Installation Instructions
Original Instructions
CIP Safety Encoder
Bulletin Number 843ES
Topic
ATTENTION: Do not attempt to install this device unless the
installation instructions have been studied and understood. This
document acts as a guide for a typical installation.
Introduction
Use this publication when an application includes the Bulletin 843ES
CIP Safety™ Encoder. This publication is to help with proper
installation of the CIP Safety encoder. It provides publication
references and guidelines, product specifications, technical data, and
cabling recommendations.
It is required that installation is in accordance with these instructions
and implemented by qualified personnel.
Technical Specifications
This device is intended to be part of the safety-related control system of
a machine. Before installation, a risk assessment must be performed to
determine whether the specifications of this device are suitable for all
foreseeable operational and environmental characteristics of the
application. See
Specifications on page 1
and ratings.
Use appropriate screws, bolts, or nuts that are fitted by tools to mount
the flange of the encoder to avoid the risk of tampering. Do not over
torque the mounting hardware.
Page
1
1
1
2
3
5
6
6
6
for certification information
Product Overview
The Bulletin 843ES CIP Safety encoder is a SIL 3, PLe rated safety
encoder that complements the Integrated Architecture® system by
monitoring drive safety applications as a safety connection directly on
an EtherNet/IP™ network. The networked position-tracking device on
EtherNet/IP provides data to the safety controller via CIP Safety. The
Bulletin 843ES encoder was designed to help simplify safety
applications with the use of controller-based monitoring functions.
This encoder helps make it easier to achieve the desired safety integrity
level (SIL) or Performance Level (PL) because it allows the
GuardLogix® 5580 or Compact GuardLogix 5380 safety controllers to
monitor position and velocity input values directly.
Specifications
Table 1 - General Specifications
Attribute
All Cat. Nos.
Safety Ratings
Cat. 3, HFT = 1
System structure
2 channels (Cat. 3)
Safety functions according to IEC 61800-5-2
Standards
PLe according to ISO 13849-1, ISO 13849-2
Safety Classification
SIL 3 per IEC 62061, IEC 61508, and IEC 61800-5-2
Functional safety data
PFH
= 8.03E-9 (average frequency of a dangerous failure per hour)
d
CE Marked for all applicable directives, c-UL-us (UL 61010), and TÜV,
Certifications
see
rok.auto/certifications
Mission time
20 years
Diagnostic coverage (DC)
≥99%
Error presumptions
IEC 61800-5-2
Operating Characteristics
Supply voltage
10...30V DC (±5%), IEC 61140 PELV power supply, UL 1310 Class 2
Power consumption, max
3 W
No-load supply current
300 mA (at 10V DC)
Load current, max
300 mA
Inrush current, max
1.5 A (at 1 ms)
Communication rate
10/100 Mbit/s
