AXA Remote 2.0 Manual

You have just acquired a high quality AXA
product. The instructions below must be
followed closely in order to effectively
assemble and operate this product.
310
Implementation:
Centre-pivot roof windows Velux new generation
(letter K) new: GGL MK06
Assembly tools (recommended):
Tape measure, (cordless) drill, screwdriver, Ø 2
mm drill bit, pencil or stiletto, screw ring, hammer,
Torx-TX20 wrench, screw ring and socket wrench
Parts to be used
1. (2x) AAA Batteries
2. (4x) AA Batteries
3. (1x) Closing unit
4. (1x) Cover
5. (1x) Window casing plate
6. (1x) Window plate
3
7
8 9
User manual
Remote control (figure
A
The remote control has 3 buttons: Open, Stop and
Close. When the Open or Close buttons are pres-
sed briefly, the window will fully open or close.
When the Open or Close buttons are pressed
continuously, the window will open or close as
long as the button is pressed. When the Stop
button is pressed, the movement will be stopped.
Always point the remote control at the front of
the closing unit (figure
B
Configuring remote control:
1 Place 2x AAA batteries in the remote control
and 4x AA batteries in the closing unit
(figure ).
C
2 The LED light in the closing unit will come on
for 20 seconds (green). Press the Open button
(top button) on the remote control. The light
will briefly turn off when configuration has
taken place.
48
63
Characteristics
Velux new generation
old: GGL M06
7. (1x) Large casing plate A
8. (1x) Small casing plate A
9. (1x) Connection support SW
10. (1x) Connection support LW
11. (1x) Metal mounting plate
12. (1x) Socket wrench
4
10
):
).
Assembly location:
Stay
min. 55cm, max. 135cm
Outer dimensions window!
The frame is
W
at a slant and
has no sill
W C
Minimum window height: 30 cm.
Maximum range remote control:
distance 10 m.
13. (10x) Screws 4,0 x 40 mm
14. (4x)
15. (2x)
16. (3x)
17. (1x)
2
5
1
13
6
12
14
11
A
Open
Stop
Close
C
D
±40
Window
±32
Window casing
Screws 4,2 x 32 mm
Bolts M4 x 16 mm
Bolts M4 x 12 mm
Remote control
15
16
17
B
