SmartLabs SML-5051W User Manual

Hide thumbs

Advertisement

Table of Contents

SML-5051W
User Manual
© 2019 SmartLabs Holding Ltd
Proprietary and Confidential

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SML-5051W and is the answer not in the manual?

Questions and answers

Related Manuals for SmartLabs SML-5051W

Summary of Contents for SmartLabs SML-5051W

  • Page 1 SML-5051W User Manual © 2019 SmartLabs Holding Ltd Proprietary and Confidential...

  • Page 2: Distribution Kit

    This manual contains a description of all possible features and options of SML-5051W, however your device may look slightly different from the one pictured in this document.

  • Page 3: Indicators And Slots

    • Adapter shall be installed near the equipment and shall be easily accessible. • The mains plug of adapter is used to disconnect device from power supply. The mains plug of adapter shall remain readily operable. • When using the STB with a plasma TV, do not put picture on pause for more than 5 minutes, due to plasma TV screen design it could lead to display damage.
  • Page 4 Element Purpose Green — STB is switched on and operates normally. Power indicator Red — STB is in stand-by mode. IR receiver The internal IR receiver is accepting signals from the IR remote control. Note: the device appearance may differ from that shown in the picture. Back Panel Element Purpose...

  • Page 5: Installation

    Connecting Installation 1. Remove your STB from packaging and remove the protective tape. 2. Make sure that the place, where you are installing the STB, meets the following requirements: • Place STB on a flat surface. • Do not place the STB on slick surfaces, where there is a risk of vibration, fall or other damages of STB.

  • Page 6: Remote Control

    Connecting to Internet via Wi-Fi 1. Turn on the STB and wait for it to boot. 2. Go to the "Settings" menu on the home screen. Next, "System" → "Native system settings" → "Network". 3. Select your wireless network in the list of available networks. 4.
  • Page 7 Switch channels Numeric keys * You can control TV after the RC setup ** RC appearance may differ from that shown in the picture. Replacing the Battery This remote is operated by a replaceable CR2032 battery. In accordance with IEC 60065:2014, the battery cover is held in the remote control case with considerable force to prevent children from accessing the battery without adult supervision.

  • Page 8: Remote Control Setup

    The remote control is supplied with a coin/button cell battery. If the coin/button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death. Keep new and used batteries away from children. If the battery compartment does not close securely, stop using the product and keep it away from children.
  • Page 9 4. You can change the search direction, using the buttons CH- and CH+. 5. Each time you start setting up, search begins with the first code in the table. Table of Manufacturer Numbers and Codes Manufacturer Number Code Aiwa 1050 1141 1094 Akai 1086 1010 1018 1002 1001 1000 1059 1056 1053 1051 1049 1054 1031 1030 1023 1013...

  • Page 10: Resetting The Remote Control

    2. Point the remote control at your TV. Press and hold the TV and OK buttons for 3 seconds. The LED on the remote control will flash twice and the remote control will switch to the setup mode. Release the TV and OK buttons. 3.

  • Page 11: First Start

    1. Press and hold TV and OK buttons for 3 seconds. The LED on the remote control will flash twice and the remote control will switch to the setup mode. Release the TV and OK buttons. 2. Enter the code 977. The LED will flash each time you enter a digit. After that, the LED will blink four times, and the settings will be reset to default.

  • Page 12: Weee Compliance Statement

    With this little personal effort, you contribute to recycle valuable raw materials and the treatment of toxic substances. Specifications Name: SML-5051W Dimensions: 110 x 107 x 33 mm, 130g Power supply: • Input: AC 100-240V, 50/60Hz •...
  • Page 13 Wi-Fi module: Standard IEEE 802.11n\ac, MIMO 2x2 Operating frequency 2.4GHz band: 2400~2483.5 MHz 5GHz band: 5150~5250 MHz & 5725- 5850 MHz (depends on country) Antenna Gain not more than 3dBi Max. transmitting power (EIRP) not more than 18 dBm BT module: Standard BT v4.2 + BLE Operating frequency...

  • Page 14: Ec Declaration Of Conformity

    Smartlabs Holding Ltd has the appropriate licenses to use these standards. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

  • Page 15: Fcc Compliance Statement

    FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 16: Manufacture Date

    7-th and 6-th are the week: Note: S/N and MACs are shown here for example only. About the Manufacturers Manufacturer: Smartlabs Holding Ltd Manufacturer address: Nafpliou 15, Limassol, Cyprus, 3025 Contact information: info@smartlabs.tv Manufacturing plant: Sichuan Changhong Network Technologies Co. LTD...
