right or left, and then select “CeilingSuspended”. <<=== Camera & Lens ==== Zoom Speed <|---|---|> Focus Speed <|---|---|> PAN Speed <|---|---|> TILT Speed <|---|---|> ROLL Speed <|---|---|> Installation Direction CeilingSuspended ROLL Angle Sync Zoom Position Sync The test pattern is displayed, and the settings are re ected. - Page 26 Setting “White Balance(WB)” with the “OnePush” Function When the white balance is affected by the red color (blood or organs) in the operative eld, this setting will disable the automatic color adjustment during an operation. Press the “MENU” button. The MENU screen appears on the monitor. Select “Color”...
-
Page 27: Chapter 3 Operation
Chapter 3 Operation Attention • Do not move the drive unit of the camera with your hand. Be sure to use the CCU Control Panel or the remote controller. 3-1. Camera Control 1. Joystick Used for PAN/TILT movements of the camera. The camera moves to a direction to which the joystick is pushed. -
Page 28: Menu Operation
3-2. Menu Operation Left / Go back Right Down ENTER Display Menu / Exit Right Left / Go back Down ENTER Display Menu (Press Hold) / Exit Chapter 3 Operation... -
Page 29: Chapter 4 Setting
Chapter 4 Setting This chapter introduces the functions that can be adjusted or con gured by pressing the “MENU” button on the CCU front panel. Note • After a certain period of idle time, the menu screen will exit. • To select and con rm a menu, use the joystick or the remote controller. See “Chapter 3 Operation”... -
Page 30: Picture
Features & Settings Description Functions Gain 0dB, 3dB, 6dB, 9dB, The sensitivity level of exposure is speci ed here. The image 12dB, 15dB, 18dB, brightness is determined. 21dB, 24dB, 27dB, This setting can be con gured when “ALC Mode” is set to “Manual”. 30dB, 33dB, 36dB, 39dB, 42dB, 45dB Iris Limit(H) -
Page 31: Color
4-3. Color The color display settings are speci ed here. <<=== Color ==== White Balance(WB) OnePush Execute WB Shift Red <|---|---|> WB Shift Blue <|---|---|> WB Reset Execute <|---|---|> Saturation <|---|---|> Features & Settings Description Functions White Balance(WB) Auto(Narrow) This function is used for adjusting the white balance. Auto(Wide) •... -
Page 32: Camera & Lens
4-4. Camera & Lens The camera motion speed and installation direction are speci ed here. <<=== Camera & Lens ==== Zoom Speed <|---|---|> Focus Speed <|---|---|> PAN Speed <|---|---|> TILT Speed <|---|---|> ROLL Speed <|---|---|> Installation Direction Normal ROLL Angle Sync Zoom Position Sync Features &... -
Page 33: Video Output
4-5. Video Output The settings for the image output format is con gured here. Signals from all the ports are output simultaneously. <<=== Video Output ==== 4K Output SDI Mode INTERLEAVE SDI BT.2020 Emulation Off 2K Output SDI Output Mode 1080p HDMI Output Mode 1080p... -
Page 34: Device Setting
4-7. Device Setting Various device settings are con gured here. <<=== Device Setting(1/2) ===>> Ethernet => Option Button PTR Acceleration Control IR Remote(Camera) IR Remote(CCU) Control Panel Features & Settings Description Functions Ethernet Specify the network address. IP Address Specify the IP address. Fill in “Addr0”, “Addr1”, “Addr2”, and “Addr3”... - Page 35 <<=== Device Setting(2/2) ===>> Factory Reset Partial Reset USB Memory => Software Update => Features & Settings Description Functions Factory Reset Partial Reset The settings are restored to the factory default state. All Reset Partial Reset The network settings and saved settings are retained, but the rest of them will be reset.
-
Page 36: Save/Load
4-8. Save/Load This menu is used for saving or loading the settings for this product. Use this menu for managing different sets of setting values to be used in varying operating environments. <<=== Save/Load ==== Save current settings User1 Load settings User1 ## Restart automatically after loading ## Features &... -
Page 37: Language
<<=== Information (2/3):Version ===>> Model Name SC430-PTR Serial No. xxxxxxxx Version Vxxxx MCPU BOOT R.xx.xx.xxxx MCPU R.xx.xx.xxxx SCPU R.xx.xx.xxxx FPGA R.xx.xx.xxxx FPGA CPU R.xx.xx.xxxx Features & Settings Description Functions Model Name SC430-PTR The model name of this product is displayed. Information on the CCU is displayed. -
Page 38: Chapter 5 Maintenance
Chapter 5 Maintenance This chapter introduces the administrator functions that are related to the maintenance of this product. 5-1. Exporting the Settings The settings for this product can be saved in a USB memory in a single operation. This function is useful for applying the same CCU settings of another operating room. - Page 39 Select “Save settings to USB memory”, and press the “ENTER” button or push the joystick toward right. <<=== USB Memory ==== Save settings to USB memory Load settings from USB memory No ## Restart automatically after loading ## Press the “ENTER” button. The settings are saved in the USB memory.
-
Page 40: Loading The Settings
5-2. Loading the Settings The settings for this product can be loaded from a USB memory and updated in a single operation. This function is useful for applying the same CCU settings of another operating room. The settings that can be loaded are those exported from the CCU only. See “5-1. -
Page 41: Chapter 6 Menu List
Chapter 6 Menu List ALC ..............................page 29 ALC Mode Level Shutter Speed Iris Gain Iris Limit(H) Iris Limit(L) Gain Limit Center Weighted Metering Picture ............................. page 30 Noise Reduction Sharpness Video Output Format Color ..............................page 31 White Balance(WB) WB Shift Red WB Shift Blue WB Reset... - Page 42 Save/Load ............................page 36 Save current settings Load settings Information ............................page 36 Information (1/3):Maintenance Model Name Ethernet MAC Address IP Address Subnet Mask Gateway FPGA Temp[°C] Information (2/3):Version Model Name Serial No. Version MCPU BOOT MCPU SCPU FPGA FPGA CPU Information (3/3):Version Model Name Serial No.
-
Page 43: Chapter 7 Troubleshooting
Chapter 7 Troubleshooting 7-1. If No Image Is Displayed Problem Possible cause and remedy 1. No picture • Check whether the power cord is connected properly. • Check whether the DC OUT terminal of the AC adapter and the DC IN terminal of the CCU are connected properly. -
Page 44: Speci Cations Of The Led Lighting
7-3. Speci cations of the LED Lighting The LED indicators will light up or start ashing in accordance with the system status. When you contact us, you may be asked to check the LED status. ● CCU Front POWER CAMERA LOCK MAINTENANCE LED status... -
Page 45: Camera Front
● Camera Front LED status Product status Flashing in red The inside of the camera is extremely hot. Or, the camera was brought to an emergency stop. Chapter 7 Troubleshooting... -
Page 46: Chapter 8 Speci Cations
Chapter 8 Speci cations 8-1. Speci cations Camera Image Sensor 1/2.5 type CMOS, single chip type Effective Pixels 3840 × 2160 Zoom Optical 30x motorized zoom Focal length f=4.6 (W) - 135 (T) mm Horizontal Field of View Approx. 68 (W) - Approx. 2.6 (T) deg. Minimum Object Distance (M.O.D.) 1500 mm (full range) 1000 mm (w/Close-up lens attached) -
Page 47: External Dimensions
8-2. External Dimensions ● Unit: mm 300.5 (12.5) 3xM4 (MAX depth 13mm) 3xM4 (MAX depth 13mm) ● Camera 19.5 (65.7) (59) 4xM4 (MAX depth 30mm) Chapter 8 Speci cations... -
Page 48: Appendix
If the open source software contains a product for which usage us granted under a GPL (GNU GENERAL PUBLIC LICENSE) license, EIZO Corporation will, in line with the GPL usage license conditions, provide the source code for corresponding GPL software via a medium, such as CD-ROM, at a cost to individuals and organizations who make contact via the following contact information for a minimum period of three years after purchase of the product. -
Page 49: Emc Information
EMC Information SC430-PTR has the capabilities of capturing images with the camera and outputting the images. Intended Use Environments The SC430-PTR is intended to be used in professional healthcare facility environments such as clinics and hospitals (including use in the vicinity of high-frequency surgical equipment such as electrosurgical knives). - Page 50 Technical Speci cations Electromagnetic emissions The SC430-PTR is intended for use in the electromagnetic environment speci ed below. The customer or the user of the SC430-PTR should assure that it is used in such an environment. Emission test Compliance Electromagnetic environment - Guidance RF emissions Group 1 The SC430-PTR uses RF energy only for its internal function.
- Page 51 Electromagnetic immunity The SC430-PTR has been tested at the following compliance levels according to the testing requirements for professional healthcare facility environments de ned in IEC / EN60601-1-2. Customers and users of the SC430-PTR must ensure that the SC430-PTR is used in the following environments: Immunity test Test level for Compliance level...
- Page 52 Recommended separation distances between portable or mobile RF communication equipment and the SC430-PTR The SC430-PTR is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the SC430-PTR can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the SC430-PTR.
-
Page 53: Warning For Radio Interference
Changes or modi cations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached speci ed cable below or EIZO signal cable with this product so as to keep interference within the limits of a Class A digital device. - AC Cord... -
Page 54: Limited Warranty
Original Purchaser or any third parties other than as provided under this Warranty. EIZO and Distributors will cease to hold or store any parts (excluding design parts) of the Product upon expiration of ve (5) years after the production of the Product is discontinued. In repairing the Product, EIZO and Distributors will use renewal parts which comply with our QC standards. -
Page 55: Recycling Information
Este producto debe desecharse y reciclarse según la legislación del país para reducir el impacto medioambiental. Cuando desee deshacerse de este producto, póngase en contacto con un distribuidor o una lial de su país. Encontrará las direcciones de contacto en el sitio web de EIZO que se indica a continuación. www.eizoglobal.com... - Page 56 Este produto, quando o deitar fora, deve ser recolhido e reciclado de acordo com a legislação do seu país para reduzir a poluição. Quando deitar fora este produto, contacte um distribuidor ou uma lial no seu país. Os endereços de contacto estão listados no website do EIZO, abaixo. www.eizoglobal.com...
- Page 57 страна за да се намали замърсяването на околната среда. Когато искате да се освободите от този продукт, моля свържете се с търговския му представител или със съответните органи отговарящи за това във вашата страна. Данните за връзка с нас са описани на следния Интернет сайт на EIZO: www.eizoglobal.com Informaţie referitoare la reciclare Acest produs, când debarasat, trebuie colectat şi reciclat conform legislaţiei ţării rspective ca să...
- Page 58 Geri Dönüşüm Bilgisi Bu ürünün, atılacağı zaman, ülkenizin çevre kirliliğinin azaltılması konusundaki mevzuatına göre toplanması ve yeniden değerlendirilmesi gerekmektedir. Ürünü atacağınız zaman lütfen ülkenizdeki bir distribütör veya ilgili kuruluşla temasa geçiniz. İrtibat adresleri aşağıdaki EIZO web sitesinde verilmiştir. www.eizoglobal.com Appendix...
- Page 60 153 Shimokashiwano, Hakusan, Ishikawa 924-8566 Japan Siemensallee 84, 76187 Karlsruhe, Germany Helmut-Grashoff-Strasse 18, 41179 Mönchengladbach, Germany 00N0N126A1 www.eizo-or.com IFU-SC430-PTR-3 Copyright © 2019 EIZO Corporation. All rights reserved. 1st Edition-April, 2019 Printed in Japan.
