INSTALLATION MANUAL
180L / 270L
istore.net.au
iStore - Installation Manual - June 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 180L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Istore 180L

  • Page 1 INSTALLATION MANUAL 180L / 270L istore.net.au iStore - Installation Manual - June 2020...
  • Page 2 The installer is to explain to the end user how to operate and maintain the unit in • accordance to this Instruction manual. iStore will not be held responsible for any damages or injuries caused by the incorrect • Installation of this hot water system.
  • Page 3: Table Of Contents

    4.4) Multi-system configuration 5. Intelligent Operation Modes 5. Functionality 5.1) Function of the LED Display 5.2) Setting the Time 5.3) Setting the Timer 6. Maintenance and repair 6.1) Typical failure and solutions 7. Troubleshooting iStore - Installation Manual - June 2020...
  • Page 4: Safety Precautions

    Compulsory - The listed action shall be followed Please pay attention to what is indicated INSTALLATION WARNING The iStore must be installed by qualified persons. Improper installation could result in electrical shock /water leakage or fire Before installation, check the unit for any damage Please ensure that the unit and power connections have a good earth.
  • Page 5 Shut Off Power RE-LOCATION OR REPAIR If the iStore needs to be relocated or installed again, only use an authorised dealer or qualified persons. Important It is prohibited for the end user to repair the unit themselves, unless qualified.
  • Page 6 Note: In SA, WA & QLD (and some other areas of other states subject to local authority regulations) it is a requirement that an expansion control valve be fitted between the non-return isolating valve and the water heater. iStore - Installation Manual - June 2020...
  • Page 7: Specifications P7

    Height to water outlet (mm) 1194 HW outlet HW condensation PTR Valve Hot water condensation (mm) Height to PTR Valve (mm) Anode Height to Anode 1094 Net weight (Kg) Top View Cold water inlet 270L iStore iStore - Installation Manual - June 2020...
  • Page 8: Dimensions 180L P8

    Height to water outlet (mm) 1240 HW outlet Hot water condensation (mm) HW condensation PTR Valve Height to PTR Valve (mm) Anode Height to Anode 1140 Net weight (Kg) Top View Cold water inlet 180L iStore iStore - Installation Manual - June 2020...
  • Page 9 Duo valve. The hot water outlet from the tank is ¾ inch FI. All hot water pipes must be insulated by UV stable & appropriately rated insulation. iStore - Installation Manual - June 2020...
  • Page 10: Safety Features

    Pressure Temperature Relief Valve (PTR) An 850kPa, 10kW and 99°C PTR valve is used on the iStore water tank, which is located on the side of the water tank and is essential for its safe operation. The PTR valve is designed to allow 3-5% of total tank volume to discharge during heating to allow for hot water expansion.
  • Page 11 Care should be taken to avoid coming into contact with any pipe work or fixtures associated with the water heater collector flow and return lines. All iStore hot water systems must be installed by an authorized plumber. All installation work must meet local authority standards, Australian standard (AS 3500.4) and the National Plumbing Code along with local electrical regulations.
  • Page 12: Installation

    Condensate drain shall discharge to an approved discharge point • Filling and commissioning the iStore Hot Water System 1. Turn on the cold water supply to the tank and open a hot water tap preferably laundry tap without filter as existing sediment may partially block pre-existing water saving devices.
  • Page 13 The unit should not be laid flat during vehicle transportation. 60º CAUTION: TOP HEAVY. HIGH CENTRE OF GRAVITY iStore - Installation Manual - June 2020...
  • Page 14: Installation Space P14

    Ensure the minimum space between the unit and walls and objects are per specifications illustrated in Diagram 1a/2a and Diagram 1b/2b. • Unit shall be located as close as possible to the most frequently used hot water outlet iStore - Installation Manual - June 2020...
  • Page 15 Installation unit: mm Diagram 1b Front View Diagram 2b. Front View Air Inlet Air Outlet Air Inlet Air Outlet 1000 1000 270L iStore 180L iStore iStore - Installation Manual - June 2020...
  • Page 16: Multi-System Configuration P16

    • Switch on the unit using the controller • In the case of any unusual noise, switch the power off and consult your iStore technician • The parameters have been pre set to a temperature of 60 degrees Seismic restraints •...
  • Page 17: Intelligent Operation Modes

    Vacation Mode For use when away on holidays, enter the date of your return and the smart iStore will not use energy while you’re away & prior to your return. Vacation mode reduces energy consumption.
  • Page 18 Move down or decrease parameter values. Down Important - If the iStore display does not detect activity for 15 seconds the screen will automatically lock to prevent any unwanted changes. To unlock the screen, simply press and hold the power button for 5 seconds.
  • Page 19 Shows that the temperature in Main display area or Auxiliary Centigrade display area is in C Shows that the temperature in Main display area or Auxiliary Fahrenheit display area is in F Lock Shows that the keyboard is locked. iStore - Installation Manual - June 2020...
  • Page 20 “ and hold for 0.5s. Top tank temperature Bottom tank temperature Mode selection Press “ “ to select the modes including Hybrid Heating, Eco Mode, Intelligent and Vacation in the standby or running interface. iStore - Installation Manual - June 2020...
  • Page 21 Example: Change the target temperature from 55 to 60 when the actual outlet water temperature is 18 iStore strongly recommends that 60 C is the default setting for optimal hot water delivery. iStore - Installation Manual - June 2020...
  • Page 22: Setting The Time P22

    Example: Change the time and date from 18:30 on August 4th to 17:40 on September 8th. Time Press twice then press to change the hour parameter and press to confirm. see next page iStore - Installation Manual - June 2020...
  • Page 23 “ to circularly display. Timer Cancel: Press “ “ and hold for 2s to enter into the interface, and then press “ “ to cancel all the operation. Please see the following picture for more details. iStore - Installation Manual - June 2020...
  • Page 24 Press and hold for 2s to enter into the next setting OFF2 without ON 2 confirm the previous one. Set the hour. Set the minute. Press to confirm the time. iStore - Installation Manual - June 2020...
  • Page 25 Current time Confirm the time after setting. OFF1 Confirm the time after setting. Confirm the time after setting. OFF2 Save Settings Press to confirm. Cancel Settings Press to cancel the setting and exit iStore - Installation Manual - June 2020...
  • Page 26 Functionality Cancelling the Timer Setting Outlet water temperature The “ON” and “ 1 “ Timer state icons are flashing Pressing more than 2s Press to cancel entire operation. iStore - Installation Manual - June 2020...
  • Page 27 Refer to page 12. Outlet water temperature Vacation Mode Press hold for 5s. Press Press and hold to cancel for 2s. Press then to choose desired date Press month/day then Press to save iStore - Installation Manual - June 2020...
  • Page 28 The fan mode is not required during normal operation, it is available for specialised situations where capturing the cold air exiting from the iStore is useful in some cases. Care must be taken not to restrict the exiting air as this will reduce the heating performance of the iStore.
  • Page 29: Maintenance And Repair P29

    How to drain the water heater Warning: Before commencing this procedure, ensure that building occupants are notified to stay clear of the iStore system components and building perimeter as steam or hot water may be discharged from pipes or com- ponents 1.
  • Page 30 The recommended factory setting is 60º Celsius to prevent the thermal cut-out from operating. The thermal cut-out operation temperature is 85º Celsius. loosen the screws and open the cover Push the red button Earthing iStore - Installation Manual - June 2020...
  • Page 31: Troubleshooting

    Increase timer setting if in use. Utilise hybrid mode to decrease re-heating time. An 850kPa and 99°C PTR valve is used on the iStore water tank, which is located on the side Pressure Temperature of the water tank and is essential for its safe Relief Valve (PTR) / Expan- operation.
  • Page 32 2. This Warranty is effective for all iStore Hot Water Systems manufactured and installed after 1 November 2012. 3. If the customer has not paid in full for the iStore Hot Water System then this Warranty does not apply. 4. iStore Hot Water System and its components are covered by a warranty against defective factory parts or workmanship from the date the iStore Hot Water System is installed for the relevant period for such component as outlined in Table 1 - Warranty Periods.
  • Page 33 Warranty. See Warranty Table on next page. 15. Any claim under this Warranty must include full details of the defect and/or damage to the iStore System. All claims must be made within one (1) month of detection of the defect.
  • Page 34 17. iStore does not warrant any work conducted by a third-party installer of the iStore Hot Water System. 18. This Warranty only applies to the iStore Hot Water System and its components and does not cover any plumbing or electrical associated parts, including but not limited to any parts supplied by any person installing the iStore Hot Water System.
