- Page 22 Identifying the Hardware for Bertha Cabinet Assembly To simplify the process of identifying the hardware included with your Bertha cabinet, we have taken pictures of the hardware bags and listed the contents to help you with your construction process. In addition, please watch our video of the assembly.
- Page 23 Identifying the Hardware for Bertha Cabinet Assembly Figure 2...
- Page 24 Identifying the Hardware for Bertha Cabinet Assembly Figure 3...
- Page 25 Adjusting the height of the platform with an insert 1. Measure your machine freearm. 80% of the machines on the market measure 3-1/4” tall Picture 1 shows how to measure the freearm. We use a 5/16” socket to adjust the Arrow lift, standard Philips head screwdriver for the Kangaroo lift &...
- Page 26 3-1/4” in Kangaroo place at 7 mark from bottom 3-3/4” machine in Arrow place at 3-1/2” 3-3/4”in Kangaroo place at 5 from bottom 4-1/2” machine in Arrow place 4-3/8” mark 4-1/2” in Kangaroo place at bottom mark Manual Mechanism chain adjustment...
