Installation and operating instructions
URBAN MF SERIES
URBAN MF 800-40-NG/LPG-1S 2S L/R 3S T
URBAN MF 800-75-NG/LPG-1S 2S L/R T
URBAN MF 1050-40-NG/LPG-1S 2S L/R 3S T
URBAN MF 1050-75-NG/LPG-1S 2S L/R T
URBAN MF 1300-40-NG/LPG-1S 2S L/R 3S T
URBAN MF 1300-75-NG/LPG-1S 2S L/R T
URBAN MF 1500-40-NG/LPG-1S 2S L/R 3S T
URBAN MF 1500-75-NG/LPG-1S
URBAN MF 1900-40-NG/LPG-1S 2S L/R 3S T
URBAN MF 2400-40-NG/LPG-1S 2S L/R 3S T

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the URBAN MF Series and is the answer not in the manual?

Questions and answers

Related Manuals for Metalfire URBAN MF Series

Summary of Contents for Metalfire URBAN MF Series

  • Page 1 Installation and operating instructions URBAN MF SERIES URBAN MF 800-40-NG/LPG-1S 2S L/R 3S T URBAN MF 800-75-NG/LPG-1S 2S L/R T URBAN MF 1050-40-NG/LPG-1S 2S L/R 3S T URBAN MF 1050-75-NG/LPG-1S 2S L/R T URBAN MF 1300-40-NG/LPG-1S 2S L/R 3S T...
  • Page 2 G_EN_08...

  • Page 3: Table Of Contents

    1 Table of contents Table of contents ..............................3 Introduction ................................5 Dimensions and weights of the appliance ......................5 Technical specifications............................6 Characteristics of the fireplace ........................6 4.1.1 Burner pebbles ............................6 4.1.2 Logburner ..............................9 Gas control components ........................... 15 Gas and Electricity connections........................
  • Page 4 12.2.6 Replacing batteries ........................... 45 Maintenance ..............................46 Troubles ................................ 46 14.1 In general ..............................46 Honeywell ESYS – black remote control ....................47 14.2 14.2.1 Examples of error messages: ......................47 14.2.2 Registering the RF remote control again in case of lack of communication between the remote control and the receiver: ............................

  • Page 5: Introduction

    2 Introduction We thank you for your confidence in the Metalfire fireplace you purchased. Our products guarantee atmospheric heating for years on end. Before beginning the installation of the appliance, first read these installation and operating instructions carefully. Afterwards you hand this manual over to the customer.

  • Page 6: Technical Specifications

    4 Technical specifications 4.1 Characteristics of the fireplace 4.1.1 Burner pebbles URBAN MF 800-40/75-NG/LPG-1S 2S L/R 3S T Type B11AS B11BS B14AS B14BS Cat. Type of Supply Load Burner pressure Consumption Nozzle Restriction Ø Flue gas duct (mm) pressure mbar Qn (Hi) mbar m³/hr...
  • Page 7 URBAN MF 1300-40/75-NG/LPG-1S 2S L/R T Type B11AS B11BS B14AS B14BS Cat. Type of Supply Load Burner Consumption Nozzle Restriction Ø Flue gas duct (mm) pressure Qn (Hi) pressure m³/hr (mm) (mm) mbar mbar 1300-40 1300-40 1300-75 1300-75 1S T 2S L/R 1S 2S L/R I2E+...
  • Page 8 URBAN MF 1500-40/75-NG/LPG-1S 2S L/R 3S T Type B11AS B11BS B14AS B14BS Cat. Type of Supply Load Burner Consumption Nozzle Restriction Ø Flue gas duct (mm) pressure Qn (Hi) pressure m³/hr (mm) (mm) mbar mbar 1500-40 1500-75 1S 1S 2S L/R T 3S I2E+ 19.53 17.57...

  • Page 9: Logburner

    URBAN MF 2400-40-NG/LPG 1S 2S L/R 3S T Type B11AS B11BS B14AS B14BS Cat. Type of Supply Load Burner Consumption Nozzle Restriction Ø Flue gas duct (mm) pressure Qn (Hi) pressure m³/hr (mm) (mm) mbar mbar 2400-40 2400-40 T 1S 2S L/R 3S I2E+ 21.93 16.32...
  • Page 10 URBAN MF 1050-40/75-NG/LPG-1S 2S L/R 3S T (LB800/15) Type B11AS B11BS B14AS B14BS Cat. Type of Supply Load Burner Consumption Nozzle Restriction Ø Flue gas duct (mm) pressure Qn (Hi) pressure m³/hr (mm) (mm) mbar mbar 1050-40 1050-40 1050-75 1050-75 1S 2S L/R 1S 2S L/R 18.73...
  • Page 11 URBAN MF 1300-40-NG/LPG-3S (LB800/15) Type B11AS B11BS B14AS B14BS Cat. Type of Supply Load Burner Consumption Nozzle Restriction Ø Flue gas duct (mm) pressure Qn (Hi) pressure mbar m³/hr (mm) (mm) mbar 1300-40 3S 18.73 1.98 1 x 3.3 1 x 5.7 I2E+ 17.48 23.1...
  • Page 12 URBAN MF 1500-40/75-NG/LPG-1S 2S L/R 3S T (LB1100/15) Type B11AS B11BS B14AS B14BS Cat. Type of Supply Load Burner Consumption Nozzle Restriction Ø Flue gas duct (mm) pressure Qn (Hi) pressure m³/hr (mm) (mm) mbar mbar 1500-40 1500-75 1S 1S 2S L/R T 3S 19.79 18.5 2.09...
  • Page 13 URBAN MF 2400-40-NG/LPG 1S 2S L/R 3S T (LB1100/15) Type B11AS B11BS B14AS B14BS Cat. Type of Supply Load Burner Consumption Nozzle Restriction Ø Flue gas duct (mm) pressure Qn (Hi) pressure m³/hr (mm) (mm) mbar mbar 2400-40 2400-40 T 1S 2S L/R 3S 19.79 18.5...
  • Page 14 Country overview I3B/P I3B/P I2E+ G20/G25 - G30/G31- G20 20mbar G25 25mbar G20 20 mbar G30 30 mbar G30 50 mbar 20/25 mbar 28-30/37 mbar √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √...

  • Page 15: Gas Control Components

    4.2 Gas control components Model Urban all models Remote control and gas control Honeywell ESYS Ignition Automatic/electric ½”G ISO 7 Gas connection Supply voltage ~ 230 V 50 Hz 28Va 0.83 A Ionization protection and atmospheric protection have been carried out as a combined unit. 4.3 Gas and Electricity connections In the Urban MF appliances, the gas and electricity connections are always on the left side of the fireplace.

  • Page 16: Safety

    5 Safety 5.1 CE homologation mark This appliance has been tested according to directive 2009/142/EC and on the basis of standard EN509. It concerns an ornamental gas-fired open fireplace intended for ambiance heating. 5.2 Safety instructions for the installation This open gas appliance may only be installed by a recognized installer according to the applicable national and/or local regulations.

  • Page 17: Installation And Mounting Instructions

    LED error indication: Red error LED TTB reset button Error code on Honeywell remote control 6 Installation and mounting instructions. 6.1 Description of the parts supplied Fireplace - Installation and operating instructions - Ceramic log set and decorative material - Remote control - Operating key - Spray can - Shut-off valve (optional)

  • Page 18: Flue Gas Duct

    In these cases, a protected flue gas fan must be installed. For this purpose, Metalfire offers an integrated solution with flue gas fans, make Exodraft. The electronic control of the fireplace activates and controls the operation of the fan before the fireplace is activated.
  • Page 19 Provided air supply connections: The following connections are provided at the bottom of the fireplace: URBAN MF 800-40/75 1S 2S L/R 3S T : 1 connection Ø 150 URBAN MF 1050-40/75 1S 2S L/R 3S T: 2 connections Ø 150 URBAN MF 1300-40/75 1S 2S L/R 3S T: 2 connections Ø...
  • Page 20 Galvanized convection jacket The flexible ducts with diameter 150 must be connected to the connection flanges at the top of the galvanized casing. These flexible ducts must run vertically over at least 0.75 metre before being bent and connected to the outlet grills.

  • Page 21: Gas Control Components And Connection Diagram

    7 Gas control components and connection diagram: 7.1 Honeywell ESYS – black remote control 7.1.1 Control components 1. Receiver DFGT-03MC01 2. Electronic burnerunit S4565C3037B 3. Gas valve VK4100 4. Remote control G_EN_08...

  • Page 22: General Connection Diagram

    7.1.2 General connection diagram : G_EN_08...
  • Page 23 Connection possibility for domotics (house automation system) Connection micro switches on air and flue gas valves – NORMAL CLOSED – MS1 – MS2 PARALLEL Connection TTB-components APS-CHECK Extra contact if optional electronic dampers or exhaust fan is used Feedback contact if optional electronic dampers or exhaust fan is used VALVE/EXHAUST Start signal for optional electronic dampers or exhaust fan, if used 7.1.2.1 Connection diagram without flue gas fan (type B11AS)
  • Page 24 7.1.2.2 Connection diagram with flue gas fan (Type B14AS) EFC 21 control for flue gas fan A: Fuse B: Internal control pressure difference switch C: Output to fan motor G: Supply voltage 230V 50Hz H: Input On/Off signal from the fireplace electronics (FAN) I: Release signal to the fireplace electronics (pressure switch)
  • Page 25 7.1.2.3 Connection without flue gas fan with TTB (B11BS) Connection possibility for domotics (house automation system) Connection micro switches on air and flue gas valves – NORMAL CLOSED – MS1 – MS2 PARALLEL Contact connected with temperature help relay: K1: TTB relay – temperature measurement relay K2: minirelais 24Vac –...
  • Page 26 7.1.2.4 Connection with flue gas fan with TTB (B14BS) EFC 21 control for flue gas fan A: Fuse B: Internal control pressure difference switch C: Output to fan motor G: Supply voltage 230V 50Hz H: Input On/Off signal from the fireplace electronics (FAN) I: Release signal to the fireplace electronics (pressure switch)

  • Page 27: Connection And Operation Of The Flue Gas Fan

    7.1.3 Connection and operation of the flue gas fan Installation diagram Flue gas fan with pressure differential switch Service switch Main supply Honeywell ESYS Connection of flue gas fan to EFC21 Q1 is a main switch that is installed close to the flue gas fan.
  • Page 28 C, the main burner will be ignited. If the flue gas fan together with the pertaining control is supplied by Metalfire, then the pressure sensor and the speed of the fan is set by Metalfire.

  • Page 29: Operating The Remote Control

    8 Operating the remote control 8.1 Honeywell ESYS: black remote control 8.1.1 Introduction The fireplace can be switched ON or OFF by means of the RF remote control. The fireplace operates with a pilot flame that is constantly on whenever the fireplace is switched on. This pilot flame ignites the main burner. The RF remote control offers the opportunity to set the flame height manually.

  • Page 30: User Menu

    Start screen with standard indication Decrease key Increase key Menu key On-off key 8.1.3 User menu Via the user mode you can make a selection between ECOWAVE and manual flame height adjustment. The time display is adjustable via this menu. From the standard display press once the menu button to activate the menu ECOWAVE, the following screen appears: The screen below appears:...

  • Page 31: Operating The Fireplace

    8.1.4 Operating the fireplace. Activate the display by pushing one of the four keys. The following screen appears: Manual flame height setting By pressing both scroll arrows simultaneously the fireplace will ignite. After the pilot flame has been detected the main burner can be activated by pressing a scroll arrow twice.

  • Page 32: Fireplace Decoration

    Reinstall the rear cover of the RF remote control by putting the notches A and B of the rear cover (figure 3) into the corresponding notches of the housing (figure 2). Slide the rear cover upward in order to interlock it. After having replaced the batteries the time indication will have to be reset.

  • Page 33: Wood Logs For Logburners

    Amount of stones per appliance: Urban MF 800 x 40/75G 1S 2S L/R 3S 8 kg Urban MF 800 x 40 G T 12 kg Urban MF 1050 x 40 /75G 1S 2S L/R 3S 10 kg Urban MF 1050 x 40 G T 16 kg Urban MF 1300 x 40 /75G 1S 2S L/R 3S 12 kg Urban MF 1300 x 40 G T...

  • Page 34: Logburner 500/15

    Keep the area around the pilot flame unit clear of vermiculite 9.2.2 Logburner 500/15 9.2.2.1 Classic style G_EN_08...
  • Page 35 9.2.2.2 Smoke style 1’ 5’ 5’ 1’ G_EN_08...

  • Page 36: Logburner 800/15

    9.2.3 Logburner 800/15 9.2.3.1 Classic style G_EN_08...
  • Page 37 9.2.3.2 Smoke style 2’ 4’ 5’ 3’ 5’’ 5’ 5’’ 2’ 3’ 4’ G_EN_08...

  • Page 38: Logburner 1100/15

    9.2.4 Logburner 1100/15 9.2.4.1 Classic style G_EN_08...
  • Page 39 9.2.4.2 Smoke style G_EN_08...

  • Page 40: Basic Test Of The Fireplace

    10 Basic test of the fireplace Before starting the finishing work of the fireplace’s encasing, the fireplace must be submitted to a basic test. The fireplace’s gas connection to the gas supply line must be checked for leakage. Connect the plug to the wall outlet. Open the flue gas valve and the air supply valve of the fireplace using the special operation lever.

  • Page 41: Safety Functions

    11 Safety functions 11.1 Fireplace configuration B11AS This configuration comprises an open fireplace with flue gas duct with natural draught, a draught blocking device and an atmospheric pilot flame safety device. If the draught in the chimney would become insufficient (contamination, blockage, …), the pilot flame will switch off the appliance so that no intoxication can occur.

  • Page 42: Operating Instructions

    12 Operating instructions The flue gas duct must be in good condition, and be cleaned prior to the installation of the fireplace, and manufactured of fire-resistant material. The draught must be checked by means of a flue gas test. 10 minutes after a cold start-up, the flue gasses must be correctly evacuated through the flue gas duct.

  • Page 43: Screen And Keys

    12.2.2 Screen and keys Screen Manual operation Closed (left) or open fireplace type (right) Atmospheric fireplace is switched on Atmospheric fireplace can be ignited Failure of atmospheric fireplace can be reset (right) Burner off/setting lower (left), burner on/setting higher ignited) An action is in progress (e.g.

  • Page 44: User Menu

    12.2.3 User menu Via the user mode you can make a selection between ECOWAVE and manual flame height adjustment. The time display is adjustable via this menu. From the standard display press once the menu button to activate the menu ECOWAVE, the following screen appears: The screen below appears: When the burner is on, the ecowave function can be activated via...

  • Page 45: Resetting A Failure

    12.2.5 Resetting a failure. If, on igniting the fireplace, after approximately 40 seconds of sparking no flame can be detected, the fireplace will go into fail condition. The error message “Fxx” appears on the screen. You can now reset the fireplace by pressing both scroll arrows simultaneously. Wait 3 minutes after resetting before igniting the fireplace again.

  • Page 46: Maintenance

    13 Maintenance Make sure that the fireplace has fully cooled down before beginning the cleaning of the fireplace and the burner medium. Shut off the gas supply and switch off the electric power. Clean the fireplace and the burner medium using a vacuum cleaner. Maintenance is of utmost importance.

  • Page 47: Honeywell Esys - Black Remote Control

    14.2 Honeywell ESYS – black remote control The fireplace is controlled by means of a bidirectional communication between the RF remote control and the receiver. Thanks to this, error messages can be displayed on the screen of the remote control. 14.2.1 Examples of error messages: Communication failure between RF remote control and the fireplace.

  • Page 48: Registering The Rf Remote Control Again In Case Of Lack Of Communication Between The Remote Control And The Receiver

    14.2.2 Registering the RF remote control again in case of lack of communication between the remote control and the receiver: Pull power supply out of wall socket Press the menu key for 10 seconds until the time indication blinks in the left upper corner.

  • Page 49: During Firing With Ttb

    checked. This must be 4mm. Check the connection of the ignition cable to the ignition electrode and to the burner controller. Check the electrical connection of the appliance. This connection must be earthed. Check whether the gas supply valve is opened. If after three lighting attempts of the pilot flame, at which sparks are produced each time, no flame is produced, there is a problem with the gas supply.

  • Page 50: Fault Reset

    14.3 Fault reset. If there is a problem when igniting the fireplace or during operation, the fireplace goes into safety mode. As a result, an error message appears on the screen. You can now reset the fire by pressing both arrow keys simultaneously. After resetting, wait for 3 minutes before trying to re-ignite the fire.

  • Page 51: Terms Of Guarantee

    Use of non-original Metalfire parts and electrical and electronic components that have not been approved by Metalfire. 15.3 Reservation Metalfire+ bvba reserves the right to change its appliances, brochures, installation and operating manuals at any time and without prior notice. Serial number:...
