- Page 1 MN2525 Configuration Guide MN2525 MoCA 2.5 Ethernet Adapter Web Configuration Guide www.starlink7.com...
- Page 2 Warranty The material contained in this document is subject to change without notice. StarLink makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
-
Page 3: Table Of Contents
Table of Contents Introduction ......................................4 1.1 Overview and Functions................................4 1.2 Important Safeguards and Precautions ..........................4 1.3 MN2525 Package..................................4 1.4 Hardware Specifications ................................. 5 1.5 Safety and Precautions ................................5 Physical Interface ....................................7 2.1 Panel Interface ..................................7 2.2 Indicator LEDs ................................... -
Page 4: Introduction
(either Cable TV, Satellite TV or any Terrestrial TV) to transmit over coaxial cable distribution structure to reach subscribers. Another MN2525 is needed at the far end to receive multiplexed signal to supply TV signal and Ethernet / IP data service in residential homes, multi-dwelling units or office buildings. -
Page 5: Hardware Specifications
Operation 1.5 SAFETY AND PRECAUTIONS Utmost care has been taken in the manufacture of the MN2525 and AN2015. Please keep the following instructions in mind while using the MN2525. Disconnect the power adapter before cleaning the device. Do not use water, paint thinner, benzene, alcohol and ... - Page 6 MN2525 Configuration Guide Avoid direct sunlight or high electromagnetic exposure. Do not service the device by yourself. Always follow the instructions to operate the device. ...
-
Page 7: Physical Interface
Reset button to restore factory defaults 2.2 INDICATOR LEDS The functional status of MN2525 is indicated by LEDs. There are four LEDs at the top of the MN2525. POWER is lit when the power supply is good. Check the power adapter if the Power LED is dark when it’s plugged into the unit. -
Page 8: Operation And Web Based Configuration / Monitoring
MN2525 Configuration Guide OPERATION AND WEB BASED CONFIGURATION / MONITORING MN2525 can be configured through its built-in Web Interface as described in sections below. 3.1 LOGIN ① Connect the ETHERNET port of the Adapter and the Ethernet port of a PC with an Ethernet cable. Power on the Adapter. -
Page 9: Settings
MN2525 Configuration Guide 3.2 SETTINGS 3.2.1 MOCA SETTINGS Configuring MoCA parameters of the adapter. Coax Setup Band Frequency band to scan for MoCA signals D-Ext Extended Band D 1125 – 1675MHz (default). Refer to the diagrams below for more description. - Page 10 MN2525 Configuration Guide Scan Offset Offset of scan mask in hexadecimal. Primary Ch(annel) Above Mask Spectral bit mask of primary channel above the scan mask in hexadecimal. Primary Ch(annel) Below Mask Spectral bit mask of primary channel below the scan mask in hexadecimal.
- Page 11 MN2525 Configuration Guide Beacon Power Level Transmission power of beacons in dBm. In certain cases, the far-end adapters can be sensitive to the receive power, the transmission power can be lowered by selecting lower Tx Power. It’s recommended to select 10dBm to satisfy high-attenuation network.
- Page 12 MN2525 Configuration Guide Notes: In special cases D-Low or D-High may be used to limit the frequency range. Extended Band D Channel Frequencies MoCA 2.5 Channle 4 Channel 5 Chennel 1 Chennal 2 Channel 3 Band D Center (if Center (if...
- Page 13 MN2525 Configuration Guide MoCA 2.5 Channel Channel 2 Channel 3 Band E 1 Center Center Center Channels E2p5-1 Band E Channel Frequency Plan Band E Channel Frequency Spectrum Band FSAT and Band FCBL Frequency Spectrum MoCA Output Power Level...
-
Page 14: Device Settings
MN2525 Configuration Guide 3.2.2 DEVICE SETTINGS Configuring Ethernet / IP parameters of the adapter. DHCP Automatic Configuration Enable DHCP mode if DHCP server is available in the network. Link Local automatic configuration If DHCP server is unavailable, Link Local Automatic Configuration indicates IP ... -
Page 15: Security Settings
MN2525 Configuration Guide 3.2.3 SECURITY SETTINGS Configuring security parameters of the adapter. Administrator Security Setup Old Password Old password of administrator login to be changed. New Password New password of administrator login. Confirm Password Retype new password to match. -
Page 16: Status
MN2525 Configuration Guide 3.3 STATUS 3.3.1 DEVICE STATUS Displaying current device status. SOC Version The embedded firmware version of the System on Chip (SoC) processor. My MoCA Version MoCA standard of the adapter. MoCA 2.5 device shows 2.5. ... -
Page 17: Phy Rates
MN2525 Configuration Guide 3.3.2 PHY RATES Displaying (Ethernet) PHY rates and link status of each coax bridge relative to other nodes on the MoCA network. The PHY rate is the average of Tx and Rx bit rates between bridges on the MoCA network in Mbps. -
Page 18: Advanced
Follow the instructions on this page to upgrade the firmware of the adapter. It’s recommended to upgrade the firmware of the adapter with dedicated StarLink support team only. The version numbers of active and backup firmware images are also displayed. -
Page 19: Reference
MN2525 Configuration Guide REFERENCE 4.1 CUSTOMER SERVICE General StarLink Customer Service is available from 8:00 AM to 5:00 PM Pacific Standard Time (California, U.S.A.). Customer Service performs the following functions: • Answers customer questions over the phone on such topics as product operation and repair. - Page 20 MN2525 Configuration Guide D. Only for CUSTOMER. COMPANY makes this warranty only for the benefit of CUSTOMER and not for the benefit of any subsequent purchaser or licensee of any merchandise. E. LIMITATION ON WARRANTY. THIS CONSTITUTES THE SOLE AND EXCLUSIVE WARRANTY MADE BY COMPANY WITH RESPECT TO HARDWARE, SOFTWARE AND FIRMWARE.THERE ARE NO OTHER WARRANTIES, EXPRESS OR IMPLIED.
