Start-Up Procedure - Protocol VERT I Instruction Manual

START-UP PROCEDURE

Before flying, the plane and transmitter must be turned on in sequence
and synchronized.
1. Plug the battery into the plane to turn it on and place it on flat ground
in front of you.
2. Turn on the remote control.
3. Switch the remote to:
a. V-Mode – Vertical Flight
b. 6G-Mode – Horizontal Flight – make sure to have area cleared
to serve as a runway
c. 3D-Mode – Stunt Flight
4. Push the throttle up and then down to sync.
NOTE:
If after 30 seconds, it has not recognized the plane, turn off the controller and
repeat Start-Up procedure.
STARTING THE ENGINE
After synchronizing the plane, pull the throttle and direction stick to lower
outer corners at the same time and release. The blades will rotate but the
plane will not lift.
7
