- Page 1 Alignment Procedure for ASX-500/510/520...
- Page 2 Alignment procedure for ASX-500/510/520 Ensure power to instrument is off. Make sure that you have a sample probe in the Z-drive, and racks on the right and left of the tray. As shown in figure 1-1. There is no need for racks in the 2 middle sections of the tray.
- Page 3 Alignment procedure for ASX-500/510/520 With the back of the autosampler off the edge of the table or cart. Locate the 4 cap screws located under the bottom of the autosampler. As shown in figure 1-3.(only one side is shown in picture) Figure 1-3 Notice the holes in the bottom of the tray, these are for access to the 4 cap screws.
- Page 4 Alignment procedure for ASX-500/510/520 Now open the program that you downloaded off the website. It will open a tcomm debug window, then soon after will open the main window as shown in figure 1-5. Figure 1-5 In the top left hand corner of the main window it should tell you what version of e-prom is in your autosampler.
- Page 5 Alignment procedure for ASX-500/510/520 14. Turn autosampler back on and when the sample probe gets to the next tube, do the same as you did on the first tube. Turn unit off align and tighten screw. As shown in figure 1-7.
