  • Page 1 Operating Manual Profibus interface for the PME MP70DP MP70DPS7, MP70S7 A0658-7.3 en...

  • Page 3: Table Of Contents

    ......General information about the MP70DP and its variants ..
  • Page 4 PME-MP70DP 10.1.2 Parameters for module MP01 ......10.2 PROFIBUS configuration ....... . .

  • Page 5: Safety Instructions

    Intended use The MP70DP module with connected transducers is to be used exclusively for measurement tasks and directly related control tasks. Use for any purpose other than the above is deemed to be non‐designated use.
  • Page 6 General dangers of failing to follow the safety instructions The MP70DP module is a state of the art unit and as such is failsafe. The device may give rise to residual dangers if it is inappropriately installed and operated by untrained personnel.
  • Page 7 PME-MP70DP Any risk of residual dangers when working with the MP70DP is pointed out in these instructions by means of the following symbols: WARNING Symbol: Meaning: Dangerous situation Warns of a potentially dangerous situation in which failure to comply with safety requirements can lead to death or serious physical injury.
  • Page 8 Greenline shielding concept (place the shield of the transducer cable onto the connector housing). The cables of the MP70/MP70DP digital inputs and outputs that are used should not be longer than 30 meters and should not exit the building in which the system is located.
  • Page 9 PME-MP70DP Conversions and modifications The MP70DP module must not be modified from the design or safety engineering point of view except with our express agreement. Any modification shall exclude all liability on our part for any damage resulting therefrom. In particular, any repair or soldering work on motherboards is prohibited.

  • Page 10: Introduction

    D MP70DP D MP70DPS7 D MP70S7 MP70DP The MP70DP module is a PROFIBUS DP Gateway for the amplifiers of the PME product family. Up to 8 measurement modules (MP01, MP30, MP55, MP60) can be connected to the gateway. Communication between the MP70DP PROFIBUS DP Gateway and the modules is handled by an integrated CAN interface.
  • Page 11 No function The MP70DP module is set up and parameterized via a keyboard and display, or by using the PME Assistant. The PME Assistant provides a user‐friendly interface under Windows for parameterizing the modules (described in the Online Help of the PME Assistant program).

  • Page 12: Selecting Amplifier Settings With Dip Switches

    PME-MP70DP Selecting amplifier settings with DIP switches NOTE The DIP switches must be set or changed before mounting the PME. The different settings are defined with the DIP switches and can be read out over the display (see chapter 7). These are the settings for synchronization, bus termination resistor To set the DIP switches, proceed as shown in Fig.
  • Page 13 PME-MP70DP Factory settings: Analog output 1 2 3 For module MP70S7: 1 2 3 4 5 6 3 4 5 6 3 4 5 6 Synchronization Analog output Amplifier type WARNING The switch positions must not be changed! for MP70DPS7 and MP70S7 only...
  • Page 14 PME-MP70DP Analog output Synchronization "10 V 1 2 3 4 5 6 1 2 3 Master 1 2 3 4 5 6 "20 mA 1 2 3 4 5 6 Slave 1 2 3 1 2 3 4 5 6 4...20 mA...

  • Page 15: Mounting/Dismounting Mp70Dp

    PME-MP70DP Mounting/dismounting MP70DP Fig. 3.1: Mounting on a support rail Fig. 3.2: Dismounting ATTENTION The support rail must be connected to grounded conductor potential A0658-7.3 en...

  • Page 16: Connecting Several Modules

    Fig. 3.4: Connecting a flat ribbon cable Several measurement modules (MP01, MP30, MP55, MP60) can be connected to the MP70DP via a flat ribbon cable. This cable provides the local supply voltage connection and synchronization between the modules. No more than eight modules should be interconnected via a flat ribbon cable.

  • Page 17: Connection

    Comply with the safety instructions before starting up the device. NOTE Use standard HBM cables for connecting the transducers. When using other shielded, low‐capacitance measurement cables, attach the shield of the transducer cable to the connector housing in accordance with the HBM Greenline concept (HBM Greenline Information, document i1577).

  • Page 18: Supply Voltage And Control Inputs/Outputs

    PME-MP70DP 4.2 Supply voltage and control inputs/outputs With the MP70DP, two removable plug terminals are available for connection, and with the S7 versions, there are four plug terminals. Connecting the voltage WARNING supply: The MP70DP module must be connected to an external...

  • Page 19: External Supply Voltage For Control Outputs

    PME-MP70DP Control inputs and control outputs are available for the MP70DPS7 and MP70S7 variants: 4.2.1 External supply voltage for control outputs Example: PLC connection MP70 module Relay max. 0.5 A max. 0.5 A OUT3 OUT1 24 V 24 V* 0 V*...

  • Page 20: Can Interface

    The CAN Bus needs a termination resistor of 120 Ω in the first and last bus nodes. The maximum number of termination resistors the bus line can have is two. A termination resistor is integrated into the MP70DP and MP70DPS7 modules, and is activated by DIP switch S14 (see page 14).

  • Page 21: Synchronization

    PME-MP70DP 4.5 Synchronization Synchronization is recommended when D the transducer cables of several devices run side by side D the measuring points are unshielded and are close together Synchronization prevents differences in the carrier frequency causing disturbing superpositions. Slave Master...

  • Page 22: Guide For Connection To A Plc

    1. Mechanically connect the device to the PROFIBUS (see page 25 and page 18) 2. Set the PROFIBUS address on the device (the HBM “PME Assistant" software can also be used for this). 3. Configure and parameterize the PROFIBUS telegram with a configuration tool (such as Step7) and GSE files, or manually, in accordance with chapters 10.1 and 10.2.

  • Page 23: Configuration And Parameterization

    • Start your configuration program (e.g. Step7; if you do not have a configuration program, proceed as in chapter 10.2) • Load the HBM GSE file (the PME system CD includes GSD/GSE files for the PME) • Add an HBM device from the hardware catalog •...
  • Page 24 PME-MP70DP • Double‐click the configured entries to open the properties window and select the required parameters. Fig.5.3: Setting parameters Notes for Simatic S7 PLC users: • To transmit consistent data of 3 bytes or over 4 bytes, you must use special function block SFC14 to read and SFC15 to write.

  • Page 25: Starting Up

    MP70DP (see Fig. 4.5, page 20). This establishes the supply voltage connection, the CAN Bus connection and the synchronization connection between the modules. D Connect the MP70DP to the 24 V supply voltage as described in chapters 4.2, and use the keyboard to set the required PROFIBUS address. ATTENTION...
  • Page 26 D Connect the PROFIBUS line to the PROFIBUS connector on the front of the MP70DP (see page 19). Make sure that that the 120 Ω line termination resistor is connected on the first and last bus nodes (there is usually a slide switch on the PROFIBUS connector housing for this).

  • Page 27: Setting And Operating (Mp70Dp)

    PME-MP70DP Setting and operating (MP70DP) 7.1 Operating philosophy Display in measuring mode: Measured value -18.0024 Status field Unit ↓ ↑ Flashes in the status field if the parameter value can be edited The keys are pressure‐sensitive: Keep key pressed - value runs continuously (press harder = runs faster)
  • Page 28 PME-MP70DP Measuring mode Password status inactive (factory setting): Password status active 2 secs 2 secs DIALOG PASSWORD Setting mode Enter password: Password ↓ ↑ Input mode Enter required password (factory setting 0) Confirm Example: Enter numerical Select table value value...
  • Page 29 PME-MP70DP During measurement, if you press , the following will be displayed: 1. display mode 2. status of input and output 3. kinds of error (ERROR) The symbol also appears in the status field. Measured value -18.0024 Status field Unit...
  • Page 30 I.CAN Tare HW‐Vers. MAINGRP I.PrBus PkMomMax I.AddFnc PkHldMax MAINGRP PkMomMin PkHldMin ParaCo1 ParaCo2 InpFunc MAINGRP Preset with DIP switches with , back to group MAINGRP: Depending on the unit chosen For MP70DPS7 and MP70S7 Not for MP70S7 A0646‐6.2 en HBM...

  • Page 31: Setting All Parameters

    ↓ ↑ Flashes, if parameter value can be edited ‰ km/h Back to MAINGRP ft/s press Confirm entry: rad/s Pulses kImp Note: 2 secs Back to measuring mode: If a group cannot be selected, check under DIALOG to establish whether the group is enabled. A0646‐6.2 en HBM...
  • Page 32 Zero V >T< 0.00 Back to MAINGRP ↓ ↑ 10.00 EndV kN volatil ↓ ↑ >T<save save ↓ ↑ 10.00 EndV V Back to MAINGRP Back to MAINGRP Depending on the unit chosen for MP70DPS7 and MP70S7 A0646‐6.2 en HBM...
  • Page 33 Back to MAINGRP ↓ ↑ Off Dlay PkHldMin ParaCo1 Back to MAINGRP ParaCo2 ↓ ↑ The same applies to limit values 2...4 enabled InpFunc locked Back to MAINGRP A0646‐6.2 en HBM Depending on the unit chosen for MP70DPS7 and MP70S7...
  • Page 34 Preset with DIP HW Synchr w. switch switch S10 Master ↑ slow Keyboard fast ↓ ↑ OutpR ms medium ↓ ↑ float PDO‐Frmt int32 HW-Vers Back to Back to MAINGRP MAINGRP A0646‐6.2 en HBM Depending on the unit chosen not for MP70S7...

  • Page 35: Clarification Of Important Parameters

    PME-MP70DP Clarification of important parameters Group Parameter Meaning DIALOG Password Specify (change) password, 0000 - 9999 (factory settings password: 0000) PassStat Specify password status: active = password must be entered; inactive = PME can be operated without entering a password I.ParaS to...
  • Page 36 PME-MP70DP Group Parameter Meaning ANALOG Source Vo The gross or net value, as well as the peak value, can be OUTPUT chosen as the source of the analog signal. Mode Vo Use DIP switches S11 and S5 to specify the signal mode for the analog output.
  • Page 37 PME-MP70DP Group Parameter Meaning LIMIT VAL. Source The choice of source for the limit value signal is: gross, net, 1...4 peak value max/min/peak‐to‐peak SwtchDir Limit value functions and parameters Value Limit1, ON Value Hyst Overshoot Hyst Undershoot Hyst Value Limit2,...
  • Page 38 PME-MP70DP Control inputs and control outputs are available for the MP70DPS7 and MP70S7 versions: Inputs /outputs Plug terminal 3: Here there are 4 inputs available to you for controlling the functions of the PME. Plug terminal 4: Here there are 4 outputs available.
  • Page 39 PME-MP70DP Group Parameter Meaning IN/OUT PkMomMax Peak value operating mode PkMomMin Measurement signal PkHldMax PkHldMin Stored value response Hold Hold Function Mode of Peak value (Store1) Current value operation Current value operating mode Measurement signal Hold Function Mode of Current value operation CAN‐Bus...
  • Page 40 PME-MP70DP Group Parameter Meaning ADDITION >0<Rf Reference zero FUNCTION When zeroing with the remote controls, the analog output is adjusted to 0 V. The display value is adjusted to >0<Ref. StillDsp Standstill indication. If standstill occurs with ON selected, the...

  • Page 41: Can Interface Description

    CAN interface description 9.1 General The MP70DP module has a built‐in CAN interface, which can be used both for transmitting measured values and for module parameterization. Different baud rates can be selected up to a maximum of 1 MBaud. The interface protocol is adapted from the CANopen Standard.

  • Page 42: Parameterization

    Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Writing a parameter: Transmit value (PC or PLC to MP70DP) Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á...
  • Page 43 Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Response in the event of an error when reading or writing parameters: Error acknowledgement (MP70DP to PC or PLC) Á Á Á Á Á Á Á Á Á...

  • Page 44: Object Dictionary: Communication Profile Range In Accordance With

    PME-MP70DP 9.4 Object dictionary: Communication profile range in accordance with CANopen (CiA‐DS301) Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á...
  • Page 45 PME-MP70DP Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Index Sub‐i...
  • Page 46 PME-MP70DP Error code (object 1003HEx): Á Á Á Á Á Á Á Á Á Á Á Á Value Meaning Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á...

  • Page 47: Object Dictionary: Manufacturer-Specific Objects

    PME-MP70DP 9.5 Object dictionary: manufacturer‐specific objects Parameters that make reference to measured values are scaled true to number, and coded as Long (32‐bit integer). The position of the decimal point is defined in object 2120 Hex. Alternatively, these quantities are also available as Float values (IEEE754‐1985 32‐bit format).
  • Page 48 PME-MP70DP Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Index Sub‐...
  • Page 49 PME-MP70DP Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Index Sub‐i...
  • Page 50 PME-MP70DP Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Index Sub‐i...
  • Page 51 PME-MP70DP Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Index Sub‐i...
  • Page 52 PME-MP70DP Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Index Sub‐i...
  • Page 53 PME-MP70DP Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Index Sub‐i...
  • Page 54 PME-MP70DP Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Index Sub‐i...
  • Page 55 PME-MP70DP Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Index Sub‐i...

  • Page 56: Manufacturer-Specific Objects In Float Data Format

    PME-MP70DP 9.6 Manufacturer‐specific objects in FLOAT data format Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á...

  • Page 57: Examples

    PME-MP70DP 9.7 Examples Example 1: Reading the net measured value as a float value via SDO transfer from the amplifier with module address 3. Protocol to the amplifier: Á Á Á Á Á Á Á Á Á Á Á Á Á Á...

  • Page 58: Settings For Profibus

    10.1 PROFIBUS parameterization The amplifier parameters are set using the keyboard or the CAN interface. With the MP70DP, the keyboard must be used to set the PROFIBUS node address. The PROFIBUS DP parameterization telegram defines some of the parameters for DP transmission. If you use PROFIBUS parameterization tools...

  • Page 59: Parameters For Modules Mp30, Mp55, Mp60 And Mp70

    PME-MP70DP 10.1.1Parameters for modules MP30, MP55, MP60 and MP70 Parameter name Possible val­ Default Meaning Zeroing control bit disabled disabled enables functionality for control enabled via output control word Taring control bit disabled disabled enables functionality for control enabled via output control word...

  • Page 60: Profibus Configuration

    10.2 PROFIBUS configuration The configuration defines which data content is exchanged during cyclic data communication. A configuration entry is reserved for each of the modules connected to the MP70DP. The first entry is always reserved for the MP70DP itself. Cfg entry...

  • Page 61: Configuration For Mp01

    PME-MP70DP Limit1 Level at which limit switch 1 responds 2 or 4 bytes Limit2 Level at which limit switch 2 responds 2 or 4 bytes Limit3 Level at which limit switch 3 responds 2 or 4 bytes Limit4 Level at which limit switch 4 responds 2 or 4 bytes 10.2.2Configuration for MP01...

  • Page 62: Cyclic Data Exchange

    PME-MP70DP 10.3 Cyclic data exchange The following data content is exchanged, subject to the configuration: 10.3.1Inputs Measured values Measured values can be transmitted in various realizations. The choice is between the 16‐bit fixed point number format (16‐bit integer in two's complement, decimal place must be known to the reading position) or the 32‐bit fixed point number format (32‐bit integer in two's complement, decimal...

  • Page 63: Outputs

    PME-MP70DP NOTE The status of the MP70DP can be queried via the MP70DP device status. A CAN slave fault can also be detected and indicated after about 10 seconds (bit 14). This bit is also set when a number of errors are present on the CAN Bus.
  • Page 64 0..7 a0(hex) Type information (manufacturer‐specific) 0..7 reserved 0..7 reserved Status of the MP70DP module Measured value overflow Analog output overflow Incorrect scaling Incorrect parameter set Status of limit switch 1 Status of limit switch 2 Status of limit switch 3...

  • Page 65: Parameterization With Decimal And Hexadecimal Values

    PME-MP70DP 10.5 Parameterization with decimal and hexadecimal values If you are using older parameterization tools, the parameter values have to be converted into decimal or hexadecimal values: Parameterization telegram Octet Bits Parameter name Possible values Default Meaning 0..7 reserved do not change...

  • Page 66: Defining Separate Configuration Combinations

    PME-MP70DP 10.5.1Defining separate configuration combinations 9 configuration entries are available in total. The first entry is reserved for the MP70 module, the subsequent 8 entries are assigned to the measurement modules connected to the MP70 module. The special identification format (special format) must be used here.
  • Page 67 PME-MP70DP Configuration for MP01 Configuration of Length of cyc­ Length of cyc­ Cyclical data content manufac­ lical data inputs lical data out­ turer‐specific puts data Byte no. Bit no. (words) (words) 0..7 Module type (MP01) Input values: 1(2) Gross channel 1...
  • Page 68 PME-MP70DP ...Configuration for MP01 Configuration of Length of cyc­ Length of cyc­ Cyclical data content manufac­ lical data inputs lical data out­ turer‐specific puts data Byte no. Bit no. (words) (words) Output values: Control word channel 1 1(2) Limit value level 1 channel 1...
  • Page 69 PME-MP70DP The configuration telegram therefore has the following format: Meaning Permitted values for CFG (hex) byte Header 0xC3..0xC9 (inputs and outputs, 3 - 9 bytes manuf.‐specific data) Length of outputs 0x40...0x48 (outputs of 1 to 9 words) or 0xC0...0xC8 (outputs of 1 to 9 words with consistency) Length of inputs 0xC0 ...

  • Page 70: Error Messages/Operating State (Led)

    PME-MP70DP Error messages/operating state (LED) Depending on the display mode, various error messages can appear on the display instead of the measured value: Signal status (mode) Possible error message HrdwOvfl Grs+Ovfl Init Err - - - - - - -...
  • Page 71 With the “Error at digital output" setting, the error message is displayed at the digital output NOTE The status of the MP70DP can be queried via the MP70DP device status. A CAN slave fault can also be detected and indicated after about 10 seconds (bit 14).
  • Page 72 WT_CONF (waiting for configuration) DATA_EX (cyclic data traffic) ERROR (bus error) The following applies for modules MP70DP and MP70DP‐S7: The LEDs indicate the operating states (ready for measurement, overflow, etc.,) of the module. However, instead of the CAN status (as with MP01, MP30, MP55 and MP60), it is the PROFIBUS status that is displayed.
  • Page 73 PME-MP70DP LED color Status Meaning Remedy Measuring mode Bus mode Flashes Measured value over­ Adapt measuring flow range Restart LCD error Steady Initialization phase: not CAN Bus not ready for Wait light (yet) ready for communication measurement, Calibration error Send the PME to...
  • Page 74 Index PME-MP70DP Index Digital output, 18 DIP switch, 12, 20 Additional functions, 40, 53 Discharge rate, 37 Additional spring, 16 Dismounting, 15 Address, 39 Display adaptation, 49, 50 Amplifier settings, 12 Display mode, 29 Analog output, 11, 13, 14, 18, 36, 51, 56...
  • Page 75 Measuring mode, 20, 28 Module configuration, 66, 67 Reference zero, 40 Module parameters, 59, 60, 61 Remote controls, 38 Mounting, 15 MP70DP , 10 MP70DPS7, 11, 19 Save, 35 MP70S7, 11, 19 Set to zero, 35 Setting , 27 Setting mode, 28...
