  • Page 1 PiiGAB PiiGAB M-Bus 810 Description User Manual www.PiiGAB.se...
  • Page 2 Phone +46 (0)31 55 99 77 All rights reserved. PiiGAB are registered trademark of Processinformation i Göteborg AB. Microsoft, Windows, Windows NT, Windows 2000, Windows XP and Windows Server 2003 are either trademarks or registered trademarks of Microsoft Cooperation in the United States...

  • Page 3: Table Of Contents

    Contents GENERAL ........................4 ....................4 BOUT THIS MANUAL ....................4 UNCTION OVERVIEW ..................4 ENEFITS AND POSSIBILITIES TECHNICAL STRUCTURE ..................5 ........................ 5 ONNECTIONS ........................6 NDICATIONS ..................6 ECHNICAL SPECIFICATIONS ......................6 UPPLY VOLTAGE ....................7 US SPECIFICATIONS ....................
  • Page 4 D E N M O D E R N A M - B U S T E K N O L O G I N SERIAL COMMUNICATION CABLES..............31 ....................31 ENERAL NFORMATION ......................31 ERIAL TO ......................32 ONFIGURATION ....................

  • Page 5: General

    WebPages. 1.2 Function overview The PiiGAB 810 gateway is working like an interface between Ethernet and the M- Bus wire. The gateway is transparent, which means that the questions asked through the Ethernet are being forwarded onto the electrical M-Bus interface. The same applies to the answers from the meters that are being sent over the Ethernet to the superior system.

  • Page 6: Technical Structure

    Connection for M-Bus loop 2 M-Bus Connection for M-Bus loop 2 M-Bus Connection for M-Bus loop 3 M-Bus Connection for M-Bus loop 3 M-Bus Connection for M-Bus loop 4 M-Bus Connection for M-Bus loop 4  PiiGAB Process Information i Göteborg AB...

  • Page 7: Indications

    2.4 Supply voltage The gateway should be supplied from a local 24 AC/DC transformer. If using a central 24 DC power supply you should mount a DC/DC converter between the gateway and the central power.  PiiGAB Process Information i Göteborg AB...

  • Page 8: M-Bus Specifications

    Communication speed: 300 – 230000bps Connector type: 8 Position Modular (RJ45) Female socket Male plug 2.7 Serial connection (RS232) Communication speed: 300 – 38400bps Connector type: 6 Position Modular (RJ12) Female socket Male plug  PiiGAB Process Information i Göteborg AB...

  • Page 9: Drawings

    T H E M O D E R N M - B U S T E C H N O L O G Y 2.8 Drawings Figure 2-1. Cabinet  PiiGAB Process Information i Göteborg AB...

  • Page 10: Communication Cables

    Ethernet Serial Serial M-Bus  Not used The following section describes the different adapters that can be connected to the gateway. A more detailed description including examples can be found in chapter 6.  PiiGAB Process Information i Göteborg AB...

  • Page 11: Adapter 1: Serial To M-Bus

    RJ-12 contact on the gateway. Table 2-7. Connection for adapter 3 9-pin DSUB/M RJ12/F Pin 2 (RxD) Pin 4 Pin 3 (TxD) Pin 3 Pin 5 (GND) Pin 1  PiiGAB Process Information i Göteborg AB...

  • Page 12: Adapter 4 And 5: Spy

    9-pin DSUB/F RJ12/F Pin 2 (RxD) Pin 3 Pin 5 (GND) Pin 1 Table 2-9. Connection for adapter 5 (M-Bus response) 9-pin DSUB/F RJ12/F Pin 2 (RxD) Pin 2 Pin 5 (GND) Pin 1  PiiGAB Process Information i Göteborg AB...

  • Page 13: Get Started Step By Step

    T E C H N O L O G Y Chapter Get started step by step This chapter covers the different steps needed to put the M-Bus 810 gateway into operation. 3.1 Necessary information The connecting of the supply voltage and the M-Bus loop is made according to table 2.1.

  • Page 14: Using M-Bus Wizard

    4. Choose “Change Device Parameters” from the main menu and click through to the site where you make your choice. At PiiGAB we recommend usage of UDP if this is supported by the superior software. The reason for this is that the M-Bus driver has complete control over how the questions and answers are being sent.

  • Page 15: Communication Toward Meters

    NrOfTelegrams, InitRead etc. The document “Citect for Windows, Version 5.xx, 6.xx M-Bus driver, User Information” (Version: 1.01.03.001-1) is available to download at the PiiGAB website.  PiiGAB Process Information i Göteborg AB...

  • Page 16: Bus Wizard

    Setup files or go via the control panel. After the program has been installed you can start it by choosing the program in the start menu. If the installation has been made with the base settings the program can be found under the PiiGAB folder.

  • Page 17: Finding The Gateway And Change Ip Address

    If 810 is connected to the network choose the option on top and with a serial connection pick the lower. In this part we are assuming that the gateway is connected to the network. On the side of the gateway there is a label with the  PiiGAB Process Information i Göteborg AB...
  • Page 18 If you are going to use a unique IP address contact the responsible for the network in order to get the correct information. Click on “Next” to continue. Figure 4-5. Change IP settings – update device  PiiGAB Process Information i Göteborg AB...
  • Page 19 Figure 4-7. Network search complete If the gateway can be found within the network you can see it in the above listings. Choose the preferred meter and click “Next” to go to the main menu.  PiiGAB Process Information i Göteborg AB...

  • Page 20: Communication Test (Ping)

    “Ping”. If the earlier steps in the Wizard are made correctly, the chosen IP address will show up on this page. Figure 4-9. Ping device If you make contact by using the Ping command the above communication result will show. Push “Next” to continue.  PiiGAB Process Information i Göteborg AB...

  • Page 21: Configuration Parameters

    2.8.1. Follow the Wizard instructions to configure via the serial-port. The difference from configure via the network is that you have to turn the voltage off and on to get to the installations. Figure 4-11. Change device parameters  PiiGAB Process Information i Göteborg AB...
  • Page 22 ”DeviceInstaller_UG_900-310.pdf” for further installation information. Figure 4-12. Change device parameters If serial communication is chosen the following picture will show. This document can be found at the CD delivered together with the gateway.  PiiGAB Process Information i Göteborg AB...
  • Page 23 Figure 4-13. Change device parameters After the port has been chosen click “Next” and follow the picture instructions. The same configuration picture will be shown as the one for configuration over the network.  PiiGAB Process Information i Göteborg AB...

  • Page 24: Meter Settings

    Figure 4-14. Initialize meter Figure 4-15. Find meter’s address By this choice you get information about what primary and secondary address the meter has. If you do not know the meter’s address choose “Test and diagnostics”  PiiGAB Process Information i Göteborg AB...
  • Page 25 This is the way it can look when the meter is answering. Figure 4-17. Set meter’s primary address There is also a possibility to change the meter’s primary address. Some meter manufacturers do not support the possibility to change the primary address on the  PiiGAB Process Information i Göteborg AB...
  • Page 26  PiiGAB Process Information i Göteborg AB...
  • Page 27 Figure 4-19. Read meter’s first data telegram The first telegram can be read out by this choice. Figure 4-20. Read meter’s first data telegram This is the way it can look when the meter is answering.  PiiGAB Process Information i Göteborg AB...
  • Page 28 Some meters need an application reset instead or in combination with SND_NKE to reset the meter to be able to read the first telegram. In some cases the meter need a subcode together with the application reset which also is possible to choose.  PiiGAB Process Information i Göteborg AB...

  • Page 29: Other Configuration Methods

    4. The screen will now show the same information as if you would use a Telnet connection. To continue see chapter 5.2 “Using Telnet.”  PiiGAB Process Information i Göteborg AB...

  • Page 30: Using Telnet

    To configure a unit over the network via Telnet you have to first create a connection to port 9999. Figure 5-1. Example Telnet The necessary settings to do if you are using Telnet to get the communication to work are:  PiiGAB Process Information i Göteborg AB...
  • Page 31 CC (UDP), C0 (TCP) Datagram Type when UDP If you want to make more adjustments please look in the original documentation XPort_UG_900-270.pdf This document can be found at the CD delivered together with the gateway.  PiiGAB Process Information i Göteborg AB...

  • Page 32: Serial Communication Cables

    When the network has been built out you can connect it to the network port on the gateway instead.  You can also use the gateway as a pure serial to the M-Bus converter of course.  PiiGAB Process Information i Göteborg AB...

  • Page 33: Configuration

    All traffic being send or received on the M-Bus port are mirrored to the serial port. This means that different types of programs can be connected for monitoring. To be able to both write and read you need two communication ports on your computer.  PiiGAB Process Information i Göteborg AB...
  • Page 34 By monitoring and/or logging the traffic a verification of the done readings can be made. Below is shown how the traffic can look like with a Serial analyzer Figure 6-1 Example of serial analyzer from Fifo electronics  PiiGAB Process Information i Göteborg AB...

  • Page 35: Device Installer

    When the M-Bus protocol is used the Port Settings 8, even, 1 should be made. See below. Figure 7-1. Port Properties This document can be found at the CD delivered together with the gateway.  PiiGAB Process Information i Göteborg AB...
  • Page 36 T E C H N O L O G Y If UDP is used ”Datagram Mode” has to be set to True and ”Datagram Type” be set to 01, see the picture below. Figure 7-2. Port Properties  PiiGAB Process Information i Göteborg AB...

  • Page 37: Com Port Redirector

    Windows communication ports. These virtual communication ports are redirected over a network to the M-Bus port of a PiiGAB 810 Gateway. The communication with the gateway is done in pretty much the same way as when ”pure” TCP/IP is used. The main difference is that the software sees the gateway as a normal communication port.

  • Page 38: Non-Redirected Connection Vs. Redirected Connections

    To address latency, Com Port Redirector provides a No Net Close option in the Port Settings dialog box. This option keeps the TCP/IP connection open when the com port is closed, reducing latency.  PiiGAB Process Information i Göteborg AB...

  • Page 39: Installing Com Port Redirector

    Either step displays the Redirector- Welcome screen in Figure 8-2. Figure 8-2 Redirector – Welcome Screen 2. Click the Continue button. The contents of the file are unpacked and the Welcome screen in Figure 8-3 appears.  PiiGAB Process Information i Göteborg AB...
  • Page 40 Redirector software will be installed. We recommend the default location. To change this location, click the Browse button and select a different location. 5. Click Next. The Select Program Folder dialog box appears (see Figure 8-5).  PiiGAB Process Information i Göteborg AB...
  • Page 41 To change this name, type a new name in the Program Folders field. 7. Click Next. The program is installed. After the installation, the Setup Complete dialog box appears (see Figure 8-6).  PiiGAB Process Information i Göteborg AB...
  • Page 42 9. Click the Start button in the Windows Taskbar, point to Programs, point to Lantronix Redirector, and click Configuration. The Com Port Redirector Configuration window appears (see Figure 8-7). Figure 8-7. Com Port Redirector Configuration Window  PiiGAB Process Information i Göteborg AB...
  • Page 43 Removing the checkmark indicates the port will not be available from the Redirect To drop-down list. 13. When finished, click OK. Note: After you use the Port Setup dialog box to add or remove com ports, reboot your computer.  PiiGAB Process Information i Göteborg AB...

  • Page 44: Configuration

     Do not run Com Port Redirector with other software that installs a virtual com port.  Do not run Com Port Redirector with other Com Port Redirection software on the same PC.  PiiGAB Process Information i Göteborg AB...

  • Page 45: Redirector Configuration

    T E C H N O L O G Y 8.3.3 Redirector Configuration This section describes how to configure Com Port Redirector for use with PiiGAB 810 M-Bus gateway. Choose IP address, Port number and baud rate to gateway before using the Com Port Redirector.
  • Page 46 Figure 8-12. Port Settings Dialog Box 9. Click OK. 10. Click the Save button.  PiiGAB Process Information i Göteborg AB...

  • Page 47: Verifying Connectivity With The Gateway

    (refer to the appropriate configuration section in this chapter for setup procedures for you gateway). 4. To hide the pop-up window, check Silent Mode on the Com Port Redirector Configuration window. Figure 8-13. Enabling Silent Mode  PiiGAB Process Information i Göteborg AB...

  • Page 48: Appendix

    Papouch s.r.o. Helping Buildings Think Strasnicka 3164/1a Lutidine House 102 00 PRAGUE 10 Newark Lane Czech Republic Ripley, Surrey GU24 6BS Phone +420 267 314 267 Phone +44 (0) 1483 270050 www.papouch.com www.helpingbuildingsthink.com  PiiGAB Process Information i Göteborg AB...
