2.6 Front Control Panel

JF1 contains header pins for various buttons and indicators that are normally located on a
control panel at the front of the chassis. These connectors are designed specifically for use
with Supermicro chassis. See the figure below for the descriptions of the front control panel
buttons and LED indicators.
LEDM1
1
JSDCARD1
USB4(3.0)
USB2/3
JSTBY1
JSD1
JSD2
SATA7
JL1
JF1
LE1
JUIDB1
BMC
M.2
BT1
JBT1
BIOS
X11DPL-i
DESIGNED IN USA
REV:1.01
PCH
SP1
JRK1
FAN4 FAN3
JWD1
JPME2
Figure 2-3. JF1 Header Pins
1
Power Button
Reset Button
3.3V
UID LED
3.3V Stby
3.3V Stby
3.3V Stby
3.3V
x
NMI
19
JLAN1
FAN5
LAN1/2
USB0/1
IPMI_LAN
CPU2
BIOS LICENSE
CPU1
2
Ground
Ground
Power Fail LED
OH/Fan Fail LED
NIC2 Active LED
NIC1 Active LED
HDD LED
PWR LED
x
Ground
20
41
