- Page 1 SUZI STORAGE SIDEKICK Where Creativity Meets Color! OWNER’S MANUAL Assembly Instructions Model Numbers: 800 Oak 801 White 802 Cherry 803 Black 804 Pistachio Green 809 Blue IMPORTANT: Please read these instructions before assembling!
- Page 2 READ THIS PAGE FIRST ARROW WARRANTY Thank you for your purchase of an Arrow Sewing Cabinet! Thank you for your purchase! Our products have a three-year warranty from the date of shipment from our facility that covers manufacturer defects plus a 15 day warranty for any shipping damages.
- Page 3 NOTE: To assure proper handling of replacement parts Notice to Customer: please include the following information: Before beginning assembly, remove all parts from the carton. Please review the illustrations below to 800 (Oak) • Model Number of Unit - determine that all parts are Included. 801 (White) For assembly or operating assistance, or to report any 802 (Cherry)
-
Page 4: Hardware Included
Hardware Included Connecting Bolts x14 Cams x14 Drawer Runners x8 #6x1” Flathead Screw x32 DrawerCams x2 Drawer Connecting Bolts x2 #10x1-1/4” Door Magnet x1 Flathead Screw x28 Wood dowel x2 #6x5/8” Gold Panhead Screws x2 #4x1/2” #8x5/16” Gold Flathead Screws x14 Flathead Screws x4 #8/32x1”... -
Page 5: Cabinet Assembly
Understanding How the “ARROW-LOC” Cam Fastener Works 180° ARROW TOWARDS HOLE IN EDGE! Position bolt in Press cam Into pre-drilled Insert bolt through pre-drilled To lock, rotate cam pre-drilled hole and hole until flush with surface. hole in edge of panel. until tight, using turn until tight. - Page 6 Step 2. Attach Drawer Runners (x8) to Left and #6x5/8” Gold Panhead Screws (x2) (as shown in Right Sides (C,D) using #6x1” Flathead Screws (x32). Fig. 2). The metal side of the magnet faces panel Attach Door Magnet (x1) on Left Side (C) using edge.
- Page 7 For additional strength dab wood glue on the tip of Step 4. Attach Plate Casters (x4) to Bottom (F) screws before attaching. using #8x1/2” Silver Panhead Screws (x16) into holes provided (as shown In FIG.4). FIG. 4. #8x1/2” Silver Panhead Screws x16 into holes in Back (B), turn Cams to locked position Step 5.
- Page 8 Step 6. Place Top (E) on the floor, guide sides (C,D) FIG. 6. and Back (B) assembly onto Connecting bolts with the opening facing the tapered edge of Top panel (E), turn Cams to locked position. Attach Bottom (F) w/casters, guide Connecting Bolts into holes in sides (C,D), turn Cams to locked position (as shown in FIG.
- Page 9 Step 8. Thread Connecting Bolts (2 total) into pre- Step 10. Attach Drawer Sides (L) to Drawer Front/ drilled holes in Top Drawer Front. Install Cams (2 Back (M). Align Drawer Bottom grooves in Sides with total) in Drawer side (Kx1, Jx1) by pushing a Cam Drawer Bottom groove In Drawer Front (as shown in into each, hole flush with surface (as shown in FIG.
- Page 10 Wood Parts and Part Numbers Back Left Side Right Side Bottom Door Top Drawer Bottom Drawer Bottom Top Drawer Front Top Side Left Top Side Right Drawer Front/Back Drawer Side Ref. Description Part# Part# Part# Part# Part# Part# Cabinet Model# 800 (Oak) 801 (White) 802 (Cherry) 803 (Black) 804 (Green) 809 (Blue) Back...
- Page 11 Hardware Included with Part Numbers #8x1/2” Silver Panhead Screws Drawer Runners #4x1/2” Flathead Screws Wood dowel #10x1-1/4” Flathead Screw #8x5/16” Flathead Screws Item Description Part No. Drawer Stoppers #8x1/2” Panhead Screw 002614 Door Hinge #4x1/2” Flathead Screw 002705 #8x5/16” Flathead Screw 002000 #6x1”...
- Page 12 Accessories to Complete Your Sewing Experience Custom Insert Arrow Sewing Chairs Enhance your sewing experience with a custom-made Our sewing chairs are designed to provide comfort, insert for your Arrow or Kangaroo cabinet. Inserts are support, and the fashionable look you want for your designed to reduce the gap between the machine space.
