URBAN MF SERIES
URBAN MF 800-40-NG/LPG-1S 2S L/R 3S T + LB
URBAN MF 800-75-NG/LPG-1S 2S L/R T + LB
URBAN MF 1050-40-NG/LPG-1S 2S L/R 3S T + LB
URBAN MF 1050-75-NG/LPG-1S 2S L/R T + LB
URBAN MF 1300-40-NG/LPG-1S 2S L/R 3S T + LB
URBAN MF 1300-75-NG/LPG-1S 2S L/R T + LB
URBAN MF 1500-40-NG/LPG-1S 2S L/R 3S T + LB
URBAN MF 1500-75-NG/LPG-1S + LB
URBAN MF 1900-40-NG/LPG-1S 2S L/R 3S T + LB
URBAN MF 2400-40-NG/LPG-1S 2S L/R 3S T + LB
Installation and operating instructions
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Metalfire URBAN MF Series
Summary of Contents for Metalfire URBAN MF Series
- Page 1 URBAN MF SERIES URBAN MF 800-40-NG/LPG-1S 2S L/R 3S T + LB URBAN MF 800-75-NG/LPG-1S 2S L/R T + LB URBAN MF 1050-40-NG/LPG-1S 2S L/R 3S T + LB URBAN MF 1050-75-NG/LPG-1S 2S L/R T + LB URBAN MF 1300-40-NG/LPG-1S 2S L/R 3S T + LB...
-
Page 2: Operating The Remote Control
8 Operating the remote control 8.1 Honeywell ESYS: black remote control 8.1.1 Introduction The fireplace can be switched ON or OFF by means of the RF remote control. The fireplace operates with a pilot flame that is constantly on whenever the fireplace is switched on. This pilot flame ignites the main burner. The RF remote control offers the opportunity to set the flame height manually. - Page 3 Start screen with standard indication Decrease key Increase key Menu key On-off key 8.1.3 User menu The user menu can be used to choose between Ecowave, manual flame height control or manual temperature control. The clock can also be set using this menu. To activate the Ecowave menu, press the menu button once while on the standard screen.
-
Page 4: Operating The Fireplace
8.1.4 Operating the fireplace. Activate the display by pressing one of the four keys. The following display then appears. You light the fire by simultaneously pressing both arrow keys. The main burner ignites to the maximum flame height. The flame height can then be adjusted between positions 1 and 15 by using the arrow keys. -
Page 5: Replacing Batteries
8.1.5.2 Behaviour Choice Wave In the Installation menu, press key a few times until one of the displays below is shown. The current selected choice (digits) flashes. The digit means: 0: function not active 1: function active, default on when the decorative fire is ignited 2: function active, default off when the decorative fire is ignited 3: function active, on or off equal to the state when the decorative fire was switched off 8.1.6 Replacing batteries... - Page 6 The supplied stones must be distributed evenly across the burner and the bottom of the appliance. One layer of stones should be distributed evenly on the burner surface. The operation levers for the flue gas and air supply valves must be able to move freely. This area must be kept clear of stones.
- Page 7 12.2.2 Screen and keys Screen Manual operation Closed (left) or open fireplace type (right) Atmospheric fireplace is switched on Atmospheric fireplace can be ignited Failure of atmospheric fireplace can be reset (right) Burner off/setting lower (left), burner on/setting higher ignited) An action is in progress (e.g.
- Page 8 12.2.3 User menu The user menu can be used to choose between Ecowave, manual flame height control or manual temperature control. The clock can also be set using this menu. To activate the Ecowave menu, press the menu button once while on the standard screen. The following screen then appears: Two symbols appear: double arrow:...
- Page 9 12.2.5 Resetting a failure. If, on igniting the fireplace, after approximately 50 seconds of sparking no flame can be detected, the fireplace will go into fail condition. The error message “Fxx” appears on the screen. You can now reset the fireplace by pressing both scroll arrows simultaneously. Wait 3 minutes after resetting before igniting the fireplace again.
-
Page 10: Maintenance
13 Maintenance Make sure that the fireplace has fully cooled down before beginning the cleaning of the fireplace and the burner medium. Shut off the gas supply and switch off the electric power. Clean the fireplace and the burner medium using a vacuum cleaner. Maintenance is of utmost importance. - Page 11 14.2 Honeywell ESYS – black remote control The fireplace is controlled by means of a bidirectional communication between the RF remote control and the receiver. Thanks to this, error messages can be displayed on the screen of the remote control. 14.2.1 Examples of error messages: Communication failure between RF remote control and the fireplace.
- Page 12 14.2.2 Registering the RF remote control again in case of lack of communication between the remote control and the receiver: Pull power supply out of wall socket Press the menu key for 10 seconds until the time indication blinks in the left upper corner.
- Page 13 14.2.3 Possible error indications. Code Fout type Oorzaak Oplossing Communication broken between the A break in the cable(s) or a poor connection in the plug(s) Replace the defective cable(s) or plug(s) modules The control has become hotter than 60 The control is in a too hot place (comes into contact with hot Move the control to a cooler environment (ensure °...
- Page 14 Code Fout type Oorzaak Oplossing No flame detection during the start-up No spark: - Defective ignition cable or connection Replace the ignition cable phase - Defective earth or connection Replace the earth cable - Defective pilot flame set or ignition pin Replace the pilot flame set or ignition pin - Defective module Replace the module...
- Page 15 Code Fout type Oorzaak Oplossing Flame detection stops after 30 min. Air in the gas piping Vent the piping Lack of oxygen due to poor flue configuration Remove the baffle (look at the flue configuration Too much draught in the fireplace again) Fit a diaphragm/restriction plate Soiled ionisation pin...
-
Page 16: Fault Reset
14.3 Fault reset. If there is a problem when igniting the fireplace or during operation, the fireplace goes into safety mode. As a result, an error message appears on the screen. You can now reset the fire by pressing both arrow keys simultaneously. After resetting, wait for 3 minutes before trying to re-ignite the fire.
