faCtory reset

Factory reset of the product can be done in the web interface or by
holding the button (15) pressed down at power-up. Hold for about 20
seconds. When green and red LEDs are flashing alternately, release the
button to execute the factory reset.

led IndICatIons

Green LED
State Description
Off Lacks power or is in boot mode
50/50 Booting in progress
Short flash Normal operation
On Indicates error in software
Red LED
State Description
On Short circuit M-Bus master
50/50 Network problems or booting in progress
Off Normal operation
Yellow LED
State Description
On Network connected to ethernet port
Off Lacks network connection to ethernet port
Flashing Communication on network
Blue LED
State Description
On Upcoming features
50/50
Short flash
On

trouBleshootIng

all leds are permanently off
Verify:
• That the product is powered up.
• If the product is in the first stage of the start-up process,
approximately 20 s.
red led is permanently on
• Verify no short-circuit of the M-Bus bus.
• Measure the voltage over the M-Bus master, voltage should be
between 24-30 VDC.
red led is flashing, the unit can not be accessed via lan
• Is the CMe3100 configured with static IP or dynamic IP (dynamic
IP is the default).
• For static IP , check that there are no conflicts with the set IP
address.
• For dynamic IP , check that the CMe3100 is connected to a network
with a correctly working DHCP server.

orderIng InforMatIon

Product Part number
CMe3100 1050016
ContaCt InforMatIon
elvaco aB technical support:
Phone: +46 300 434300
E-mail: support @elvaco.com
Online: www.elvaco.com
© 2015, Elvaco AB. All rights reserved. The documentation and product are provided on an "as is" basis only and may contain deficiencies or
inadequacies. Elvaco AB takes no responsibility for damages, liabilities or other losses by using this product. No part of the contents of this
manual may be transmitted or reproduced in any form by any means without the written permission of Elvaco AB. Printed in Sweden.
Description
DIN-mounted intelligent M-Bus master

teChnICal speCIfICatIons

Mechanics
Dimensions
Weight
Mounting
Electrical connections
Mains supply
USB slave port
M-Bus master port
M-Bus slave port 1
M-Bus slave port 2
Ethernet
USB master port
Electrical characteristics
Nominal voltage
Voltage range
Frequency
Power consumption (max)
Power consumption (nom)
Overvoltage category
Ethernet
Speed and duplex
Environmental
Operating temperature range
Storage temperature range
Pollution
Altitude
Usage
M-Bus
M-Bus standard
M-Bus baud rate
Transparent M-Bus
Internal M-Bus master
Maximum connected M-Bus
devices
Maximum cable length
IR Interface
Pass Through
Compatibility
General
Data storage
Real time clock backup
Real time clock accuracy
Script engine
Software update
Integration
Transparent M-Bus
Value reports
E-mail
FTP
HTTP
Configuration
Approvals
EMC
Safety
65x72x90 mm
180 g
Mounted on DIN rail (DIN 50022) 35 mm
Screw terminal cable 0.25-2.5 mm²
Type mini B
Pin terminal solid wire 0.6-0.8 Ø mm
Screw terminal cable 0.25-1.5 mm²
Screw terminal cable 0.25-1.5 mm²
RJ45
Type A
100-240 VAC
-10 % to +10 % of nominal voltage
50/60 Hz
<15 W
<5 W
CAT 3
Auto 10/100 MBit half/full duplex
-20 °C to +50 °C
-40 °C to +85 °C
Degree 2
0-2000 m
Indoor use only, can be extended with IP67
enclosure for outdoor use
EN 13757 Full M-Bus decoder implemented
300, 2400, 9600* Bit/s (* not compatible with
CMeX Series)
Listening server on TCP data
32 (can be extended using CMeX10 Series)
Configured by software
1000 m
Yes
No
All standard M-Bus meters, all ABB meters
with IR interface, CMeX Series products
2 GB
7 days
<2 s/day
Intelligent script engine for active content
generation
Via web interface or SSH
TCP
HTTP , FTP , e-mail
SMTP
Standard FTP client
Standard HTTP and HTTPS client, POST & GET
HTTP , FTP , Telnet, JSON
EN 61000-6-2, EN 61000-6-3
EN 61010-1, CAT 3
CMe3100 Quick manual A4 English
Document id: 1090079
Version: 3.0
