- Page 2 IMPORTANT SAFETY • Be extremely careful as torch flame tip temperature is over 1300°C INSTRUCTIONS (2400°F) • Be extremely careful as torch flame is almost invisible in daylight or Warnings: under strong light. • Unit uses flammable gas (Butane) under pressure – use with care. • Use Safety Glasses. • DO NOT expose to heat above +50°C (120°F) and avoid prolonged • Do not touch the heated tip of the unit. exposure to the sun. • DO NOT leave unit unattended when operating or hot. • DO NOT puncture or incinerate. • Always be sure unit is cool before storing. • DO NOT refill, ignite or use near open flame, heater, furnace or • DO NOT replace cap without switching unit off and ensuring tip has combustible materials. cooled. • Keep work area clean. Cluttered areas and benches invite injuries. • If your torch malfunctions do not try to repair. Contact your dealer • KEEP AWAY FROM CHILDREN. Visitors should be kept away from or online support for help. work area. • Butane-Propane mix or other fuel could create much higher • Store in dry, locked cabinet out of reach of children.
- Page 3 DESCRIPTION ON/OFF Ignition Switch Soldering Knurled Gas Tank Filling Valve Tip Assembly Gas Control Lever...
- Page 4 HOW TO USE THE IGNITION SOLDERPRO 90K 1. Set Gas Control Lever at mid position to start the flow of gas.( Fig.2) REFILLING 2. As gas is flowing, slowly slide up the ON/OFF Fig.1 • Use only high-quality butane gas. Ignition Switch toward the tip till you hear a click. (Fig. 2b) • Refill in a well-ventilated area away from any ignition source and other people. 3. The automatic ignition will light the torch and the tip housing will start to glow red. 1. Hold butane canister upside down when filling (Fig.1) Fig.2 4. To turn off, slide the Gas Control Lever left towards 2. Firmly press canister nozzle into Gas Filling Valve. Fig.1 the OFF position. 3. Release canister when gas starts to overflow. (Gas overflow during refilling is normal and does not indicate a leak) 4. Wait for a few minutes before use.
-
Page 5: Temperature Adjustment
IGNITION WARNINGS TEMPERATURE ADJUSTMENT • Do not touch Tip, Tip Housing or Knurled Nut while igniting. (Fig. 3) • The tip temperature can be adjusted by turning the Gas Control Lever left or right. (Fig. 5) • Do not ignite torch when Tip Assembly is not screwed on. (Fig. 4) • Set to mid-position when soldering or brazing. • Excessive gas flow, flare-up or catalyst pulsing red may occur when the Gas Control Lever is set too high. Fig.5 Mid-Position Fig.3 Fig.4... - Page 6 CHANGING TIPS CLEANING 1. Be sure the tip has cooled before removal. • Use only mild soap and a damp cloth to clean the housings of the Knurled tool. Many household cleaners contain chemicals which could 2. Unscrew Tip Assembly with a seriously damage the plastic. Also do not use gasoline, turpentine, counterclockwise motion. (Fig. 6) Pliers may lacquer or paint thinner, dry cleaning fluids or similar products. be required to lightly grasp the Knurled Never let any liquid get inside the tool; never immerse any part of Nut in order to loosen the tip. the tool into a liquid. 3. Replace with desired tip. Be careful not to overtighten as this could damage the thread in the cap. WARNING: The catalyst inside the soldering tip is very delicate and will not sustain mechanical abuse without serious damage. Fig.6...
-
Page 7: Troubleshooting
TROUBLE SHOOTING SPECIAL WARNING • To reduce the risk of personal injury, property damage, or damage • This product, when used for soldering and similar applications, to your SOLDERPRO 90K, do not attempt to repair the unit body. produces chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. PROBLEM PROBABLE CAUSE HOW TO CORRECT Does not a. Empty Gas Tank a. Refill with butane fuel • Department of Transportation Hazardous Materials Regulations ignite forbid the carriage of butane or other flammable gas products on b. Too high or low fuel b. Adjust control lever to a pressure higher or lower position. passenger aircraft. Do not pack this item or any other flammable c. Pushing on/off ignition c. Re-read IGNITION steps gas item, in any checked or carry-on baggage. switch too fast. Low gas a. Cold fuel a. Hold body in hands to pressure or allow unit to warm up. -
Page 8: Specifications
SPECIFICATIONS Operating Time Mid Setting / One Gas Filling 53 min. Length W / Cap 198 mm (7.8 inches) Heat Up Time Working Temperature 17 seconds W / Soldering Tip 189 mm (7.4 inches) Width 22 mm (0.9 inches) Height W / Stand 40 mm (1.6 inches) W / O Stand 27.5 mm (1.1 inches) This appliance may be filled with any cartridges marked Weight Empty Fuel Tank 63 g ± 2 g “Butane” complying with EN 417. Watt 25 W - 80 W Warning: -Use outdoors only or use in well ventilated areas. -Read the instructions before using the appliance. Approximate Soldering Tip ≈ 752 ℉ (400 ℃) CAUTION: Temperature Hot Knife ≈ 752 ℉ (400 ℃) -Accessible parts may be very hot. Keep young children Heat Blower ≈ 1300 ℉ (650 ℃) away from the appliance. Capacity Gas Container 12 ml (0.41 oz) - Page 9 www.pro-iroda.com...
