Hunter 28568 Installation Instructions

For Hunter Ceiling Fan Light Kits

Preparing for Installation

CAUTIONS
· Read entire text carefully before beginning
installation and save these instructions.
· Suitable for use in wet locations when used
with Hunter Type 5 suspended ceiling fans.
· To reduce the risk of electrical shock, install
this light kit only on listed Hunter ceiling
fans type A through Z.
WARNINGS
· To avoid possible electrical shock, before
installing light fixtures, disconnect power
by turning off the circuit breakers both
to the outlet box and to its associated wall
switch location. If you cannot lock the
circuit breakers in the off position,
securely fasten a prominent warning
device, such as a tag, to the service panel.
· Connect house wiring to the fan before
attaching the light fixture to the fan.
· All wiring must be in accordance with
national and local electrical codes. If you
are unfamiliar with wiring, you should use
a qualified electrician. Professional
installation is recommended.
© 2002 Hunter Fan Company
Installation Instructions
Outdoor Low Profile Light Kit
1. Unassemble the fan switch housing as shown in
Figure 1.
2. Disconnect the upper and lower plug connectors
between the upper switch housing and lower
switch housing.
Note: Do not discard any parts. You will need to
replace it if you remove the light fixture in the
future.
Switch
Housing
Cover
Plate
Figure 1 - Unassembling the fan switch housing
1
Upper Switch
Housing
Switch
Housing
Assembly
Screws
Lower
Switch
Housing
Plug Button
Switch Housing
Assembly Screws
41561-01 12-19-2002
