Summary of Contents for Heatmor 100 CB
- Page 1 Coal Burner SAVE THESE INSTRUCTIONS Manuel en Français disponible en ligne: www.HEATMOR.com...
-
Page 2: Table Of Contents
B Placing the HEATMOR™ on the Concrete Base C Filling the HEATMOR™ Outdoor Furnace Initially with Water D Maintaining Heat Transfer Fluid (HTF) in the Bladder and HEATMOR™ E Low Heat Transfer Fluid (HTF) Condition F Initial Installation of Sand... - Page 3 F In the Event of a Power Failure D Firebox Door Handle 19 EXTERIOR CLADDING AND INSULATION E Firebox Door Hinge A Outer Front Door of HEATMOR™ F Firebox Door Latch B Roof of the HEATMOR™ G Firebox Door Magnet C Sides of the HEATMOR™...
-
Page 4: Notice To The Reader
The methods of operation described within this Operations and Maintenance Manual have proven to be effective for HEATMOR™ for the sole purpose of the operation of a HEATMOR™ Stainless Steel Outdoor Furnace. All formulas and figures listed within this Operations and Maintenance Manual are approximated and should be read as such. - Page 5 CHAPTER 1 CHAPTER 2 HEATMOR ™ STAINLESS STEEL OUTDOOR FURNACE MODELS RESIDENTIAL FURNACE SPECIFICATIONS Specifications Model 100 CB Model 200 CB Model 400 CB Overall Width (Inches) Base Width (Inches) (Footprint) 46.5 46.5 46.5 Overall Height (Inches) 82.5 82.5 82.5...
-
Page 6: Front Cut Away View Of Heatmor
CHAPTER 3 FRONT CUT-AWAY VIEW OF HEATMOR™ OUTDOOR FURNACE FURNACE PARTS LIST (For parts not shown on the cut-away view, please refer to the appropriate chapter for further details.) Firebox Ashes Firebox Ash pan Firebox door Ash auger (not shown) -
Page 7: Rear Cut Away View Of Heatmor
CHAPTER 4 REAR CUT-AWAY VIEW OF HEATMOR™ OUTDOOR FURNACE FURNACE PARTS LIST (For parts not shown on the cut-away view, please refer to the appropriate chapter for further details.) Firebox Ashes Firebox Ash pan Firebox door Ash auger (not shown) -
Page 8: Minimum Clearance Separation Specifications
Do not connect the HEATMOR™ furnace to the chimney of any existing heating system. HEATMOR™ Outdoor Furnaces, Model 100 CB, 200 CB and 400 CB are not designed or certified to be located in densely populated areas. This unit was not designed, nor is it recommended, for use as a stand-alone heating system. -
Page 9: A Model 100 Pad Specifications
NOT be attached appliances. to main base of furnace. 6) The red wire from the New Style High-Limit on the back of the HEATMOR™ should BASE: OUTDOOR FURNACE SITS ON THIS PAD It is recommended to use steel mesh or R-bar be wired to the indoor temperature control to override the thermostat. -
Page 10: B Model 200 Pad Specifications
3. Less bending when adding coal. 4. Keeps smoke above the operator. 4. Keeps smoke above the operator. 48” 5. Protects the base of the HEATMOR™. 5. Protects the base of the HEATMOR™. PATIO STONES OR SEPARATE CEMENT SLAB FOR CONVENIENT LOADING... -
Page 11: Installation Of The Heatmor™ Furnace
PH LEVEL OF 7.0 TO 11.5 firebox base. CHLORIDE LEVEL OF UNDER 50 2) Need to seal the perimeter of the entire HEATMOR™ so rodents are not able to find a HARDNESS UNDER 200 PPM home inside the HEATMOR™. SOFTENED AND FILTERED TO LIMIT THE AMOUNT OF SOLIDS. -
Page 12: D Maintaining Heat Transfer Fluid (Htf) In The Bladder And Heatmor
40% DOWFROST™ HD) but open at all other times. Your bladder should have a small amount of HTF in it. 2) HEATMOR™ does not recommend the use of in-line fill valves due to the dilution of the HTF over time. - Page 13 Using such liquids may result in severe burns and injury. Heatmor™ outdoor furnaces, model 100 CB, 200 CB, and 400 CB are certified to burn coal 10) When adding HTF, DOWFROST™ HD or maintaining the HEATMOR™ furnace, only.
-
Page 14: B Lighting The Heatmor™ For The First Time
Just as moisture collects on the inside of a warm house window on a cold outside day, the who will be lighting and fueling the HEATMOR™ furnace. same thing is occurring inside the HEATMOR firebox. The warm moisture in the smoke is Confirm the furnace is full of HTF condensing on the cold firebox walls of the HEATMOR. -
Page 15: D Loading Coal Into The Heatmor
Types of coal allowed to be used include: Pennsylvania anthracite, Eastern Canadian Loading a large amount of coal into the HEATMOR™ furnace once a day is not always best. We have found that you have a more efficient fire and produce less smoke when you Bituminous and Western Canadian Sub-bituminous. -
Page 16: F Types Of Coal
If you are draining the system because of total system shutdown in cold weather, remember to also drain the supply and return lines to prevent freeze-up. The use of an In-Line Filling system is not recommended by HEATMOR as it may void your warranty due to the dilution of the HTF When refilling your HEATMOR™, refer to “Filling the HEATMOR™... -
Page 17: Bladder Assembly
Before draining the water, please refer to “Removal/Replacement of System HTF”. Bladder HEATMOR does not recommend the use of water additives. As they may void your warranty Principle of the Bladder The HEATMOR™ is designed to be a semi-closed system. -
Page 18: C Bladder Ball Valve And Bladder Hose
Removal and Replacement of the Bladder Heat Transfer Fluid (HTF) Level Gauge 1) Turn off the bladder ball valve located at the front of the HEATMOR™ furnace. Principle of the HTF Level Gauge 2) Remove the bladder cover plate held in place by two wing nuts. -
Page 19: Water Jacket
HTF within the water jacket absorbs heat produced in the firebox. The heated HTF is used Principles of the Firebox to transfer heat from the HEATMOR™ into the building needing heat. The water jacket and the firebox are one welded component and can be replaced. -
Page 20: A Firebox B Firebox Door
Firebox Door Removal of Firebox Door 1) Turn off power to the combustion air blowers. Principles of the Firebox Door The firebox door is HTF cooled to prevent warping of the 2) Ensure that the fire in the firebox is extinguished. door. - Page 21 The door hoses allow HTF from the water jacket to to the firebox door handle holder on the outer door. This procedure prevents either of the pass through the firebox door, through thermal doors closing while the Heatmor is being loaded with coal. siphoning. Refer to “Firebox Door”...
- Page 22 5) Cover the door rope with silicone and tool to a smooth, flat, finish. firebox door completely open while the operator is loading coal into the HEATMOR™. 6) Leave the firebox door open for 24 hours to allow silicone to dry completely.
-
Page 23: J Firebox / Base Connector Clamps
Firebox / Base Connector Clamps Removal and Replacement Principles of the Firebox / Base Connector Clamps 1) Allow the ashes to burn completely and extinguish. To allow easy separation of the firebox / water jacket assembly and the base, if repairs are 2) Push the ashes to the back of the firebox or remove all the ashes from the firebox. -
Page 24: O Flash Curtain / Heat Shield
Principles of Sand in the Base of the Firebox ABSOLUTELY NO FIRE IN THE FIREBOX WHEN The HEATMOR™ furnace, in boiler terms, is a “dry PERFORMING THIS REPAIR. ALWAYS WEAR base boiler.” This is to say there is no HTF around PROPER PERSONAL PROTECTIVE EQUIPMENT. -
Page 25: Air Supply
CHAPTER 14 Removal and Replacement AIR SUPPLY 1) Turn off the main power supply to the furnace. Combustion Air Blower(s) and Flipper Assembly(s) 2) Loosen and remove the thumbnuts securing the blower/flipper assembly to the air tube. THE FLIPPER MUST OPERATE PERFECTLY OR PROBLEMS QUICKLY ARISE. 3) Disconnect the electrical wire from the blower. -
Page 26: C Combustion Air Tube
“fan on” position or if 1) See chimney maintenance above. the Automatic Fan Switch fails in the “fan on” position, the Heatmor combustion fan will 2) Purchase approved chimney extensions that fit together correctly. If the extensions continue to run until the high limit is tripped. -
Page 27: Ashes
Ash Management and Ash Removal Creosote - Formation and Need for Removal - 1) If ash management is deficient, the HEATMOR™ will not perform to its optimum. When coal is burned slowly, it produces tar and other organic vapors, which combine with It is time well spent to ensure proper ash management. -
Page 28: B Ash Pan
3) A proper method of storing the ash auger is to attach a six inch PVC pipe, three feet long, to the side of the Ash Auger HEATMOR™. Storing the auger in the tube will keep it from being frozen into or under snow. Rev. 05/2020... -
Page 29: Electronic Aquastat Controller
Keep the face of the dial clean by cleaning periodically with 5) The electrical supply wire should be connected to it’s own circuit. glass cleaner. 6) The red wire is used as a 120v signal back to the house that the Heatmor is in an Removal and Replacement Over-Temp situation. -
Page 30: C Double Electrical Outlets At Rear
In the Event of a Power Failure 5) Remove electrical box cover. If a power failure occurs during the use of a HEATMOR™, do not open the firebox door 6) Disconnect - Black - Brown - Red. to provide draft for the fire to burn. Allow the fire to go out. In case of a prolonged power 7) Pull wires - Black - Brown - Red. -
Page 31: Exterior Cladding And Insulation
EXTERIOR CLADDING AND INSULATION Removal and Replacement If the roof has been damaged it can be replaced. Follow these steps or contact your local Outer Front Door of the HEATMOR™ dealer. Principles of the Outer Front Door 1) Remove the silicone from around the lift hook and vent pipe. -
Page 32: Checking For Air Leaks
CHECKING FOR AIR LEAKS HEAT TRANSFER FLUID (HTF) LEAKS Once your HEATMOR™ system is up and running, we recommend that you conduct an If you suspect that your HEATMOR™ Stainless Steel Outdoor Furnace has developed a HTF leak, please contact your local dealer for verification and further details. -
Page 33: Domestic Coil
End of Season 2) Firmly fastened connections are essential to ensure there are no leaks. To begin End of Season Shutdown of your Heatmor™ Outdoor Furnace, follow the Removal and Replacement instructions below: If you suspect you have a leak or faulty internal coil requiring replacement, contact your 1) Turn off pump(s). -
Page 34: Frequently Asked Questions
Transfer Fluid” Refer to: 9) Take HTF sample and Mail to HEATMOR™, Box 787, Warroad, MN 56763 as per ”Trouble Shooting and Solutions” Furnace has excessive moisture in firebox •... -
Page 35: Troubleshooting And Solutions
CHAPTER 25 Why am I experiencing an excess build up of creosote in the furnace? TROUBLESHOOTING AND SOLUTIONS You more than likely are introducing unwanted draft into the firebox. This may Main Principles to Remember be caused by several things, including a door ajar, ash auger tube cover loose, •... - Page 36 “Chimney Not enough coal in “Loading Coal into excessive moisture Add coal Chimney plugged Clean Chimney Stub/Chimney Firebox the HEATMOR™” in Firebox Extension(s)” Remove blower and flipper assembly. “Top Rectangular Draft flipper stuck “Steps to Maintain Flue Plugged Clean flue Clean, lube, or Flue”...
- Page 37 Firebox Door Loading fuel too Load your fuel away “Loading Coal into “Top Rectangular close to the firebox from the firebox Flue Plugged Clean Flue the HEATMOR™ Flue” pops or Rattles door door Charcoal Adjust aquastat “Electrical (HTF HTF Temp. range “Ash Management...
- Page 38 Heating devices Maintain heating Bladder is leaking Replace Bladder “Bladder” Local Dealer need maintenance devices HEATMOR™ not Door hoses are “Firebox Door “Electrical Aquastat Replace door hoses running between Adjust Aquastat leaking Hoses and Elbows” Controller”...
- Page 39 Dealer cast iron grates, gaskets and auger are all under warranty by HEATMOR™ for a period of two (2) years from the date of purchase. HEATMOR™ does not warranty parts damaged by freezing, overheating, pressurization, use of unauthorized fuels, or abuse.
-
Page 40: How To Maintain Your Warranty
1) Test your water before filling your HEATMOR™ a Heatmor Furnace sold after July 31, 2010 will be mailed a $100 check for each confirmed 2) Send in a sample of your Heat Transfer Fluid after it has run through your system for referral after the sale of the new furnace is finalized and the warranty is sent in. -
Page 41: Notes
Notes: Rev. 05/2020...
