Parts Guide

Quantity Description
1 PowerBlaster™ Receiver with integrated antenna
1 Mounting Plate for wall mounting PowerBlaster™
4 Screws for wall mounting the mounting plate
1 9V-300mA Power Supply
6 Flashers with 10 foot plug-in cables.
Red Power LED
lights to indicate when
PowerBlaster is
™
plugged into an active
AC outlet.

The Mounting Plate

guides enable
PowerBlaster's ™ matching
guide to slide and "snap"
into place for mounting
on the wall.
Red Status LED lights
when PowerBlaster ™
receives an RF signal
from an RF series
remote control.
Front blaster sends
Infrared commands to all
A/V components in the
same cabinet space.
The Mounting Plate
Using the four enclosed screws,
you can choose to fix the mounting
plate to a wall or the back of your
component cabinet.
