Nature's Generator Elite User Manual

Power pod
Hide thumbs Also See for Elite:
Table of Contents

Advertisement

Quick Links

Download this manual
Nature's Generator
Power Pod Elite
User Manual

Advertisement

Table of Contents
loading

Related Manuals for Nature's Generator Elite

Summary of Contents for Nature's Generator Elite

  • Page 1 Nature's Generator Power Pod Elite User Manual...

  • Page 2: Table Of Contents

    How to Install Your Nature's Generator Power Pod Elite on Top of Nature’s Generator Elite How to Connect Your Nature's Generator Power Pod Elite to the Nature’s Generator Elite How to Maintain and Store Your Nature's Generator Power Pod Elite Troubleshoo�ng Technical Specifica�ons Limited Warranty...

  • Page 3: Important Safety Instruc�Ons

    Do not use near flammable gases or fumes or other apparatus that produces large amounts of heat. Energy and burn hazard Nature's Generator Power Pod Elite has a sealed lead acid ba�ery, which can present a risk of burn from high current because of short-circuit.

  • Page 4: Cau�On

    Stop using the Nature's Generator Power Pod Elite and refer servicing to qualified service personnel under the following condi�ons: • If liquid has been spilled or objects have fallen into your Nature's Generator Power Pod Elite. • If your Nature's Generator Power Pod Elite has been exposed to rain or water.

  • Page 5: Introduc�On

    Introduction Congratula�ons on your new Nature's Generator Power Pod Elite, a great expansion to your Nature’s Generator Elite. Unpacking Your Nature's Generator Power Pod Elite 1. Nature's Generator Power Pod Elite 2. Accessory Box 3. This user guide Visit Naturesgenerator.com for More Information...

  • Page 6: Get To Know Your Nature's Generator Power Pod Elite

    Get to Know Your Nature's Generator Power Pod Elite Front Panel LED Light Button: Press it to show the ba�ery charge level. LED Lights: When facing the front of the Nature's Generator Power Pod Elite, from le� to right: the first light will show green, which indicates a 20% charge.
  • Page 7 Top Compartment Expansion cable: 35 inch long expansion cable. Visit Naturesgenerator.com for More Information...

  • Page 8: Using Your Nature's Generator Power Pod Elite

    3. It takes about 15 to 25 hours to recharge Nature's Generator Power Pod Elite if using 100 wa� solar panel, and also depends on the the strength of the sunlight.

  • Page 9: How To Install Your Nature's Generator Power Pod Elite On Top Of Nature's Generator Elite

    How to Install Your Nature's Generator Power Pod Elite on Top of Nature’s Generator Elite What is in the accessory box 1. Brackets 2. Bolts and nuts A: 16mm x 2pcs B: 25mm x 2pcs 3. Power Pod Elite Bar 4.
  • Page 10 Installing Procedures Step 1: Li� Nature's Generator Power Pod Elite and set it on top of Nature’s Generator Elite. Make sure the feet of Nature's Generator Power Pod Elite sit between the handle and top case of Nature’s Generator Elite.
  • Page 11 Step 2: Remove two bolts from Nature's Generator Power Pod Elite with included the Allen wrench. Put these two bolts aside for now as they will be reused in step 5 below. Visit Naturesgenerator.com for More Information...
  • Page 12 Step 3: Put the brackets on the cart. Bracket will match up with the shape of the cart frame. The curved part of the bracket should be placed on the back of the cart and the straight part of the bracket should be placed on the front of the cart.
  • Page 13 Step 4: Use type A bolts and nuts to secure the two brackets. Use wrench to hold the nuts the Allen wrench to �ghten the bolts. Visit Naturesgenerator.com for More Information...
  • Page 14 Step 5: Place Nature's Generator Power Pod Elite on the top of Nature's Generator Elite. Insert the bolts that were removed in step 2 by the Allen wrench. Visit Naturesgenerator.com for More Information...
  • Page 15 Step 6: Use the type B bolts and nuts to secure the brackets and bar. Use the wrench to hold the nuts and the Allen wrench to �ghten the bolts. Visit Naturesgenerator.com for More Information...

  • Page 16: How To Connect Your Nature's Generator Power Pod Elite To The Nature's Generator Elite

    If possible, please connect your Nature's Generator Power Pod Elite to the solar panel while in storage to top off the ba�ery voltage. This keeps the ba�ery healthy and prolongs its life. Failure to maintain Nature's Generator Power Pod Elite by these steps can result in ba�ery damage which will void the product warranty.

  • Page 17: Technical Specifica�Ons

    Technical Specifications Battery: Type: AGM Sealed Lead Acid Capacity: 100Ah (1200Wh) Self-discharge: Recommend to recharge it every 4 months Ports: 12V DC Port: up to 20A (240W max) Expansion Cable: 35 inches Charges: Solar Charger: 300wa� Ba�ery Level LED lights: 5 LED lights General: Dimensions: 18 x 12 x 15 in (47 x 30 x 38 cm) Opera�ng temperature: 32-104 °F (0-40 °C)

  • Page 18: Limited Warranty

    Limited Warranty One Year Limited Warranty Huntkey USA Inc. warrants to you, the original purchaser of this new product, that the product shall be free of defects in the original manufacture of the material or workmanship for a period of one (1) year from the original date of your purchase of the product (“Warranty Period”). This product must be purchased from an authorized dealer and packaged with this warranty statement.
  • Page 19 What does the Warranty not Cover? This warranty does not cover: • Cosme�c damage • Damage due to force majeure, such as lightning strikes, fire, flood, etc.. • Accident • Misuse • Abuse • Negligence • Commercial use • Modifica�on of any part of the product •...
  • Page 20 V1.0 ENGLISH 20-0507...
