Instruction Manual for
NAUTICUS
RC Speedboat
Congratulations on purchasing the Protocol RC Speedboat!
CAUTION: Do not allow children to use this speedboat without adult supervision. Not intended
for use by anyone under 14 years of age. Observe all the rules of water safety at all times when
using this speedboat.
DANGER: THIS IS A RACING BOAT AND OPERATES AT HIGH SPEEDS. IT IS NOT A TOY.
Use extreme care not to touch the propeller or allow it to come in contact with body or loose
clothing. The propeller spins very fast and has sharp edges. Contact with the spinning
propeller can cause serious injury. Use care when turning on the power and when placing
the boat into the water or taking it out. Parental supervision is recommended.
LIMITED WARRANTY
At Protocol, we're dedicated to bringing you innovative and well-designed products that make living fun and
easy. We stand behind all of our products and warrant this to be free from defects in workmanship and
materials for 30 days from the date of purchase. The warranty does not cover transportation damage,
misuse, accident, or similar events. Specific legal rights pertaining to this warranty may vary by state.
For service claims or questions please consult our website ProtocolNY.com.
INSTALLING BATTERIES
Note: Batteries may pose a hazard to children. Check safety notices provided with batteries
before use. Install batteries under adult supervision.
Warning: Dispose of batteries properly.
Cautions:
• Use only batteries of the size and type indicated.
• Do not mix old and new batteries.
• Do not mix battery types – ie; standard, alkaline or rechargeable.
• Do not mix rechargeable batteries of different capacities.
• Remove all batteries from speedboat after each use; drain any water that has accumulated
inside the speedboat. Water can damage the speedboat's electronic components and
batteries. Store the speedboat with its battery compartment door open to allow the
compartment to dry.
• Use six "AA" for the remote control.
• Use provided lithium ion batteries or the rechargeable for the speedboat.
INSTALLING BATTERIES IN THE REMOTE CONTROL
1. Use a screwdriver to loosen the screws on the battery compartment cover.
2. Lift the cover to remove it.
3. Place the six "AA" batteries in the compartment making
sure to properly align the (+ and -) polarity symbols as
marked inside the compartment.
4. Replace the battery compartment cover and tighten the screws to
secure the cover.
Note: When you notice the range of the remote control decreasing
or weakening, replace the batteries. Non-rechargeable batteries
CANNOT be recharged.
USING RECHARGEABLE BATTERY IN THE REMOTE CONTROL
1. Remove the rechargeable battery from the speedboat.
2. Charge the battery for approximately 3.5 hours under adult supervision
for 6-7 minutes of run time.
3. Remove battery from charge before reinstalling battery into speedboat.
4. CAUTION: Battery surface may be warm after recharging.
Housing cover
AGES
14
+
(SEE ILLUSTRATION)
WARNING: CHOKING HAZARD! SMALL PARTS. NOT INTENDED
(SEE ILLUSTRATION)
FOR USE BY CHILDREN UNDER 3 YEARS OF AGE.
BOAT PARTS (SEE ILLUSTRATION)
Boat cover
Display stand
Direction knob
Remote control
flip cover
Power LED
Directional fine
tuning knob
Throttle control
Power switch
trigger
INSTALLING BATTERIES IN THE SPEEDBOAT
1. Open the top cover of the speedboat
3. Connect batteries and JST plug as
shown in diagram above.
SYNCING THE REMOTE CONTROL AND SPEEDBOAT
To properly sync the remote control and speedboat, place the speedboat on the surface of the
water. The speedboat will draw in water through its intakes and its motor will engage. Next, turn
on the remote control. This will light the red light and cause the green light to flash. When the
green light stops flashing, the remote control and the speedboat are synced. The speedboat is
now ready for use.
Boat cover
turn switch
Steering
Bar
Tail
Rudder
Propeller
Charger
Battery Pack
Throttle fine
tuning knob
Frequency
LED
(SEE ILLUSTRATION)
2. Place lithium ion batteries in battery
compartment.
4. Replace top cover of speedboat.
