  • Page 1 EDGE 190L Gasoline Welding Generator USER’S MANUALS...
  • Page 2: Table Of Contents

    The detailed information provided here in below, which contains the installation, trial run, operation and maintenance of “EDGE 190L Gasoline Dynamotor and Welding machine”, is intended for your kind perusal to help you minimize the operational problems so that the product can work as smoothly as it is expected.
  • Page 3: 1、 Brief Introduction To Edge190L

    6.3. Oil pipe check 1、 Brief introduction to EDGE 190L Gasoline Welding Generator EDGE 190L Gasoline welding generator is using gasoline engine for power generating. Gasoline chemical energy is transformed to mechanical energy, then to electric energy. The product could be used as welder and generator. The advantage is that it could not be...
  • Page 4 ⑶ Welding arc light is harmful to eyes ● Wear welding protective mask, watch welding arc through filter glass; ● Use welding mask conforming to national standards; ● Protect exposed skin in case of any hurt; ● Notice peoples around before welding work. ⑷...
  • Page 5: Operator's Self-Protection

    * No smoking, and keep away from any flame when charging fuel. 2.3 Operator’s notice * EDGE 190L gasoline welding generator belongs to electrical products. Do not switch or modulate over exert in case of damage to components. * Check welding cable every time before work, connection right and reliable or not, earth connection reliable or not.
  • Page 6: Safe Measures To Be Taken To Assure The

    * There will be sparks flying during operating, keep distance between working field and vicinity. * Operating should be within duty-cycle. Over load will cause accelerated components aging and decreased use life, even machine damage. * Do not modulate or move the machine during operation. * Welders have strong electromagnetism and frequency interference, so keep away people with heart pacemaker or the articles which can be interfered by electromagnetism and frequency.
  • Page 7: Welding Generator's Principle

    Assistant power supply output Table( 1) 3.3. Main Technical Data Model EDGE 190L Item Rated Frequency Hz Rated Voltage V 120/240 Rated current A 16.7/8.3 Max. power KVA output...
  • Page 8: Standard Applied

    Fuel consume rate g/HP-H ( Length × Wide × Height ) 700×540×650( with wheel) Unit NW(Kg) 3.4. Standard applied: * JB/T 9528-1999 * GB 15579.1-2004 * GB/T8118-1995 * GB 4208-93 3.5. Remark & Sign of Illustration 4. Control Panel 4.1. Control panel, parts name and function Item Name Qty.
  • Page 9: Control Panel

    Main power switch Air switch three pronged outlet Provide out power source as 120/240V Welding current output Connect welding cable terminal Fuel margin display Indicate the remained quantity of fuel Fuel tank cover Fuel tank cover 4.2. Control Panel Drawing( 1) AMPERAGE ADJUST AMPERAGE ADJUST 5、...
  • Page 10: Protection Grounding Check

    5.2.3 Place the machine at flat field in case of any shift the brake wheel should be locked. 6. Checking Before Started Check each part accordingly, keep safe environment and notice people before start. 6.1. Check gasoline engine oil 6.1.1 Check engine oil dipstick (refer to engine Manual) 6.1.2 Make up engine oil if it’s lower than limit.
  • Page 11: Starting Procedure

    7.5. Turn the switch of engine to “start” position 7.6. The pre-warning time should be 3-5mins Notice: speed is adjusted in place before shipment. Do not adjust at will, which will cause engine rotation speed quicker or slower. 8. Starting Procedure 8.1.
  • Page 12: Simple Fault Examination Guidance

    Notice: when welding, not using generating. Switch off power outlet in case of any hurt to people by wrong operation. Notice: when generating, remove welding cable. 11. Simple fault examination guidance Repairman could distinguish “Normal” and “Abnormal” situation. The guidance is useful for you under the condition that you don’t have any test equipment or measure instrument repairman.
  • Page 13: Notices

    12.2. Notices: 11.2.1 Rotation parts: Danger! There are high-speed moving parts in the machine. Stop the machine before Inside check and maintenance 11.2.2 Electric shock Hazard! There is high voltage part in working machine. Stop the machine before Inside check and maintenance 11.2.3.
  • Page 14: Main Circuit Chart

    Anti- shake feet was not Tighten Tighten Large Shake Generator was not tighten Tighten Engine Noise Repair Bad bearing Replace Noise Generator Loose fasten screw Fasten Cover Noise Repair objects Over heat Check the enviornment surrounded Short circuit when loading Check Adjust rotate speed to Abnormal rotate speed...
  • Page 15: Complete Set Specification

    Table(5) Item on drawing Description Quantity Gasoline machine Gasoline tank Frame Protector comp., muffler inner Protector comp., muffler outer Protector, muffler side Generator Anti-shock feet Universal wheel Directional wheel Winding Electricity appliance housing Welding current output terminal Cantalever resistor 5W 6Ω Operation board Underpan grounding screw Welding current adjustment knob...
  • Page 16 guarantee to get the welder repaired at our expense within 12 months upon the purchase of welder if and when the welder is found either damaged partially or working improperly. Explosive view( 2)...
  • Page 17 Drawing 3 Main circuit chart...
