  • Page 1 FS OVEN SERVICE MANUAL...

  • Page 2: Table Of Contents

    1.COVER 2.INDEX 1. COVER 2.INDEX 1.COVER ............................2 3. SAFETY WARNING .......................... 4 3.1 G ............................4 ENERAL AFETY 3.2. S ........................4 AFETY FOR ONFİGURATİONS 3.3 I ........................4 NFORMATİONS FOR ONSUMER 4. TECHNICAL SPECIFICATIONS ......................6 5. PRODUCT ASSEMBLY/ ASSEMBLY RULES/ SETTINGS ............... 7 5.2 U ..........................
  • Page 3 10.2.2 Oven does not work,oven lamp does not light, ................. 34 10.3 T ..........................35 ERMOSTAT AULT 10.3.1 Furnace runs continuosly,the thermostat is not tripped............35 11. COMPONENT ASSEMBLY / DEMONTAJ USED EQUIPMENT ............36 12. COMPONENT ASSEMBLY / DİSASSEMBLY ..................37 12.1 R ......................

  • Page 4: Safety Warning

    3. SAFETY WARNING This section contains safety instructions that will help protect from risk of personal injury or property damage. Throughout this service manual the following symbols are used. Important information or useful hints about usage. Warning for hazardous situations with regard to life and property. Warning for electric shock.
  • Page 5  Do not heat the closed preserve jar or can with the product. Presure may cause the explosion.  Do not clean while the product is working.  Do not change in anything on the porduct or any repair instead of some problems in the user guide.

  • Page 6: Technical Specifications

    4. TECHNICAL SPECIFICATIONS Please e-library of product specific technical specifications of the product by going under or see manusoft.

  • Page 7: Product Assembly/ Assembly Rules/ Settings

    5. PRODUCT ASSEMBLY/ ASSEMBLY RULES/ SETTINGS 5.1 Product Transportation To carry or move the product, do not use door or handle of the product. Door, handle or hinges can be harmed. Product should be carried by two person for safety of the product and ergonomics When the product is being carried or the product is being put to the ground, do not put it keenly, do not drag it and do...

  • Page 8: Unpacking Product

    5.2 Unpacking Product To consider product changing in the mounting process, please do not harm package, product and the product package when extracting. Extract package with a knife without harming top and bottom carton. Take the top carton. Take lathes on the product’s front and behind sides, like shown in below.

  • Page 9: Controlling The Setup Place And Energy Sources

    Take stripers which are left and right side of the products. Symbols on the package of the products and meaning of them; Do not carry Carry the product Carry with Preserve the product in this way by Do not step on Fragile barrow in from damp...
  • Page 10 • It can be used with cabinets on either side but in order to have a minimum distance of 400mm above hotplate level allow a side clearance of 65mm between the appliance and any wall, partition or tall cupboard. • It can also be used in a free standing position.

  • Page 11: Control Of The Electrical Installation

    The appliance corresponds to device class 1, i.e. it may be placed with the rear and one side to kitchen walls, kitchen furniture or equipment of any size. The kitchen furniture or equipment on the other side may only be of the same size or smaller.
  • Page 12 Products for the control system according to the available measuring device called wattmeter. Wattmetre Products Wattmeters plug plug in plug and wattmeter. Refer to the location where you want to measure the oven.

  • Page 13: Electrical Connection

    Related position that many volts wattmeter screen check. 5.4 Electrical connection Before starting any work on the electrical installation, disconnect the product from the mains supply. Connect the product to a grounded outlet/line protected by a fuse of suitable capacity as stated in the "Technical specifications"...

  • Page 14: Setting Foot Oven

    Setting Foot Oven Goods received at the base of the hair depends on the plastic feet are 4 screw. Product is out of whack at your feet during use of the product may result in the overthrow of the containers on rocking. To prevent such dangerous situations and balanced on the feet of the product should stop.

  • Page 15: Use Of Products

    6.USE OF PRODUCTS 6.1 Time settings (adora timer) Function knob Thermostat knob PS: Before you can use the oven, the time must be set. If the time is not set, oven will not operate. 6.1.1 First Time Setting Symbols used in Clock Display; Program key Cooking time End of cooking time...

  • Page 16: Display Brightness Adjustment

    When setting items on that screen time transactions must be made within 3 sec. Otherwise, the display will return to the first image. Settings button Program key Plus key Minus key With the time of day 3 or 4 button set. If not set the time of day from 12:00 time setting will begin to rise.

  • Page 17: Alarm Sound Setting

    Violence program for setting the alarm sound by pressing the alarm sound volume adjustment, activate the symbol. 6.1.3 Alarm Sound Setting (+) And (-) keys to set the desired intensity using. The display of the selected alarms sound of violence «b-01" or «b-02" or «b-03" would appear The selected display brightness tray "d-01", or "C-02"...

  • Page 18: Key Lock Setting

    6.1.4 Key Lock Setting The key lock feature prevents the use of the watch using the key. After the keypad lock is set "On" is displayed and the key lock symbol will remain lit. Key to Unlocking the No. 1 key lock symbol by pressing Activate.

  • Page 19: Setting The Alarm Clock

    4 Turn the key and the key lock disabled. The display shows "OFF" will appear. Power outages will be canceled if the key lock settings. You need to do the reprogramming. 6.1.5 Setting the Alarm Clock Product clock cooking program be used for any other warning or reminder. Alarm clock, does not have any effect on receptor oven.
  • Page 20 (-) And (+) key using the set alarm time. After you set the alarm time, alarm time remains illuminated After completion of the alarm time, alarm time symbol starts flashing and the alarm sounds. You can stop the alarm by pressing any key.

  • Page 21: Changing The Time Of Day

    6.1.6 Changing the time of day The time of day by pressing the program time of day you activate the symbol. (-) And (+) buttons to set the time of day using. Important: In case of power failure time of day settings will be canceled. Re-adjustment must be made...

  • Page 22: By Products/Products Labels Used

    7.BY PRODUCTS/PRODUCTS LABELS USED 7.1 PeripheralAccessories Oven Tray Used for pastries, frozen foods and big roasts. Cake Tray Used for pastries such as cookies and biscuits. Wire Grid Used for roasting and for placing the food to be baked, roasted or cooked in casserole dishes to the desired rack.

  • Page 23: Tags And Descriptions Used In The Product

    7.2 Tags and Descriptions used in the product 7.2.1 Type the label Given information on the product nameplate label on the product gas. Sticker on the location; According to the type of product, or the product can be seen in the front door or the rear wall of the lower lid is opened.

  • Page 24: Energy Label

    7.3.3 Energy Label; Product energy label product energy class, the label shows the volume of the product.
  • Page 25 Energy Label lacatıon; Energy label products are in a group of periodicals.

  • Page 26: Genarel Working Principle

    8. GENAREL WORKING PRINCIPLE Oven functions work normally, walkable oven cooking mode. In this mode, the plug is inserted into the oven starts for the first time. Normal operation mode, the following functions are working. Statıc Statıc + fan Multi (3D) Pizza Grid+fan Grid...
  • Page 27 Top and bottom heating Top and bottom heating are in operation. Food is heated simultaneously from the top and bottom. For example, it is suitable for cakes, pastries, or cakes and casseroles in baking moulds. Cook with one tray only. Bottom heating Only bottom heating is in operation.

  • Page 28: Component Of List / Component Working Principles

    9. COMPONENT OF LIST / COMPONENT WORKING PRINCIPLES 9.1 Components Technical Data Components Power Lower resistance 1200 W Turbo resistance 1800 W Upper resistance / statıc 1100 W Gril resistance 2200 W Gril + upper resistance (1100+1100) 2200 W Turbo motor 22-26 W Lamp 15-25 W...
  • Page 29 Clemens Connects to the wires in the mains cord and the oven element. Distributed to the cable clamp components inside the oven. Turbo Motor Turbo and multifunctional oven is defrosting works alone. Turbo working positions with resistance, heat resistance turbo fan properly into the oven via the corporate network. Oven Lamp Depending on the control button or a separate button commutator and the furnace is controlled with the help illuminate the inside of the chassis.
  • Page 30 Commutator Electric, turbo and multifunctional ovens, heaters, hotplate, oven lamp, fan motor, chicken roasting in the oven, such as engine components, optionally allows you to run. Is dependent on the control button works with their movements. Thermal cut out The purpose of the thermal cutter or on the furnace when the thermostat shorted as a result of any short circuit of the heater in case of continuous operation of the furnace temperature does not exceed a certain value used to phase or neutral cutting purposes.
  • Page 31 Energy Regulator Hob and Grids are used to run. There is a bimetal contact structure therein. The component according to translate on the tray of the bimetal thereby opening and closing contacts of varying the spacing may be made endless in the tray opening-closing range. On the component contains one independent signal lamp foot.

  • Page 32: Flow Fault / Fault Detection Diagrams

    10. FLOW FAULT / FAULT DETECTION DIAGRAMS 10.1.Resistance Faults 10.1.1 Resistance does not work;the food is not cooked...

  • Page 33: Lamp Fault

    10.2 Lamp Fault 10.2.1 Furnace is working but the oven does not illuminate...

  • Page 34: Oven Does Not Work,Oven Lamp Does Not Light

    10.2.2 Oven does not work,oven lamp does not light,...

  • Page 35: Termostat Fault

    10.3 Termostat Fault 10.3.1 Furnace runs continuosly,the thermostat is not tripped.

  • Page 36: Component Assembly / Demontaj Used Equipment

    11. COMPONENT ASSEMBLY / DEMONTAJ USED EQUIPMENT Cordless Screwdriver Cape Crow Nippers...

  • Page 37: Component Assembly / Di̇sassembly

    12. COMPONENT ASSEMBLY / DİSASSEMBLY NOTE: The following components disassembly operations in reverse order.Component Apply installations 12.1 Replacement the upper flammable Product top view To remove the upper flammable greenhouse glass products glass group that connects to the rear wall screws, one is located in the right and left. Remove the screws with a screwdriver.

  • Page 38: Replacement The Control Panel

    Begin gently lift it up from the rear tray and pushing forward the panel located on the burner plate recover from two sets of quotation marks. 12.2 Replacement the control panel Pull out all the buttons on the dashboard. Remove the upper flammable table. The control panel located on the right and on the left side of the star-tipped screwdriver and unscrew the 2 screws.
  • Page 39 Open the front door of the oven. The control panel is located under the right and left Unscrew the two screws. 39 | EN...

  • Page 40: Replacement The Oven Door

    Behind the dashboard clock (clock models), all cables that are connected to the socket grabbed Switches remove. Taps that are installed on your switch gently pull it toward you. 12.3 Replacement the oven door Open oven door. 0pen clips which are located left/right side of the door by pushing them. 40 | EN...

  • Page 41: Replacement The Door Hinge

    12.4 Replacement the door hinge Initially, this is necessary to remove the side walls. After removing the front cover hinges on the side by 2 Remove the screws with a screwdriver. Pull the hinge slot. 41 | EN...

  • Page 42: Replacement The Room

    12.5 Replacement the room Pull and remove the drawer. Remove the screws that are on the right and left side to take the inner part of the drawer. 42 | EN...

  • Page 43: Replacement Of The Door Seal

    12.6 Replacement of the Door seal Remove door seals from the hales which are on the cavity. 12.7 Replacement of the ring heater and Fan Protector Sheet Remove ring heater connections. Unscrew fan protector. 43 | EN...
  • Page 44 Unscrew 2 screw that connects ring heater to cavity. 44 | TR...
  • Page 45 Take the ring heater from the cavity plug in the new heater according to electrical instructions. 45 | TR...

  • Page 46: Replacement Of The Fan Blade

    12.8 Replacement of the Fan Blade Unscrew the nut on the fon with nippers. 12.9 Replacement of the grill heater Firstly remove top and back wall of the oven; Unplug the heater connectios. Unscrew the two scews that connect heater to cavity. 46 | TR...
  • Page 47 Open the oven door and unscrew the screws that connect heater to top wall. Remove the grill heater that swings freely. Replace the heater with the new one according to electrical instructions. 47 | TR...

  • Page 48: Replacement The Oven Bottom Heater

    12.10 Replacement the oven bottom heater Before you the lower ground floor of this process of sheet removal and the opening of the relevant portion of glass wool is required. Resistance to ground connecting sheet is attached with 2 screws. Unscrew the screws with a screwdriver.

  • Page 49: Replacement Of The Thermostat Bulb

    12.11 Replacement of the Thermostat Bulb Thermostat bulb is placed on the right top of the rear wall of the cavity.To reach thermostat bulb,upper and rear cover sheets should be demounted unscrew the screw of bulb support sheet. 49 | TR...

  • Page 50: Replacement Of The Fan Motor

    12.12 Replacement of the fan motor Firstly remove the back wall and fon protector; Unplug fan motor’s connections. 50 | TR...
  • Page 51 Unscrew the nut on the fon with nippers. 51 | TR...

  • Page 52: Replacement Of The Signal Lamp

    Unscrew three screws that connect fan motor to cavity. Plug the new motor according to electrical instructions 12.13 Replacement of the signal lamp Firstly remove the burner plate. Depends on the signal lamp socket, plug socket, remove the signal lamp behind the dashboard.

  • Page 53: Replacement Of The Oven Lamp

    12.14 Replacement of the oven lamp Rotate the illumination glass counterclockwise to replace just the lamp. Replace the lamp with the new one. 12.15 Replacement of the oven lamp square Before this procedure the oven wire racks, glass wool and lamp electrical connections must be removed Nails the lamp by pressing square outside the chassis frame in the frame edges to hold the broken glass is pushed towards the drinker...
  • Page 54 Remove the space where the glass into the frame by pulling Insert the cables before inserting the glass again, and then make sure that the glass is seated on the slot snaps nails. 54 | TR...

  • Page 55: Replacement Of The Glass Wool

    12.16 Replacement of the Glass Wool For this operation must remove the first side walls and the rear housing Disconnect the frame wire around the wire wrapped with glass wool. Glass wool loose change with a new one. 12.17 Replacement of the Sides Rock Remove side rocks from the cavity by saving balts.

  • Page 56: Replacement Of The Side Rock Screw

    12.18 Replacement of the side rock screw Rotate the side rack screw mounted on the side Wall counterclockwise and replace with the new one. 56 | TR...

  • Page 57: Replacement The Turbo Heating Elements

    12.19 Replacement the turbo heating elements Initially, this fan guard sheet, the sheet rear enclosure of the furnace must be disassembled. Resistance of the cables connected to the turbo behind the bakery at the base to remove. 57 | TR...
  • Page 58 Turbo resistance Unscrew the two screws holding the star-tipped screwdriver. Idle in the oven is plugged turbo pulling resistance, remove it from the slot. 58 | TR...

  • Page 59: Replacement Of The Back Wall

    12.20 Replacement of the Back Wall Unscrew the back wall. 59 | TR...

  • Page 60: Replacement Of The Terminal Box

    12.21 Replacement of the Terminal Box Oven before performing this operation is necessary to remove the rear housing the sheet. Terminal connected to the protective plastic tab located on the top portion of the sheet you save. 60 | TR...

  • Page 61: Replacement Of The Side Wall

    Terminal 30 degree angle upward, keeping your interests. 12.22 Replacement of the Side Wall Before replacing the top cover side wall of the oven, cook top, rear enclosure and control panel disassembly is required. On the back, the side wall of the product with the help of tip screwdriver remove the screws.
  • Page 62 On the front of the product, the side wall with the help of the front strut connecting the tip screwdriver remove the screws on the upper side. On the front of the product, the side wall of the lower part of the front strut connecting the star-tipped screwdriver to remove the screws Before you leave the range of 30 degrees from the rear of the side wall of the oven...
  • Page 63 ling upwards at the rear of the side wall of the furnace and disconnect the front of the upright nails. 63 | TR...

  • Page 64: Replacement Of The Oven Si̇de Wall Decors Sheet

    12.23 Replacement of the oven side wall decors sheet Side wall of the oven must be dismantled before beginning this operation. The side of the side wall decor plate with the help of tip screwdriver remove the screws. 64 | TR...
  • Page 65 The tabs on the side wall on the side of the side wall decor wall plate.Disconnect remove the upward direction 65 | TR...
  • Page 66 66 | TR...

  • Page 67: Remove Upper Glass

    12.24 Remove Upper Glass oven top view Greenhouse glass sheet with connection to the oven body is screwed. Keep tip screwdriver in connection with the help of screws remove. 67 | TR...
  • Page 68 Greenhouse glass as shown in the picture before the forward. Then lift it upwards. Grounding cable is connected to the greenhouse glass. Pull the cable. 68 | TR...

  • Page 69: Replacement Of The Hotplate

    12.25 Replacement of the hotplate Remove the four nuts which connected the cooktop. Remove the cable connections and nut. 69 | TR...
  • Page 70 Replace with new one 70 | TR...
  • Page 71 71 | TR...
  • Page 72 72 | TR...
  • Page 73 73 | TR...

  • Page 74: Exploded View

    13. EXPLODED VIEW Product exploded pictures are available by e-library or manusoft. 74 | TR...

  • Page 75: Service Part List

    14.SERVICE PART LIST Product service parts list can be accessed from the e-library or manusoft. 75 | TR...
  • Page 76 Envelope IV 76 | TR...
