Kits Consists Of; Mounting - Kindermann 7426000000 Manual

Anti-theft device
for Kindermann ceiling mounts
Ref. no. 7426000000

Mounting

1. Take the pre-mounted beamer with the universal projector holder out of the ceiling fixture and put it on a suitable table,
with the universal holder on top.
2. Loosen the screws between the projector and the holder and replace them by the set of screws of the anti-theft device along
with the distance elements and the discs
adapter elements and discs on the other two arms.
5a
3. Check the construction before you guide the safety rope
4. Mount the safety bracket
plugs and screws (ill. B). Note: With Kindermann Pro C 60/Pro 60/Pro 100 models you can also attach the safety rope via the
safety bolt to the ceiling fixture (ill. A). Take off one mounting plate
1
the specific drill-hole.
5. Attach the projector with the safety rope
lock the device.
7 426 000 000 D/GB 2014-10 / 843 899
Kindermann GmbH · Mainparkring 3 · D-97246 Eibelstadt · E-Mail: info@kindermann.de · www.kindermann.com
+ . Mount the two safety element
3 4
with the attached safety rope
1b
to the ceiling fixture (see user manual), insert the pre-mounted safety rope and
7

Kits consists of

• 1x safety rope , length 95 cm
2
• 1x safety rope with lock and 2 keys
7
• 1x safety bolt to be mounted on Kindermann
1
Pro C 60/Pro 60/Pro 100
• 1x safety bracket for mounting the safety rope on the ceiling
1b
• 2x safety elements
5
• 4x distance elements
• 4x distance elements
• 2x adapter elements
• 3x 4 screws in M3, M4 and M5 mm
6
on two arms of the holder and fix the
5
through the eye of the safety elements
7
beside the ceiling fixture on the ceiling with the help of suitable
2
of the holder and insert the bolt with the rope into
1a
