XPAND UP
Height Adjustable Dual Station– Assembly
Instructions
Tools Required
Cordless Drill
Philips bit with extension
for Work Surface screws
(XP-Screw-WS)
3/16 Hex drive bit
for XP-Screws
Measuring Tape
Level
Rubber Mallet
For additional assembly support, refer to www.openplan.com
or contact 844.OPS.OPS1
www.openplan.com | 844.OPS.OPS1 | sales@openplan.com
Advertisement
Table of Contents
Related Manuals for Openplan XPAND UP
Summary of Contents for Openplan XPAND UP
- Page 1 Instructions Tools Required Cordless Drill Philips bit with extension for Work Surface screws (XP-Screw-WS) 3/16 Hex drive bit for XP-Screws Measuring Tape Level Rubber Mallet For additional assembly support, refer to www.openplan.com or contact 844.OPS.OPS1 www.openplan.com | 844.OPS.OPS1 | sales@openplan.com...
- Page 2 XPand UP – Height Adjustable Dual Station XPand Parts Used for Assembly Item Part name Part Image Item Part name Part Image Description Description XP-HA-Base, leg Legs for XP-HA- XP-CTC Cable Tray Clip Base XP-SB-Bracket Stretcher Bar XP-CTCXX Cable Tray Bracket Cover, XX”...
- Page 3 XPand UP – Height Adjustable Dual Station Step 1: Prepare a large floor space to put the XPand order together. Unpack the parts and check to see if all the XPand parts are present as per the sales order pick list.
- Page 4 XPand UP – Height Adjustable Dual Station Step 5: Assemble the Stretcher Bar (XP-SB-XX) to the Step 6: Repeat Step 1 to Step 6 to assemble the other end of Stretcher Bar Bracket (XP-SB-Bracket) using (3) XP-Screws Height Adjustable Leg Assembly.
- Page 5 XPand UP – Height Adjustable Dual Station Step 8: Snap on the assembled cable tray clips to the Stretcher bar. Step 9: Using the HA-Base screws provided with the HA-Base, assemble the Height Adjustable Frame to the Legs. www.openplan.com | 844.OPS.OPS1 | sales@openplan.com...
- Page 6 XPand UP – Height Adjustable Dual Station Step 12: Place the Work Surface (XP-HA-TXXXX) on the frame. Step 11: Assemble Cable Tray Cover (XP-CTC) to the Height Adjustable Center the Work Surface to the frame and secure the Work Frame using (4) XP-Screws.
- Page 7 XPand UP – Height Adjustable Dual Station Step 13: Snap on the Leg Rail Covers (XP-LRC-XX) to the Leg Rails. Step 14: Level the HA-legs by turning the leveling feet. www.openplan.com | 844.OPS.OPS1 | sales@openplan.com...
