Summary of Contents for KanexPro SP-SDIX4

  • Page 1 PDF provided by Conference Room AV KanexPro SP-SDIX4 1x4 3G/HD/SD-SDI Distribution Amplifier - 1080p...
  • Page 2 3G/HD/SD_SDI Splitter 1 x 4 User manual VER:1.1...
  • Page 3 Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. I. Introduction 1×4 SDI splitter distributes allows 1 SDI, HD-SDI or 3G-SDI video source to 4 SDI/HD-SDI/3G-SDI displays simultaneously.
  • Page 4 Supports resolutions up to 1920x1080@60Hz. Supports signal input and output distances of up to 300m for SD signals, 200m for HD signals and 100m for 3G signals. Supports 5-12V wide voltage input. III. Package 1x4 SDI Splitter --------------------------------------------------------------------------- 1PCS 5V1A DC Power Supply adapter ------------------------------------------------------- 1PCS Operation Manual ------------------------------------------------------------------------- 1PCS IV.
  • Page 5 ESD Protection Human Body Model: ± 8kV (air-gap discharge) ± 4kV (contact discharge) Dimensions (mm) 70(W) X 145 (D) X 25 (H) Weight 350g Operating Temperature 0°C ~ 40°C / 32°F ~ 104°F Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F Relative Humidity 20 ~ 90% RH (Non-condensing) Power Consumption (Max)
  • Page 6 V. Operation controls and Functions Front Panel ON/OFF: Power on/off switch. POWER LED: This red LED illuminate when the device is connected with power supply. LOCK LED: This red LED illuminate when the SDI signal plug in.
  • Page 7 Rear Panel SDI INPUT: This slot is where you connect the SDI source output from SDI Camera. SDI OUTPUT: These slots are where you connect the SDI displays or monitors with coaxial cable (RG6). DC 5V-12V: Plug the 5V or 12V DC power supply into the unit and connect the adapter to AC wall outlet.
  • Page 8 VI. Application Example...
