- Page 1 HDSP2X4 HDMI 2 x 4 Splitter with Full HD 1080p...
- Page 3 HDSP2X4 Setup Guide Table of Contents 1) Introduction 3 2) Specifications 4 3) Package Contents 4 4) Unit Layout & Description 5...
-
Page 4: Specifications
Specifications Input: HDMI x2 Interface: Output: HDMI x4 Operating Frequency: Video Amplifier Bandwidth of 6 75 Gbps Vertical Frequency Range 60Hz Maximum Resolution: 1920x1080p@60Hz 12bit per channel Color Depth: Power Supply: 5V DC@2A, 5W Environmental: Operating Temperature: 0°C to +70°C Operating Humidity: 10% to 85 % RH (no condensation) Storage Temperature: -10°C to +80°C Storage Humidity: 5% to 90 % RH (no condensation) Regulatory Approvals Converter: FCC, CE, UL Regulatory Approvals Power Supply: FCC, CE, UL Dimensions: 10 6”x7 1”x1 6” (270x181x40mm) Weight: 3 1lbs (1416g) Warranty: 1 Year limited Package Contents 1)Splitter Unit x1 2)5V DC Power Supply x1... - Page 5 Unit Layout & Description Transmitter Front Output 1 Output 2 Output 3 Output 4 Input 1 Input 2 Switch Power Output 1 Output 2 Output 3 Output 4 Input 1 Input 2 Switch Power Back HDMI Output 4 HDMI Output 3 HDMI Output 2 HDMI Output 1 HDMI Input 2...
-
Page 6: Connection Diagram
D. NO LIABILITY FOR DAMAGES TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL KANEXPRO BE LIABLE FOR ANY DAMAGES WHATSOEVER (INCLUDING WITHOUT LIMITATION, SPECIAL, INCIDENTAL, CONSEQUENTIAL, OR INDIRECT DAMAGES FOR PERSONAL INJURY, LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, OR ANY OTHER PECUNIARY LOSS) ARISING OUT OF THE USE OF OR INABILITY TO USE THIS PRODUCT, EVEN IF KANEXPRO HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES Brea, California KanexPro com MPN: HDSP2X4 HDMI are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. Kanex is a trademark of Apogee Inc., registered in the U.S. HDBaseT™ is a trademark of HDBaseT™ alliance. Blu-Ray is a trademark of Blu-ray Disc Association. Playstation is the registered... - Page 8 Brea, California KanexPro.com...
