- Page 1 HG-400W HEAT GUN...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS Warnings: • Read instructions before use. • Disconnect cylinder when not in use. • DO NOT refill, ignite or use near open flame, heater, furnace or • Keep in a dry place, out of the reach of children. combustible materials. • Never attempt to modify the HG-400W construction and never • KEEP AWAY FROM CHILDREN. use unapproved accessories or fuels. • Use only with hand held propane cylinders specifically designated • Be extra careful when using outdoors on windy days. Wind may for use with torches and other heat tools. carry the heat back towards you or others. • Do not touch the nozzle cover during use, or before sufficient time • Never leave the HG-400W unattended when lit. has passed for cooling. • If your HG-400W malfunctions do not try to repair. Contact your • Always be sure the unit is cool, before storing. dealer or online support for help.
- Page 3 DESCRIPTION HOW TO USE HEAT GUN HG-400W (4) CONNECTING TO CYLINDER Heat Sink Control / Ignition Button Cage 1. Ensure that the Control/Ignition Button (2) is turned off (turned fully clockwise). 2. Keep the propane cylinder upright when fitting it to the heat gun valve. 3. Place the heat gun valve on top of the disposable propane cylinder valve. (Fig. 1) Propane 4. Gently screw the propane cylinder into the Cylinder valve. Be careful not to cross-thread the heat gun to the cylinder. CAUTION: Screw on hand tight only. Do not Hand Fig.1...
- Page 4 • Depending on conditions it may take up to 3 pushes of the Control/ IGNITION Ignition Button to ignite. • Full power should be achieved with Control/Ignition Button opened • Always point the burner away from your body and any flammable or approx. 1/2 turn, but this may vary depending on the ambient combustible objects. temperature and contents of the propane cylinder. • The heat gun has a built-in Hand Protector/Vertical Stand (3) that 1. T urn the Control/Ignition Button counterclockwise approx. 1/4 allows for use in the nozzle-up position. (Fig. 2) turn to open the valve. Control / Ignition 2. Press and release the Button Ignition Button to ignite the heat gun flame. You should hear a loud "WOOSH" sound which indicates that the heat gun is ignited and hot. Fig.2...
- Page 5 ATTACHMENTS TROUBLE SHOOTING • Deflector Nozzle is used for Heat Shrink Tubing and other similar • To reduce the risk of personal injury, property damage, or damage products. to your HG-400W, do not attempt to repair the unit body. • Heat Spreader can be used for applying heat activated films, shrink wraps, removing paint, caulking, and other materials. SPECIAL WARNING • This product, when used for soldering and similar applications, produces chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. • Department of Transportation Hazardous Materials Regulations forbid the carriage of butane or other flammable gas products on passenger aircraft. Do not pack this item or any other flammable gas item, in any checked or carry-on baggage. Deflector Heat Nozzle Spreader...
- Page 6 SPECIFICATIONS Dimensions Length 225 mm (8.6 inches) Width 53 mm (2.1 inches) Height 122 mm (4.8 inches) Weight 485 g Fuel Butane Operating Time Approx. 160 minutes per cylinder Nozzle Air Temp. ≈ 932 °F (500 °C) (One inch from heat outlet) Patent Design of the head of Heat Gun WARNING: HG-400W may be used with US 1" Thread Propane Cylinder -Use outdoors only or use in well ventilated areas. -Read the instructions before using the appliance. (CGA600 Valve) CAUTION: -Accessible parts may be very hot. Keep young children away from the appliance.
- Page 7 www.pro-iroda.com...
